2002 Ford Explorer

United StatesGasoline4WDSUV

Photos

Specifications

Vehicle Details

Year
2002
Make
Ford
Model
Explorer
Body Style
SUV
Generation
3rd Generation (U152)
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
4WD
Transmission
  • Automatic
  • Manual, 5-speed

Powertrain

Engine Name
4.0 V6 SOHC ControlTrac
Engine Configuration
V
Power (hp)
213 hp
Power (kW)
157 kW
Torque
326 Nm (240 lb-ft)
Displacement
4,009 cc

Dimensions

Length
4,813 mm (189.5 in)
Width
1,874 mm (73.8 in)
Height
1,801 mm (70.9 in)
Wheelbase
2,835 mm (111.6 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,300 rpm
Rev. at Max Torque
3,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Configuration
Bore
100.3 mm (3.9 in)
Stroke
84.3 mm (3.3 in)
Compression Ratio
9.7 :1
Engine Configuration
V-Engine
Type of Combustion Engine
Piston

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 5-speed

Dimensions & Weight

Exterior

Track, Front
1,486 mm (58.5 in)
Track, Rear
1,488 mm (58.6 in)
Turning Circle
11.5 m
Ground Clearance
216 mm (8.5 in)

Weight

Max Roof Load
91 kg (201 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Ford Motor Company
U Platform (U1)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Tinted Windows
  • Front
  • Second Row
  • Rear Window
Other Equipment
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)
Colour
Black

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Central Bore (CB), front
70.3

Interior

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Split Fold Ratio
60/40
Second Seat Row › Headrests
Outer Seats
Height Adjustment

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
1,205 litres
Volume, Back Seat Collapsed
2,310 litres
Depth
1,050 mm (41.3 in)

Features

Accessories

Warning Triangle
Yes
First Aid Kit
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Front Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Airbags

Feature
Frontal Airbag
Side Head Airbag

Other

Car Classification

American Classification
Mid-Size SUV
British Classification
Large 4x4
Australian Classification
Large SUV
European Segment
J-Segment
Car.info Classification
Large SUV
