1963 Aston Martin DB5

United KingdomGasoline2WDCoupe

Photos

Specifications

Vehicle Details

Year
1963
Make
Aston Martin
Model
DB5
Body Style
Coupe
Generation
1st Generation
Seats
4
Doors
2
Fuel
Gasoline
Drivetrain
2WD
Transmission
  • Automatic
  • Manual, 3
  • 5-speed

Powertrain

Engine Name
4.0
Engine Configuration
Inline
Power (hp)
286 hp
Power (kW)
210 kW
Torque
390 Nm (288 lb-ft)
Top speed
240 km/h (149 mph)
0–60 mph
6.5 seconds (estimated)
0–100 km/h
6.8 seconds
Displacement
3,995 cc

Dimensions

Length
4,572 mm (180.0 in)
Width
1,680 mm (66.1 in)
Height
1,346 mm (53.0 in)
Wheelbase
2,490 mm (98.0 in)
Curb weight
1,466 kg (3,232 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 rpm
Rev. at Max Torque
3,850 rpm
Engine Configuration
Bore
96 mm (3.8 in)
Stroke
92 mm (3.6 in)
Compression Ratio
8.9 :1
Engine Configuration
Inline

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 3
  • 5-speed

Fuel

General
Tank Volume
86 litres
Fuel Consumption NEDC
Combined
16.6 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,372 mm (54.0 in)
Track, Rear
1,360 mm (53.5 in)
Turning Circle
10.3 m
Ground Clearance
160 mm (6.3 in)

Weight

Gross Weight
1,765 kg (3,891 lb)
Cargo Capacity
299 kg (659 lb)
Max Roof Load
50 kg (110 lb)

Exterior

Chassis & Body

Chassis
Chassis
Coupé

Equipment

Other Equipment
Normal Roof
Yes

Interior

Trunk

Rear Trunk
Yes

Other

Car Classification

American Classification
Grand Tourer
British Classification
Grand Tourer
Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car
