1976 Mercedes-Benz /8

GermanyDieselRWDSedan

Specifications

Vehicle Details

Year
1976
Make
Mercedes-Benz
Model
/8
Body Style
Sedan
Generation
W114/W115
Seats
5
Doors
4
Fuel
Diesel
Drivetrain
RWD
Transmission
  • Automatic
  • Manual, 4-speed

Powertrain

Engine Name
240 D 3.0
Engine Configuration
Inline
Power (hp)
80 hp
Power (kW)
59 kW
Torque
172 Nm (127 lb-ft)
Top speed
143 km/h (89 mph)
0–60 mph
18.8 seconds
0–100 km/h
19.9 seconds
Displacement
3,005 cc

Dimensions

Length
4,685 mm (184.4 in)
Width
1,770 mm (69.7 in)
Height
1,440 mm (56.7 in)
Wheelbase
2,750 mm (108.3 in)
Curb weight
1,430 kg (3,153 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,000 rpm
Rev. at Max Torque
2,400 rpm
Engine Configuration
Bore
91 mm (3.6 in)
Stroke
92.4 mm (3.6 in)
Compression Ratio
21 :1
Engine Configuration
Inline
Service Intervals
Oil Change & Engine Filter
15,000 km / 1 years

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 4-speed

Brakes

Parking Brake
Manual
Pedal
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
Double Wishbone

Fuel

General
Tank Volume
65 litres
Fuel Consumption NEDC
Combined
9.6 – 10.8 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,444 mm (56.9 in)
Track, Rear
1,440 mm (56.7 in)
Turning Circle
11 m
Ground Clearance
170 mm (6.7 in)

Interior

Head Room, Front
960 mm (37.8 in)
Head Room, Rear
860 mm (33.9 in)
Hip Room, Front
1,490 mm (58.7 in)
Hip Room, Rear
1,485 mm (58.5 in)
Shoulder Room, Front
1,410 mm (55.5 in)
Shoulder Room, Rear
1,405 mm (55.3 in)

Weight

Gross Weight
1,950 kg (4,299 lb)
Max Trailer Load, braked 12%
1,200 kg (2,646 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
520 kg (1,146 lb)
Max Roof Load
30 kg (66 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Other Equipment
Sunroof
Optional
Normal Roof
Yes

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Yes
Fog Lights
Front
Yes
Special Features
Headlight Range Adjustment
Manual

Rims & Tires

Fastening Type
Lug Bolts
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Odometer Limit
100,000 km/miles
Climate Control
Number of Vents, Front
4 pcs
Connectivity
Radio
Optional
Connectivity › Radio
AM
Optional
FM
Optional
Cassette
Optional
Interior Storage › Storage Compartments
Glove Compartment
Lockable
Armrest Hatch
Optional
Interior Storage › Storage Compartments › Armrest Hatch
Front
Optional
Other Equipment
Clock
Analogue
12V Outlet
Front
Carpets
Optional
Cigarette Lighter
Optional

Steering Wheel

Adjustments
Telescope
Material
Plastic
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
530 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Optional
Headrest, Tilt
Optional
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Optional
Headrest, Tilt
Optional
Front Seats
Armrest
Optional
Second Seat Row
Armrest
Yes

Safety & Security

Seat Belt

Seat Belt Colour
Black
Belt Pretensioner
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Other Features

Central Locking
Optional

Other

Car Classification

British Classification
Executive Car
Australian Classification
Large Car
European Segment
E-Segment
Car.info Classification
Executive Car
