1990 Mercedes-Benz S-Class

GermanyGasolineRWDCoupe

Specifications

Vehicle Details

Year
1990
Make
Mercedes-Benz
Model
S-Class
Body Style
Coupe
Generation
W126 Facelift
Seats
5
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic, 4-speed

Powertrain

Engine Name
560 SEC Automatic
Engine Configuration
V
Power (hp)
242 hp
Power (kW)
178 kW
Top speed
228 km/h (142 mph)
0–60 mph
7.2 seconds (estimated)
0–100 km/h
7.6 seconds
Displacement
5,547 cc

Dimensions

Length
4,935 mm (194.3 in)
Width
1,828 mm (72.0 in)
Height
1,407 mm (55.4 in)
Wheelbase
2,850 mm (112.2 in)
Curb weight
1,760 kg (3,880 lb)

Engine & Performance

Engine

Engine Fluids
Semi-synthetic Oil (viscosity)
10W-40
Engine Configuration
Bore
96.5 mm (3.8 in)
Stroke
94.8 mm (3.7 in)
Compression Ratio
9 :1
Engine Configuration
V-Engine
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston

Transmission & Drivetrain

Transmission
Automatic, 4-speed

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
90 litres
Fuel Consumption NEDC
Combined
13.5 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,555 mm (61.2 in)
Track, Rear
1,527 mm (60.1 in)
Turning Circle
11.5 m
Ground Clearance
150 mm (5.9 in)

Weight

Gross Weight
2,220 kg (4,894 lb)
Max Trailer Load, braked 12%
1,500 kg (3,307 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
460 kg (1,014 lb)
Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
Coupé
Pillars
A-B
Chassis Construction
Unibody
Doors
Front Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Heat-Insulating Windows
Optional
Tinted Windows
Optional
Safety Glass
Yes
Windows › Heat-Insulating Windows
Front
Optional
First Row
Optional
Second Row
Optional
Rear
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Windows › Safety Glass
Front
Laminated
Side
Tempered
Rear
Tempered
Other Equipment
Sunroof
Optional
Tow Hook
Front
Normal Roof
Yes
Antenna
Optional
Mud Flaps
Optional
Other Equipment › Sunroof
Sun Blind
Optional
Other Equipment › Sunroof › Sun Blind
Tinted Glass
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Optional
Special Features
Headlight Range Adjustment
Manual

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
112
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
66.6
Fastening Type
Lug Bolts
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Climate Control
Air Condition
Optional
Connectivity
Radio
Optional
Connectivity › Radio
AM
Optional
FM
Optional
Cassette
Optional
Rear-view Mirror
Anti-glare
Manual
Interior Storage › Storage Compartments
Glove Compartment
Lockable (Manual)
Armrest Hatch
Optional
Back Pocket
Optional
Coin Holder
Optional
Card Holder
Optional
Fridge
Optional
Under Seats
Optional
Interior Storage › Storage Compartments › Glove Compartment
Light
Optional
Interior Storage › Storage Compartments › Armrest Hatch
Front
Optional
Interior Storage › Storage Compartments › Fridge
Trunk
Optional
Interior Storage › Storage Compartments › Under Seats
Front
Optional
Lights
Read Light
Front
Guide Light
Entry Guard
Lights › Read Light
Rear
Optional
Other Equipment › Make-up Mirror
Driver Side
Optional
Passenger Side
Optional
Make-up Light
Optional
Other Equipment
Clock
Yes
12V Outlet
Front
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › 12V Outlet
Rear
Optional
Other Equipment › Carpets
Front
Optional
Rear
Optional
Other Equipment › Ashtray
Front
Optional
Rear
Optional

Steering Wheel

Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Number of Spokes
4
Material
Leather
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Light
Yes
Rear Trunk
Volume
510 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Manual
Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Armrest
Optional
Type of Seat
Comfort Seat (Driver | Passenger)
Front Seats › Heated Seats
Cushion
Optional
Second Seat Row
Number of Seats
2
Type of Seat
Adult

Features

Comfort Features

Cruise Control
Optional

Other Features

Horn
Dual Note

Accessories

Tool Kit and Jack
Yes
Tire Repair Kit
Optional
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Yes
First Aid Kit
Yes
Trunk Modules
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Feature
Seat Belt Reminder
Belt Pretensioner
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats

Other Features

Anti-theft Alarm
Optional

Airbags

Frontal Airbag
  • Driver: Optional
  • Passenger: Optional
  • Rear: -

Other

Car Classification

American Classification
Full-Size Luxury Car
British Classification
Luxury Car
Australian Classification
Upper Large Car
European Segment
F-Segment
Car.info Classification
Luxury Car
