2002 Ferrari 550 Maranello

ItalyGasolineRWDConvertible

Specifications

Vehicle Details

Year
2002
Make
Ferrari
Model
550 Maranello
Body Style
Convertible
Generation
F133
Seats
2
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
Manual, 6-speed

Powertrain

Engine Name
5.5 V12 Manual
Engine Configuration
V
Power (hp)
485 hp
Power (kW)
357 kW
Torque
569 Nm (420 lb-ft)
Top speed
300 km/h (186 mph)
0–60 mph
4.3 seconds
0–100 km/h
4.4 seconds
Displacement
5,474 cc

Dimensions

Length
4,550 mm (179.1 in)
Width
1,935 mm (76.2 in)
Height
1,277 mm (50.3 in)
Wheelbase
2,500 mm (98.4 in)
Curb weight
1,690 kg (3,726 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
7,000 rpm
Rev. at Max Torque
5,000 rpm
Redline
7,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
5W-40
Engine Oil, Volume
10 litres
Transmission Fluid, Volume
4.5 litres
Engine Coolant, Volume
19 litres
Car Battery
Voltage
12 V
Battery Capacity
74 Ah
Alternator Charge Current
140 A
Alternator Voltage
14 V
Engine Configuration
Bore
88 mm (3.5 in)
Stroke
75 mm (3.0 in)
Compression Ratio
10.8 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Belt
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Timing Interval
30,000 km (18,641 mi)
Air Filter
15,000 km (9,321 mi)
Fuel Filter
30,000 km (18,641 mi)
Oil Change & Engine Filter
15,000 km (9,321 mi)
Transmission, Fluid
15,000 km / 2 years

Transmission & Drivetrain

Gear Selector
Stick
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
3.15 :1
2nd Gear
2.18 :1
3rd Gear
1.57 :1
4th Gear
1.19 :1
5th Gear
0.94 :1
6th Gear
0.76 :1
Final Drive
3.91 :1
Reverse
2.38 :1

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Double Wishbone

Fuel

General
Tank Volume
114 litres
Reserve Tank Capacity
20 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 3
Emission Control
  • Catalyst
  • Evaporative Control System
Fuel Consumption NEDC
City
35.6 - 38.2 litres / 100 km
Highway
15.5 - 16.4 litres / 100 km
Combined
22.9 - 24.4 litres / 100 km
Emission NEDC
CO₂, Combined
530 - 558 g/km

Performance

Quarter Mile
12.5 sec

Dimensions & Weight

Exterior

Track, Front
1,632 mm (64.3 in)
Track, Rear
1,586 mm (62.4 in)
Overhang, Front
1,080 mm (42.5 in)
Overhang, Rear
970 mm (38.2 in)
Turning Circle
11.6 m
Ground Clearance
135 mm (5.3 in)

Weight

Gross Weight
1,950 kg (4,299 lb)
Cargo Capacity
260 kg (573 lb)
Max Roof Load
0 kg (0 lb)

Exterior

Chassis & Body

Chassis
Chassis
Cabriolet (Open Body)
Pillars
A
Doors
Front Doors
Conventional

Equipment

Windscreen Wipers
Volume Water Tank
2 litres
Windows
Window Lifts, Front
Powered

Lights

Main Beam
Halogen
Low Beam
Halogen
Fog Lights
Yes
Fog Lights
Front
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
108
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
67.1
Fastening Type
Lug Bolts

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes
Climate Control › Air Condition
Refrigerant
R134A
Refrigerant, Capacity
760 g

Steering Wheel

Steering Mechanism
Rack and Pinion

Seats

Colour & Material
Upholstery
Leather

Trunk

Rear Trunk
Yes

Safety & Security

Brake Systems

Anti-lock Braking System (ABS)
Four-channel

Other Features

Central Locking
Yes

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Other

Car Classification

American Classification
Convertible
British Classification
Convertible
Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car

Production

Statistics
Production Number (Series)
3,531
Production Number (Generation)
3,531
Statistics › Production Number (Model)
1st Generation
448
