1995 Volkswagen Passat Variant

GermanyGasoline2WDWagon

Specifications

Vehicle Details

Year
1995
Make
Volkswagen
Model
Passat
Variant
Variant
Body Style
Wagon
Generation
B4 (Type 3A)
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
2WD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.6 Manual
Power (hp)
101 hp
Power (kW)
74 kW
Torque
135 Nm (100 lb-ft)
Displacement
1,595 cc

Dimensions

Length
4,595 mm (180.9 in)
Width
1,720 mm (67.7 in)
Height
1,445 mm (56.9 in)
Wheelbase
2,630 mm (103.5 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,800 rpm
Rev. at Max Torque
4,400 rpm

Fuel

General › Fuel Cap Position
Rear
Right

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Semi-dependent
Twist-Beam

Dimensions & Weight

Exterior

Track, Front
1,480 mm (58.3 in)
Track, Rear
1,420 - 1,435 mm (55.9 - 56.5 in)
Turning Circle
10.7 m
Ground Clearance
110 mm (4.3 in)

Weight

Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon
Pillars
A-D
Chassis Construction
Unibody
Body Material
Steel
Roof Material
Steel
Protective Moldings
Yes
Chassis › Protective Moldings
Front
Mid-Strip
Rear
Mid-Strip
Sides
Mid-Strip
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
Volkswagen Group
B4

Equipment

Side Mirrors
Mirror Type
Conventional
Folding
Manual
Mirror Shape, Driver side
Aspheric
Windscreen Wipers
Heated Washer Nozzles
Optional
Intermittent Control
Yes
Rear Wiper
Yes
Rear Washer System
Yes
Windscreen Wipers: Connector type, Front
Hook
Windows › Window Lifts, Features
Pinch Protection
Optional
One-touch up/down
Optional
Windows › Window Lifts, Features › Pinch Protection
Driver
Optional
Passenger
Optional
Windows › Window Lifts, Features › One-touch up/down
Driver
Optional
Passenger
Optional
Windows
Heated Windows
Rear
Heat-Insulating Windows
Front
Tinted Windows
Optional
Safety Glass
Yes
Windows › Heat-Insulating Windows
First Row
Optional
Second Row
Optional
Rear
Optional
Windows › Tinted Windows
Windscreen, upper part
Optional
Second Row
Optional
Rear Window
Optional
Windows › Safety Glass
Front
Laminated
Side
Tempered
Rear
Tempered
Other Equipment
Sunroof
Optional
Tow Hook
  • Front
  • Rear
Roof Railing
Yes
Antenna
Whip
Mud Flaps
Optional
Other Equipment › Sunroof
Sun Blind
Optional
Other Equipment › Sunroof › Sun Blind
Tinted Glass
Optional
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)
Colour
Black
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Yes
Fog Lights
Rear
Halogen
Special Features
Headlight Washers
Optional
Headlight Range Adjustment
Manual (Electric)

Colour

Door Handles
Non-painted

Rims & Tires

Fastening Type
Lug Bolts
Anti-Theft Locking Lug Nuts/Bolts
Optional
Rim Type
Disc Wheel
Spare Wheel
Full-size (Steel)

Interior

Equipment

Instrument Cluster
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Number of Climate Zones
1
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Optional
Controls
Rotary Dials
Climate Control › Controls
Buttons
Optional
Connectivity
Radio
Optional
Radio Preparation
Yes
Connectivity › Radio
AM
Optional
FM
Optional
Connectivity › Media Format
CD
Optional
Cassette
Optional
Speakers
Total Number of Speakers
4 pcs
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
  • Light
  • Lockable (Manual)
Armrest Hatch
Optional
Back Pocket
Yes
Coin Holder
Optional
Card Holder
Optional
Door
  • Driver Side
  • Passenger Side
Interior Storage › Storage Compartments › Glove Compartment
Cooled
Optional
Interior Storage › Storage Compartments › Armrest Hatch
Front
Optional
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Interior Storage › Cup Holders › Front
Placement
  • Middle of Media Center
  • Top of Front Panel
Lights
Read Light
Front
Guide Light
  • Entry Guard
  • Bottom of the Doors
Other Equipment
Make-up Mirror
Passenger Side
Clock
Yes
12V Outlet
Front
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Yes
Other Equipment › Make-up Mirror
Driver Side
Optional
Make-up Light
Optional
Other Equipment › Clock
Digital
Instrument Cluster
Other Equipment › 12V Outlet
Rear
Optional
Other Equipment › Carpets
Front
Optional
Rear
Optional
Other Equipment › Ashtray
Front
Optional
Rear
Optional

Steering Wheel

Power Steering
Hydraulic
Adjustments
  • Tilt
  • Telescope
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Barrier Net/Grid
Optional
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
465 litres
Volume, Back Seat Collapsed
1,500 litres
Opening Width
1,120 mm (44.1 in)

Design

Interior Decor Material
Plastic
Pedals
Standard

Seats

Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Yes
Backrest Angle
Manual
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Seat Height
Optional
Backrest Angle
Manual
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Armrest
Optional
Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40
Heated Seats
Optional
Second Seat Row › Headrests
Outer Seats
Optional
Centre Seat
Optional
Second Seat Row › Headrests › Outer Seats
Height Adjustment
Optional

Features

Comfort Features

Cruise Control
Optional
Parking Heater
Optional
Parking Heater Preparation
Optional
Parking Heater
Cabin Heater
Optional
Parking Heater › Cabin Heater
Engine Heater
Optional
Remote
Optional
Timer
Optional

Accessories

Tool Kit and Jack
Yes
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional
Trunk Modules
Optional
Bicycle Holder
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Brake Systems

Power Brakes
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes

Other Features

Anti-theft Alarm
Optional
Child Safety Locks
Manual

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Optional
  • Rear: -

Child Protection

Feature
Isofix
Integrated Child Seat

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Centre

Car Classification

American Classification
Mid-Size Car
British Classification
Large Family Car
Australian Classification
Medium Car
European Segment
D-Segment
Car.info Classification
Large Family Car

Spare Parts BETA

Bulb Types
Low Beam
  • H1
  • H4
Main Beam
  • H1
  • H4
Fog Light, Front
H1
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BA15s (P21W)
Reversing Light
BA15s (P21W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BA15s (P21W)
Read Light
  • BA9s (T4W)
  • W2.1×9.5d (W5W)
Trunk
SV8.5 (C5W)
License Plate Light
W2.1×9.5d (W5W)
