2003 Dodge Ram

United StatesGasoline2WDLCV

Photos

Specifications

Vehicle Details

Year
2003
Make
Dodge
Model
Ram
Body Style
LCV
Generation
2nd Generation
Seats
1
Doors
4
Fuel
Gasoline
Drivetrain
2WD
Transmission
Automatic, 4-speed

Powertrain

Engine Name
5.9 V8 EFI TorqueFlite
Engine Configuration
V
Power (hp)
249 hp
Power (kW)
183 kW
Displacement
5,898 cc

Dimensions

Width
2,002 mm (78.8 in)

Engine & Performance

Engine

Engine Configuration
Engine Configuration
V-Engine

Transmission & Drivetrain

Transmission
Automatic, 4-speed

Fuel

General › Fuel Cap Position
Rear
Left

Brakes

Parking Brake
Manual
Pedal
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Leaf (Longitudinal Spring)
Anti-roll Bar
Front
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Dependent
Beam Axle (Dead Axle)

Dimensions & Weight

Exterior

Ground Clearance
188 - 231 mm (7.4 - 9.1 in)

Interior

Head Room, Front
991 mm (39.0 in)
Leg Room, Front
991 mm (39.0 in)
Shoulder Room, Front
1,727 mm (68.0 in)

LCV Specific

General
Version
  • L2H1
  • L3H1
Dimensions › Length
L2
5,296 mm (208.5 in)
L3
5,956 mm (234.5 in)
Dimensions › Height
L2H1
2,070 mm (81.5 in)
L3H1
2,070 mm (81.5 in)
Dimensions › Wheel Base
L2
3,231 mm (127.2 in)
L3
3,231 mm (127.2 in)
Dimensions › Turning Circle
L2
14.11 m
L3
14.11 m
Side Door › Side Door Height
H1
1,252 mm (49.3 in)
Side Door › Side Door Width
L2
1,199 mm (47.2 in)
L3
1,199 mm (47.2 in)
Rear Doors › Rear Doors Height
L2H1
1,252
Rear Doors
Rear Doors Width
1,199 mm (47.2 in)
Cargo Space › Cargo Volume
L1H2
6,765 litres
L1H3
8,342 litres
Cargo Space › Depth
L2
3,495 mm (137.6 in)
L3
4,155 mm (163.6 in)
Cargo Space › Height
H1
1,351 mm (53.2 in)
Cargo Space
Space Width
1,834 mm (72.2 in)
Cargo Space › Space Width, Between Wheel Arches
L2
1,270 mm (50.0 in)
L3
1,270 mm (50.0 in)
Weight › Gross Weight
L2H1
3,538 kg (7,800 lb)
L3H1
3,538 kg (7,800 lb)

Exterior

Chassis & Body

Chassis
Chassis
LCV (Panel Van)
Pillars
  • A-D
  • A-D + Extra Pillar(s)
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
  • Sliding Right
  • Dual Swing-out
Door Handles
Button
Platform
Chrysler Platforms
B Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Folding
Manual
House Colour
Black
Windscreen Wipers
Number of Wiper Speeds
2
Integrated Water Nozzles in Wipers
Yes
Intermittent Control
Yes
Windows
Heated Windows
Optional
Heat-Insulating Windows
  • Front
  • First Row
Windows › Heated Windows
Rear
Optional
Other Equipment
Antenna
Whip
Number of Exhaust Pipes
1

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen

Colour

Door Handles
Non-painted

Rims & Tires

Fastening Type
Lug Nuts
Rim Material
Steel
Rim Type
Disc Wheel
Spare Wheel
Full-size (Steel)

Interior

Equipment

Instrument Cluster
Speedometer
Analogue
Fuel Gauge
Analogue
Voltmeter
Analogue
Oil Pressure
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Air Condition
Optional
Number of Vents, Front
5 pcs
Controls
Rotary Dials
Climate Control › Air Condition
Refrigerant
R134A
Refrigerant, Capacity
964 g
Connectivity
Radio
  • AM
  • FM
  • RDS
Connectivity › Media Format
CD
Optional
Cassette
Optional
Displays
Equalizer
Optional
Speakers
Total Number of Speakers
2 pcs
Interior Storage › Storage Compartments
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
3
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Optional
Lights › Read Light
Front
Optional
Other Equipment
Clock
Yes
12V Outlet
Front
Carpets
Optional
Ashtray
Front (Retractable)
Cigarette Lighter
Yes
Other Equipment › Clock
Digital
Dashboard

Steering Wheel

Multifunction Steering Wheel
Optional
Power Steering
Hydraulic
Adjustments
Tilt
Number of Spokes
4
Material
Plastic
Colour
Black
Multifunction Steering Wheel
Number of Buttons
5 pcs

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Optional
Backrest Angle
Manual
Front Seats
Number of Driver Seat Adjustments, Manual
4
Number of Driver Seat Adjustments, Powered
6
Number of Driver Seat Adjustments, Total
4 - 6
Number of Passenger Seat Adjustments, Manual
4
Number of Passenger Seat Adjustments, Powered
6
Number of Passenger Seat Adjustments, Total
4 - 6
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Armrest
  • Driver
  • Passenger
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Optional
Backrest Angle
Manual

Trunk

Release Button
Yes
Hatch Opening Type
Two-parted Doors

Design

Interior Decor Material
Plastic
Transmission Knob Material
Plastic
Entry Guard Material
Plastic

Features

Comfort Features

Keyless Entry
Optional
Cruise Control
Optional
Parking Heater
Optional
Parking Heater
Engine Heater
Optional

Accessories

Tool Kit and Jack
Yes
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Front Seats
Feature
Belt Pretensioner
Belt Load Limiter

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Optional
Reversing Alarm
Optional

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Other

Identification

VIN Location
Left Side Casing of Window
Yes
On-board Diagnostic, Port Location
Steering Wheel, Lower Left

Car Classification

American Classification
Cargo Van
British Classification
Minibus
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Cargo Van
