1993 SEAT Ibiza

SpainGasolineFWDHatchback

Specifications

Vehicle Details

Year
1993
Make
SEAT
Model
Ibiza
Body Style
Hatchback
Generation
021A
Seats
5
Doors
3
Fuel
Gasoline
Drivetrain
FWD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.7i Manual
Engine Configuration
Inline
Power (hp)
101 hp
Power (kW)
74 kW
Torque
138 Nm (102 lb-ft)
Top speed
182 km/h (113 mph)
0–60 mph
9.9 seconds (estimated)
0–100 km/h
10.4 seconds
Displacement
1,675 cc

Dimensions

Length
3,683 mm (145.0 in)
Width
1,610 mm (63.4 in)
Height
1,394 mm (54.9 in)
Wheelbase
2,443 mm (96.2 in)
Curb weight
950 kg (2,094 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,700 rpm
Rev. at Max Torque
3,800 rpm
Car Battery
Battery Capacity
55 Ah
Alternator Charge Current
65 A
Engine Configuration
Bore
83 mm (3.3 in)
Stroke
77.4 mm (3.0 in)
Compression Ratio
10.8 :1
Engine Configuration
Inline
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Fuel Injection
Engine Cooling
Liquid Cooling

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes

Suspensions

Spring, Front
  • Coil
  • Leaf
Spring, Rear
  • Coil
  • Leaf
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Yes

Fuel

General
Tank Volume
42 litres
General › Fuel Cap Position
Rear
Right
Fuel Consumption NEDC
City
10.1 litres / 100 km
Combined
6.7 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,421 mm (55.9 in)
Track, Rear
1,375 mm (54.1 in)
Turning Circle
10 - 10.2 m
Ground Clearance
125 mm (4.9 in)

Weight

Gross Weight
1,450 kg (3,197 lb)
Max Trailer Load, braked 12%
1,000 kg (2,205 lb)
Cargo Capacity
500 kg (1,102 lb)
Max Roof Load
50 kg (110 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Mechanical
Folding
Manual
House Colour
Black
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Number of Windscreen Wipers, Front
1
Windows
Heated Windows
Rear
Heat-Insulating Windows
Optional
Tinted Windows
Optional
Safety Glass
Yes
Windows › Heat-Insulating Windows
Front
Optional
First Row
Optional
Second Row
Optional
Rear
Optional
Windows › Tinted Windows
Windscreen, upper part
Optional
Second Row
Optional
Rear Window
Optional
Windows › Safety Glass
Front
Laminated
Side
Tempered
Rear
Tempered
Other Equipment
Sunroof
Optional
Tow Hook
  • Front
  • Rear
Antenna
Whip
Mud Flaps
Optional
Other Equipment › Sunroof
Sun Blind
Optional
Other Equipment › Sunroof › Sun Blind
Tinted Glass
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Yes
Fog Lights
Rear
Halogen
Headlight Washers
Optional

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
98
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
58.1
Fastening Type
Lug Bolts
Rim Type
Disc Wheel
Spare Wheel
Full-size (Steel)

Interior

Equipment

Instrument Cluster
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Climate Control
Air Condition
Optional
Pollen Filter
Optional
Controls
Rotary Dials
Connectivity
Radio
Optional
Radio Preparation
Yes
Connectivity › Radio
AM
Optional
FM
Optional
Connectivity › Radio Preparation
Cassette
Optional
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Lockable (Manual)
Armrest Hatch
Optional
Back Pocket
Optional
Sunglass Compartment
Optional
Card Holder
Yes
Under Seats
Optional
Door
  • Driver Side
  • Passenger Side
Interior Storage › Storage Compartments › Glove Compartment
Light
Optional
Interior Storage › Storage Compartments › Armrest Hatch
Front
Optional
Interior Storage › Storage Compartments › Under Seats
Front
Optional
Interior Storage
Cup Holders
Optional
Lights
Read Light
Front
Guide Light
  • Entry Guard
  • Bottom of the Doors
Lights › Read Light
Rear
Optional
Other Equipment › Make-up Mirror
Driver Side
Optional
Passenger Side
Optional
Make-up Light
Optional
Other Equipment
Clock
Optional
12V Outlet
Front
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Clock
Analogue
Optional
Digital
Optional
Other Equipment › Carpets
Front
Optional
Rear
Optional
Other Equipment › Ashtray
Front
Optional
Rear
Optional

Steering Wheel

Number of Spokes
3
Material
Polyurethane
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Carpet
Optional
Hatch Opening Type
From Roof
Rear Trunk
Volume
320 litres
Volume, Back Seat Collapsed
1,200 litres
Carpet
Rubber
Optional

Seats

Colour & Material
Upholstery
Textile
Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Optional
Backrest Angle
Manual
Lumbar Support
Optional
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Seat Height
Optional
Backrest Angle
Manual
Lumbar Support
Optional
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Heated Seats
Optional
Armrest
Optional
Front Seats › Heated Seats
Cushion
Optional
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Optional

Features

Comfort Features

Parking Heater
Optional
Parking Heater Preparation
Optional
Parking Heater
Cabin Heater
Optional
Parking Heater › Cabin Heater
Engine Heater
Optional
Remote
Optional

Other Features

Horn
Single Note

Accessories

Tool Kit and Jack
Yes
Tire Repair Kit
Optional
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional
Bicycle Holder
Optional
Coat Hanger
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Belt Pretensioner
  • Driver: Yes
  • Passenger: Yes
  • Rear: -
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats

Brake Systems

Power Brakes
Optional
Anti-lock Braking System (ABS)
Optional

Other Features

Immobiliser
Optional
Central Locking
Yes
Central Locking
Remote
Optional

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Right
Engine Compartment, Front Panel
Yes

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
Supermini
Australian Classification
Light Car
European Segment
B-Segment
Car.info Classification
Small Family Car
