2002 Ferrari 575 GTZ

ItalyGasolineRWDCoupe

Photos

Specifications

Vehicle Details

Year
2002
Make
Ferrari
Model
575 GTZ
Body Style
Coupe
Generation
F133
Seats
2
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
  • Automatic Manumatic
  • Semi-automatic
  • Sequential
  • Manual, 6-speed

Powertrain

Engine Name
5.7 V12
Engine Configuration
V
Power (hp)
515 hp
Power (kW)
379 kW
Torque
589 Nm (434 lb-ft)
Top speed
325 km/h (202 mph)
0–60 mph
4.0 seconds (estimated)
0–100 km/h
4.2 seconds
Displacement
5,748 cc

Dimensions

Wheelbase
2,500 mm (98.4 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
7,250 rpm
Rev. at Max Torque
5,250 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-40
  • 5W-40
Engine Oil, Volume
10 litres
Transmission Fluid, Volume
4.5 litres
Engine Coolant, Volume
19 litres
Car Battery
Voltage
12 V
Battery Capacity
75 - 80 Ah
Alternator Charge Current
140 A
Alternator Voltage
14 V
Engine Configuration
Bore
89 mm (3.5 in)
Stroke
77 mm (3.0 in)
Compression Ratio
11 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Belt
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Timing Interval
50,000 km / 3 years
Air Filter
20,000 km (12,427 mi)
Spark Plug
30,000 km (18,641 mi)
Oil Change & Engine Filter
20,000 km (12,427 mi)
Transmission, Fluid
20,000 km / 2 years

Transmission & Drivetrain

Transmission
  • Automatic Manumatic
  • Semi-automatic
  • Sequential
  • Manual, 6-speed
Gear Selector
  • Stick
  • Joystick
  • Push Button
  • Paddles
Gear Selector Location
  • Mid-Console
  • On Steering Wheel
Gear Ratio
1st Gear
3.15 :1
2nd Gear
2.18 :1
3rd Gear
1.57 :1
4th Gear
1.19 :1
5th Gear
0.94 :1
6th Gear
0.76 :1
Final Drive
3.91 :1
Reverse
2.38 :1

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Double Wishbone

Fuel

General
Tank Volume
105 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
Fuel Consumption NEDC
City
34.5 litres / 100 km
Highway
14.3 litres / 100 km
Combined
21.8 litres / 100 km
Emission NEDC
CO₂, City
790 g/km
CO₂, Highway
329 g/km
CO₂, Combined
499 g/km

Performance

Quarter Mile
12.25 – 12.3 sec

Dimensions & Weight

Exterior

Track, Front
1,632 mm (64.3 in)
Track, Rear
1,586 mm (62.4 in)
Turning Circle
11.6 m
Ground Clearance
100 mm (3.9 in)

Weight

Max Roof Load
0 kg (0 lb)

Exterior

Chassis & Body

Chassis
Chassis
Coupé
Pillars
A-C
Doors
Front Doors
Conventional

Equipment

Windows
Window Lifts, Front
Powered
Other Equipment
Normal Roof
Yes

Lights

Main Beam
Halogen
Low Beam
Halogen
Fog Lights
Yes
Fog Lights
Front
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
108
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
67.1
Fastening Type
Lug Bolts

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes

Steering Wheel

Steering Mechanism
Rack and Pinion

Seats

Colour & Material
Upholstery
Leather

Trunk

Rear Trunk
Yes

Safety & Security

Brake Systems

Anti-lock Braking System (ABS)
Yes

Other Features

Central Locking
Yes

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Other

Car Classification

American Classification
Grand Tourer
British Classification
Grand Tourer
Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car

Production

Statistics
Production Number (Series)
2,615
Production Number (Generation)
2,615
Statistics › Production Number (Model)
1st Generation
2,056
