1997 Ford Expedition

United StatesGasoline4WDSUV

Photos

Specifications

Vehicle Details

Year
1997
Make
Ford
Model
Expedition
Body Style
SUV
Generation
1st Generation (UN93)
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
4WD
Transmission
Automatic, 4-speed

Powertrain

Engine Name
5.4 V8 SEFI 2V ControlTrac Automatic
Engine Configuration
V
Power (hp)
233 hp
Power (kW)
172 kW
Torque
441 Nm (325 lb-ft)
Top speed
180 km/h (112 mph)
0–60 mph
9.5 seconds (estimated)
0–100 km/h
10 seconds
Displacement
5,408 cc

Dimensions

Length
5,196 mm (204.6 in)
Width
2,000 mm (78.7 in)
Height
1,943 mm (76.5 in)
Wheelbase
3,023 mm (119.0 in)
Curb weight
2,360 kg (5,203 lb)

Engine & Performance

Engine

Engine Configuration
Bore
90.2 mm (3.6 in)
Stroke
105.7 mm (4.2 in)
Compression Ratio
9 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Type of Combustion Engine
Piston

Transmission & Drivetrain

Transmission
Automatic, 4-speed

Fuel

General
Tank Volume
98 litres
General › Fuel Cap Position
Rear
Left
Fuel Consumption NEDC
City
18.1 litres / 100 km
Highway
13.1 litres / 100 km

Dimensions & Weight

Exterior

Width, with Mirrors
2,293 mm (90.3 in)
Track, Front
1,661 mm (65.4 in)
Track, Rear
1,663 mm (65.5 in)
Turning Circle
12.5 m
Ground Clearance
216 mm (8.5 in)

Weight

Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Ford Motor Company
U Platform (U1)

Equipment

Side Mirrors
Mirror Type
Conventional
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Other Equipment
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)
Colour
Black

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
135
Nut/Bolt Dimensions
M12x1.75
Central Bore (CB), front
86.8
Fastening Type
Lug Nuts
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Oil Pressure
Analogue
Oil Temperature
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Interior Storage › Storage Compartments
Glove Compartment
Yes
Back Pocket
Yes
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Lights
Read Light
Front

Steering Wheel

Adjustments
Telescope
Number of Spokes
2

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
337 litres
Volume, Back Seat Collapsed
3,347 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Second Seat Row
Collapsible
Yes
Number of Seats
3
Type of Seat
Adult
Third/Fourth Seat Row
Third Seat Row
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Rear Centre Seat Belt
Yes
Belt Pretensioner
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: -
  • Rear: -

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Full-Size SUV
British Classification
Large 4x4
Australian Classification
Upper Large SUV
European Segment
J-Segment
Car.info Classification
Large SUV

Awards

North American
Truck of the Year
1997
