1999 Lincoln Navigator

United StatesGasoline4WDSUV

Photos

Specifications

Vehicle Details

Year
1999
Make
Lincoln
Model
Navigator
Body Style
SUV
Generation
1st Generation (UN173)
Seats
7
Doors
4
Fuel
Gasoline
Drivetrain
4WD
Transmission
Automatic, 4-speed

Powertrain

Engine Name
5.4 V8 SEFI 4V ControlTrac Automatic
Engine Configuration
V
Power (hp)
304 hp
Power (kW)
224 kW
Torque
481 Nm (355 lb-ft)
Top speed
202 km/h (126 mph)
0–60 mph
9 seconds
0–100 km/h
9.6 seconds
Displacement
5,408 cc

Dimensions

Length
5,202 mm (204.8 in)
Width
2,030 mm (79.9 in)
Height
1,950 mm (76.8 in)
Wheelbase
3,025 mm (119.1 in)
Curb weight
2,532 kg (5,582 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,000 rpm
Rev. at Max Torque
2,750 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Oil, Volume
6.6 litres
Engine Configuration
Bore
90.2 mm (3.6 in)
Stroke
105.8 mm (4.2 in)
Compression Ratio
9.5 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
DOHC
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
Automatic, 4-speed

Fuel

General
Tank Volume
113 litres

Brakes

Parking Brake
Manual

Dimensions & Weight

Exterior

Track, Front
1,660 mm (65.4 in)
Track, Rear
1,660 mm (65.4 in)
Turning Circle
12.3 m
Ground Clearance
220 mm (8.7 in)

Weight

Gross Weight
3,266 kg (7,200 lb)
Cargo Capacity
734 kg (1,618 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Platform
Ford Motor Company
U Platform (U1)

Equipment

Other Equipment
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)
Colour
Silver

Lights

Main Beam
Halogen
Low Beam
Halogen

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
135
Nut/Bolt Dimensions
M14x2
Central Bore (CB), front
70.3

Interior

Equipment

Instrument Cluster
Tachometer
Analogue

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
1,832 litres
Volume, Back Seat Collapsed
3,295 litres

Seats

Second Seat Row
Collapsible
Yes
Third/Fourth Seat Row
Third Seat Row
Yes

Other

Car Classification

American Classification
Full-Size SUV
British Classification
Large 4x4
Australian Classification
Upper Large SUV
European Segment
J-Segment
Car.info Classification
Large SUV
