1999 Toyota Celica TS

JapanGasolineFWDHatchback

Photos

Specifications

Vehicle Details

Year
1999
Make
Toyota
Model
Celica
Variant
TS
Body Style
Hatchback
Generation
T230
Seats
4
Doors
3
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic
  • Manual, 4
  • 6-speed

Powertrain

Engine Name
TS
Engine Configuration
Inline
Power (hp)
192 hp
Power (kW)
141 kW
Torque
180 Nm (133 lb-ft)
Top speed
225 km/h (140 mph)
0–60 mph
7.0 seconds (estimated)
0–100 km/h
7.4 seconds
Displacement
1,796 cc

Dimensions

Length
4,350 mm (171.3 in)
Width
1,735 mm (68.3 in)
Height
1,315 mm (51.8 in)
Wheelbase
2,600 mm (102.4 in)
Curb weight
1,115 kg (2,458 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
7,800 rpm
Rev. at Max Torque
6,800 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 5W-30
  • 10W-30
Semi-synthetic Oil (viscosity)
  • 10W-30
  • 15W-40
Engine Oil, Volume
4.4 litres
Engine Configuration
Bore
82 mm (3.2 in)
Stroke
85 mm (3.3 in)
Compression Ratio
11.5 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston
Service Intervals
Air Filter
60,000 km / 4 years
Spark Plug
60,000 km / 4 years
Brake Fluid
30,000 km / 2 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
90,000 km (55,923 mi)
Interior Filter
30,000 km / 2 years

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 4
  • 6-speed

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
55 litres
Fuel Consumption NEDC
City
10.2 – 11.5 litres / 100 km
Highway
6.6 – 7.8 litres / 100 km
Combined
8.4 litres / 100 km
Emission NEDC
CO₂, Combined
200 g/km

Dimensions & Weight

Exterior

Track, Front
1,490 mm (58.7 in)
Track, Rear
1,480 mm (58.3 in)
Turning Circle
10.4 m
Ground Clearance
140 mm (5.5 in)

Interior

Head Room, Front
975 mm (38.4 in)
Head Room, Rear
889 mm (35.0 in)
Leg Room, Front
1,107 mm (43.6 in)
Leg Room, Rear
686 mm (27.0 in)
Hip Room, Front
1,303 mm (51.3 in)
Hip Room, Rear
1,189 mm (46.8 in)
Shoulder Room, Front
1,336 mm (52.6 in)
Shoulder Room, Rear
1,285 mm (50.6 in)

Weight

Gross Weight
1,595 kg (3,516 lb)
Max Trailer Load, braked 12%
1,200 kg (2,646 lb)
Max Trailer Load, unbraked
585 kg (1,290 lb)
Cargo Capacity
480 kg (1,058 lb)
Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Platform
Toyota Platform
MC Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Mechanical
Folding
Manual
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Optional
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Tinted Windows
  • Front
  • Second Row
  • Rear Window
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Spoiler
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Daytime Running Light
Halogen
Fog Lights
Yes
Auxiliary Lights
Spot Light
Fog Lights
Front
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
54.1
Fastening Type
Lug Nuts
Rim Material
Alloy
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Shape
Cockpit
Climate Control
Number of Climate Zones
1
Air Condition
Yes
Outside Temperature Indicator
Yes
Number of Vents, Front
4 pcs
Connectivity
Radio
Optional
Connectivity › Radio
AM
Optional
FM
Optional
Connectivity › Media Format
CD
Optional
Displays
Center Display
Yes
Center Display Controls
Buttons
Displays › Center Display
Type
Monochrome
Speakers
Total Number of Speakers
6 - 8 pcs
Rear-view Mirror
Anti-glare
Manual
Interior Storage › Storage Compartments
Glove Compartment
Lockable (Manual)
Armrest Hatch
Front
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
Yes
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Guide Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
Front
Ashtray
Front
Cigarette Lighter
Yes
Other Equipment › Clock
Digital
Center Display

Steering Wheel

Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Sport
Yes
Number of Spokes
3
Material
Leather
Colour
Black

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
232 litres
Volume, Back Seat Collapsed
593 litres
Depth
870 mm (34.3 in)
Depth, Back Seat Collapsed
1,530 mm (60.2 in)

Design

Interior Decor Colour
Black

Seats

Colour & Material
Seat Colour
Black
Stitching Colour
Black
Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Backrest Angle
Manual
Front Seats
Armrest
Middle
Type of Seat
Sport Seats
Second Seat Row
Collapsible
Manual
Number of Seats
2
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
50/50

Features

Comfort Features

Keyless Entry
Optional
Cruise Control
Optional
Parking Heater
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner

Brake Systems

Anti-lock Braking System (ABS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes

Other Features

Immobiliser
Yes
Central Locking
Remote

Airbags

Feature
Frontal Airbag
Side Chest Airbag

Other

Identification

VIN Location
Engine Compartment, Bulkhead
  • Centre
  • Right

Car Classification

Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car

Spare Parts BETA

Bulb Types
Low Beam
  • D2S (xenon)
  • H7
Main Beam
  • HB3
  • HIR1
Fog Light, Front
H3
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
W3×16q (W21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Side
W2.1×9.5d (W5W)
Turn Indicators, Rear
  • BAU15s (PY21W)
  • W3×16d (W21W)
Read Light
SV8.5 (C10W)
Trunk
SV8.5 (C5W)
License Plate Light
W2.1×9.5d (W5W)
