2001 Lexus LS

JapanGasolineRWDSedan

Photos

Specifications

Vehicle Details

Year
2001
Make
Lexus
Model
LS
Body Style
Sedan
Generation
UCF30
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic, 5-speed

Powertrain

Engine Name
430 Automatic
Engine Configuration
V
Power (hp)
282 hp
Power (kW)
207 kW
Torque
417 Nm (308 lb-ft)
Top speed
250 km/h (155 mph)
0–60 mph
6.4 seconds (estimated)
0–100 km/h
6.7 seconds
Displacement
4,293 cc

Dimensions

Length
5,005 mm (197.0 in)
Width
1,830 mm (72.0 in)
Height
1,470 mm (57.9 in)
Wheelbase
2,925 mm (115.2 in)
Curb weight
1,830 kg (4,034 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,600 rpm
Rev. at Max Torque
3,500 rpm
Engine Fluids
Engine Oil, Volume
4.5 litres
Engine Configuration
Bore
91 mm (3.6 in)
Stroke
82.5 mm (3.2 in)
Compression Ratio
10.5 :1
Engine Configuration
V-Engine
Synchronization
Timing Belt

Transmission & Drivetrain

Transmission
Automatic, 5-speed

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
84 litres
Emission
Emission Standard
Euro 4
Fuel Consumption NEDC
City
17.5 litres / 100 km
Highway
8.9 litres / 100 km
Combined
12.1 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,575 mm (62.0 in)
Track, Rear
1,575 mm (62.0 in)
Turning Circle
10.4 m
Ground Clearance
145 mm (5.7 in)

Weight

Gross Weight
2,350 kg (5,181 lb)
Max Trailer Load, braked 12%
2,000 kg (4,409 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
520 kg (1,146 lb)
Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan

Equipment

Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Other Equipment
Normal Roof
Yes

Lights

Main Beam
Halogen
Low Beam
Halogen
Fog Lights
Yes
Fog Lights
Front
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
60.1
Fastening Type
Lug Nuts

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
Yes
Connectivity › Media Format
CD
Multiple CD Changer
DVD
Optional
Displays
Center Display
Optional

Seats

Colour & Material
Upholstery
Leather

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
552 litres
Depth
960 mm (37.8 in)

Features

Comfort Features

Keyless Entry
Yes
Cruise Control
Yes

Other Features

GPS
Optional

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Rain Sensors
Yes

Other Features

Immobiliser
Yes
Central Locking
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Airbag cut-off Switch

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Left Side Casing of Window
Yes
Pillar
  • B-Pillar, Left
  • B-Pillar, Right

Car Classification

American Classification
Full-Size Luxury Car
British Classification
Luxury Car
Australian Classification
Upper Large Car
European Segment
F-Segment
Car.info Classification
Luxury Car
