1998 Peugeot Partner

FranceGasolineFWDLCV

Specifications

Vehicle Details

Year
1998
Make
Peugeot
Model
Partner
Body Style
LCV
Generation
S1
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.8 Manual
Engine Configuration
Inline
Power (hp)
90 hp
Power (kW)
66 kW
Torque
147 Nm (108 lb-ft)
Top speed
160 km/h (99 mph)
0–60 mph
11.6 seconds (estimated)
0–100 km/h
12.2 seconds
Displacement
1,761 cc

Dimensions

Length
4,108 mm (161.7 in)
Width
1,719 mm (67.7 in)
Height
1,801 mm (70.9 in)
Wheelbase
2,690 mm (105.9 in)
Curb weight
1,145 kg (2,524 lb)

Engine & Performance

Engine

Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 5W-30
  • 5W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-40
  • 15W-40
Engine Configuration
Bore
83 mm (3.3 in)
Stroke
81 mm (3.2 in)
Compression Ratio
10.2 :1
Engine Configuration
Inline
Synchronization
Timing Belt
Engine Placement
Front
Type of Combustion Engine
Piston
Service Intervals
Timing Interval
120,000 km / 10 years
Air Filter
60,000 km (37,282 mi)
Fuel Filter
60,000 km (37,282 mi)
Spark Plug
60,000 km (37,282 mi)
Brake Fluid
60,000 km / 2 years
Oil Change & Engine Filter
30,000 km / 2 years
Engine Coolant
120,000 km (74,565 mi)
Interior Filter
15000 – 30000 km / 2 years

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Dependent
Yes

Fuel

General
Tank Volume
55 litres
Fuel Consumption NEDC
City
11.9 litres / 100 km
Highway
7.1 litres / 100 km
Combined
8.9 litres / 100 km
Emission NEDC
CO₂, Combined
213 g/km

Dimensions & Weight

Exterior

Track, Front
1,442 mm (56.8 in)
Track, Rear
1,440 mm (56.7 in)
Turning Circle
11.3 m
Ground Clearance
140 mm (5.5 in)

Weight

Gross Weight
1,780 kg (3,924 lb)
Max Trailer Load, braked 12%
1,100 kg (2,425 lb)
Max Trailer Load, unbraked
620 kg (1,367 lb)
Cargo Capacity
635 kg (1,400 lb)
Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
LCV (Minibus)
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Sliding (Left | Right)

Equipment

Side Mirrors
Mirror Type
Conventional
Folding
Manual
Heated
Optional
Mirror Shape, Driver side
Aspheric
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Windscreen Wipers: Connector type, Front
Hook
Number of Windscreen Wipers, Front
2
Windows › Window Lifts, Features
Pinch Protection
Optional
Windows › Window Lifts, Features › Pinch Protection
Driver
Optional
Passenger
Optional
Windows
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Yes
Safety Glass
Yes
Windows › Safety Glass
Front
Laminated
Side
Tempered
Rear
Tempered
Other Equipment
Tow Hook
  • Front
  • Rear
Normal Roof
Yes
Antenna
Whip
Mud Flaps
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Yes
Fog Lights
Rear
Halogen
Special Features
Headlight Range Adjustment
Manual

Colour

Non-painted
Bumper (Front | Rear)
Door Handles
Non-painted

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
108
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
65.1
Fastening Type
Lug Bolts
Rim Colour
Grey
Rim Type
Disc Wheel
Spare Wheel
Optional
Spare Wheel
Full-size
Optional
Spare Wheel › Full-size
Steel
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Optional
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Air Condition
Optional
Pollen Filter
Optional
Outside Temperature Indicator
Optional
Connectivity
Radio
Optional
Radio Preparation
Yes
Connectivity › Radio
AM
Optional
FM
Optional
Connectivity › Media Format
CD
Optional
Cassette
Optional
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Manual
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Lockable (Manual)
Armrest Hatch
Optional
Sunglass Compartment
Optional
Coin Holder
Optional
Card Holder
Yes
Under Seats
Optional
Door
  • Driver Side
  • Passenger Side
Interior Storage › Storage Compartments › Glove Compartment
Light
Optional
Interior Storage › Storage Compartments › Armrest Hatch
Front
Optional
Interior Storage › Storage Compartments › Under Seats
Front
Optional
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Lights
Read Light
Front
Guide Light
Entry Guard
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
Front
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Clock
Digital
Instrument Cluster
Other Equipment › Carpets
Front
Optional
Rear
Optional
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Optional
Power Steering
Yes
Adjustments
Telescope
Material
Plastic
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Cargo Hooks
Yes
Flat Surface
Yes
Light
Yes
Hatch Opening Type
Two-parted Doors
Rear Trunk
Volume
600 litres
Volume, Back Seat Collapsed
2,800 litres
Depth
810 mm (31.9 in)

Design

Transmission Knob Material
Plastic
Pedals
Standard

Seats

Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Seat Height
Optional
Backrest Angle
Manual
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Heated Seats
Optional
Armrest
Optional
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult

Features

Comfort Features

Cruise Control
Optional
Speed Limiter
Optional
Parking Heater
Optional
Parking Heater Preparation
Optional
Parking Heater
Cabin Heater
Optional
Parking Heater › Cabin Heater
Engine Heater
Optional
Remote
Optional
Timer
Optional

Other Features

Horn
Dual Note

Accessories

Tool Kit and Jack
Yes
Tire Repair Kit
Optional
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional
Coat Hanger
Yes

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Centre Rear Seat

Brake Systems

Anti-lock Braking System (ABS)
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Optional
Central Locking
Remote
Optional

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Airbag cut-off Switch

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Yes
Engine Compartment, Inner Wing
Right

Car Classification

European Segment
M-Segment
Car.info Classification
Passenger Van

Spare Parts BETA

Bulb Types
Low Beam
H4
Main Beam
H4
Fog Light, Front
H1
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
BA15s (P21W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Side
W2.1×9.5d (W5W | WY5W)
Turn Indicators, Rear
BAU15s (PY21W)
Read Light
W2.1×9.5d (W5W)
License Plate Light
W2.1×9.5d (W5W)
