1993 Chrysler LHS

United StatesGasolineFWDSedan

Photos

Specifications

Vehicle Details

Year
1993
Make
Chrysler
Model
LHS
Body Style
Sedan
Generation
1st Generation
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic, 4-speed

Powertrain

Engine Name
3.5 V6 Automatic
Engine Configuration
V
Power (hp)
218 hp
Power (kW)
160 kW
Displacement
3,518 cc

Dimensions

Length
5,268 mm (207.4 in)
Width
1,890 mm (74.4 in)
Height
1,415 mm (55.7 in)
Wheelbase
2,870 mm (113.0 in)
Curb weight
1,580 kg (3,483 lb)

Engine & Performance

Engine

Engine Fluids
Synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Oil, Volume
4.8 litres
Engine Configuration
Bore
96 mm (3.8 in)
Stroke
81 mm (3.2 in)
Compression Ratio
10.4 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Belt
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
OHC
Engine Block
Cast Iron
Engine Heads
Aluminium

Transmission & Drivetrain

Transmission
Automatic, 4-speed

Fuel

General
Tank Volume
68 litres
Fuel Consumption NEDC
City
13.1 litres / 100 km
Highway
9 litres / 100 km
Combined
11.3 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,575 mm (62.0 in)
Track, Rear
1,575 mm (62.0 in)
Turning Circle
11.5 m

Interior

Head Room, Front
975 mm (38.4 in)
Head Room, Rear
947 mm (37.3 in)
Leg Room, Front
1,074 mm (42.3 in)
Leg Room, Rear
983 mm (38.7 in)
Hip Room, Front
1,427 mm (56.2 in)
Hip Room, Rear
1,476 mm (58.1 in)
Shoulder Room, Front
1,499 mm (59.0 in)
Shoulder Room, Rear
1,496 mm (58.9 in)

Weight

Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Platform
Chrysler Platforms
LH Platform

Equipment

Other Equipment
Normal Roof
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
71.6
Fastening Type
Lug Nuts

Interior

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
505 litres

Other

Car Classification

American Classification
Full-Size Luxury Car
British Classification
Luxury Car
Australian Classification
Upper Large Car
European Segment
F-Segment
Car.info Classification
Luxury Car

Awards

Canadian
Car of the Year
1993
