2002 Toyota RAV4

JapanGasolineFWDSUV

Photos

Specifications

Vehicle Details

Year
2002
Make
Toyota
Model
RAV4
Body Style
SUV
Generation
XA20
Seats
5
Doors
3
Fuel
Gasoline
Drivetrain
FWD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.8 VVT-i Manual
Engine Configuration
Inline
Power (hp)
125 hp
Power (kW)
92 kW
Top speed
175 km/h (109 mph)
0–60 mph
11.6 seconds (estimated)
0–100 km/h
12.2 seconds
Displacement
1,794 cc

Dimensions

Length
3,870 mm (152.4 in)
Width
1,735 mm (68.3 in)
Height
1,685 mm (66.3 in)
Wheelbase
2,280 mm (89.8 in)
Curb weight
1,095 kg (2,414 lb)

Engine & Performance

Engine

Engine Fluids
Synthetic Oil (viscosity)
  • 5W-30
  • 10W-30
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 10W-30
Engine Oil, Volume
3.7 litres
Engine Configuration
Bore
79 mm (3.1 in)
Stroke
91.5 mm (3.6 in)
Compression Ratio
10 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston
Service Intervals
Air Filter
60,000 km / 4 years
Spark Plug
60,000 km / 4 years
Brake Fluid
30,000 km / 2 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
150,000 km / 10 years

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
57 litres
Fuel Consumption NEDC
City
9.4 litres / 100 km
Highway
6.2 litres / 100 km
Combined
7.4 litres / 100 km
Emission NEDC
CO₂, Combined
175 g/km

Dimensions & Weight

Exterior

Track, Front
1,510 mm (59.4 in)
Track, Rear
1,500 mm (59.1 in)
Turning Circle
10 m
Ground Clearance
195 mm (7.7 in)

Weight

Gross Weight
1,590 kg (3,505 lb)
Max Trailer Load, braked 12%
1,000 kg (2,205 lb)
Max Trailer Load, unbraked
500 kg (1,102 lb)
Cargo Capacity
495 kg (1,091 lb)
Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Platform
Toyota Platform
MC Platform

Equipment

Side Mirrors
Mirror Type
Conventional
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Tinted Windows
  • Front
  • Second Row
  • Rear Window
Other Equipment
Sunroof
Optional
Roof Railing
Yes
Antenna
Optional
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Optional

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
60.1
Fastening Type
Lug Nuts
Tightening Torque
103 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Tachometer
Analogue
Climate Control
Climate Control
Manual
Air Condition
Yes
Pollen Filter
Yes
Connectivity
Radio
  • AM
  • FM
Media Format
CD
Rear-view Mirror
Anti-glare
Manual
Interior Storage › Storage Compartments
Glove Compartment
Lockable (Manual)
Armrest Hatch
Front
Card Holder
Yes
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
12V Outlet
Front
Carpets
Optional
Ashtray
Yes
Cigarette Lighter
Yes

Steering Wheel

Power Steering
Yes
Adjustments
Tilt
Number of Spokes
3
Colour
Black

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
150 litres

Seats

Colour & Material
Upholstery
Textile
Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Front Seats
Number of Driver Seat Adjustments, Manual
4
Number of Driver Seat Adjustments, Total
4
Number of Passenger Seat Adjustments, Manual
3
Number of Passenger Seat Adjustments, Total
3
Armrest
Middle
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Second Seat Row
Collapsible
Manual
Adjustments
Backrest Angle
Number of Seats
3
Type of Seat
Adult
Height Adjustment
Yes
Second Seat Row › Collapsible
Backrest Release
From Trunk
Split Fold Ratio
50/50

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Seat Belt Colour
Black
Belt Pretensioner
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Brake Systems

Anti-lock Braking System (ABS)
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Left
Pillar
B-Pillar, Left
Passenger Seat
  • in Front of
  • Under

Car Classification

American Classification
Compact SUV
British Classification
Compact SUV
Australian Classification
Medium SUV
European Segment
J-Segment
Car.info Classification
Medium SUV

Spare Parts BETA

Bulb Types
Low Beam
H4
Main Beam
H4
Fog Light, Front
HB4
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
W3×16q (W21/5W)
Reversing Light
BA15s (P21W)
Turn Indicators, Front
  • W3×16d (W21W)
  • WX3×16d (WY21W)
Turn Indicators, Side
W2.1×9.5d (W5W)
Turn Indicators, Rear
W3×16d (W21W)
Read Light
SV8.5 (C10W)
License Plate Light
W2.1×9.5d (W5W)
