1961 Volvo P1800

SwedenGasoline2WDCoupe

Photos

Specifications

Vehicle Details

Year
1961
Make
Volvo
Model
P1800
Body Style
Coupe
Generation
1st Generation
Seats
2
Doors
2
Fuel
Gasoline
Drivetrain
2WD
Transmission
Manual, 4-speed

Powertrain

Engine Name
1800S Manual
Engine Configuration
Inline
Power (hp)
90 hp
Power (kW)
66 kW
Torque
138 Nm (102 lb-ft)
Top speed
165 km/h (103 mph)
0–60 mph
12.9 seconds (estimated)
0–100 km/h
13.5 seconds
Displacement
1,780 cc

Dimensions

Length
4,350 mm (171.3 in)
Width
1,700 mm (66.9 in)
Height
1,280 mm (50.4 in)
Wheelbase
2,450 mm (96.5 in)
Curb weight
1,135 kg (2,502 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 rpm
Rev. at Max Torque
3,400 rpm
Engine Configuration
Bore
84.1 mm (3.3 in)
Stroke
80 mm (3.1 in)
Compression Ratio
9.5 :1
Engine Configuration
Inline

Transmission & Drivetrain

Transmission
Manual, 4-speed

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
Yes

Fuel

General
Tank Volume
45 litres
Fuel Consumption NEDC
Combined
9.5 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,315 mm (51.8 in)
Track, Rear
1,315 mm (51.8 in)
Turning Circle
9.1 m

Weight

Gross Weight
1,435 kg (3,164 lb)
Max Roof Load
0 kg (0 lb)

Exterior

Chassis & Body

Chassis
Chassis
Coupé
Pillars
A-B
Chassis Construction
Unibody
Doors
Front Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Mechanical
House Colour
Silver
Windows
Window Lifts, Front
Manual
Other Equipment
Sunroof
Optional
Normal Roof
Yes

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Daytime Running Light
Halogen
Special Features
Headlight Washers
Special Features
Headlight Range Adjustment
Manual

Colour

Finish
Solid

Rims & Tires

Fastening Type
Lug Bolts
Rim Material
Steel
Rim Type
Disc Wheel
Spare Wheel
Yes

Interior

Equipment

Instrument Cluster
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Odometer Limit
100,000 km/miles
Connectivity
Radio
FM
Other Equipment
Clock
Analogue
12V Outlet
Front
Carpets
Yes
Ashtray
Yes
Cigarette Lighter
Yes
Other Equipment › Carpets
Material
Textile

Steering Wheel

Material
  • Aluminium
  • Plastic
Colour
Black
Steering Ratio
15.5 :1

Seats

Colour & Material
Upholstery
Leather

Trunk

Rear Trunk
Yes
Flat Surface
Yes

Design

Transmission Knob Material
Plastic

Features

Other Features

Horn
Single Note

Accessories

Tool Kit and Jack
Yes
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional
Trunk Modules
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Front Seats
Seat Belt Colour
Black
Belt Pretensioner
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Other

Car Classification

American Classification
Grand Tourer
Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car

Production

Statistics
Production Number (Series)
47,855
Statistics › Production Number (Year)
1971
3,070
1972
5,007
