1970 Ferrari Dino 246 GT

ItalyGasolineRWDCoupe

Photos

Specifications

Vehicle Details

Year
1970
Make
Ferrari
Model
Dino 246 GT
Body Style
Coupe
Generation
Series litres
Seats
2
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
Manual, 5-speed

Powertrain

Engine Name
2.4 V6 Manual
Engine Configuration
V
Power (hp)
195 hp
Power (kW)
143 kW
Torque
225 Nm (166 lb-ft)
Top speed
235 km/h (146 mph)
Displacement
2,419 cc

Dimensions

Length
4,235 mm (166.7 in)
Width
1,700 mm (66.9 in)
Height
1,135 mm (44.7 in)
Wheelbase
2,340 mm (92.1 in)
Curb weight
1,080 kg (2,381 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
7,600 rpm
Rev. at Max Torque
4,800 rpm
Engine Configuration
Bore
92.5 mm (3.6 in)
Stroke
60 mm (2.4 in)
Compression Ratio
9 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Rear-Mid
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Tri Carburator
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Fuel

General
Tank Volume
65 litres

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Double Wishbone

Dimensions & Weight

Exterior

Track, Front
1,425 mm (56.1 in)
Track, Rear
1,430 mm (56.3 in)

Exterior

Chassis & Body

Chassis
Chassis
Coupé
Doors
Front Doors
Conventional

Equipment

Other Equipment
Normal Roof
Yes

Interior

Steering Wheel

Steering Mechanism
Rack and Pinion

Other

Car Classification

American Classification
Grand Tourer
British Classification
Grand Tourer
Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car

Production

Statistics
Production Number (Series)
3,761
Production Number (Generation)
357
Statistics › Production Number (Model)
1st Generation
357
2nd Generation
506
3rd Generation
1,624
