2003 Ferrari 575 GTC

ItalyGasolineRWDRace Car

Photos

Specifications

Vehicle Details

Year
2003
Make
Ferrari
Model
575 GTC
Body Style
Race Car
Generation
F133
Seats
2
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic (Sequential), 6-speed

Powertrain

Engine Name
6.0 V12 Sequential
Engine Configuration
V
Power (hp)
605 hp
Power (kW)
445 kW
Torque
730 Nm (538 lb-ft)
Displacement
5,997 cc

Dimensions

Length
4,590 mm (180.7 in)
Width
2,035 mm (80.1 in)
Height
1,170 mm (46.1 in)
Wheelbase
2,500 mm (98.4 in)
Curb weight
1,150 kg (2,535 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,300 rpm
Rev. at Max Torque
5,200 rpm
Engine Configuration
Bore
90 mm (3.5 in)
Stroke
78.56 mm (3.1 in)
Compression Ratio
12.9 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Belt
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Fuel

General
Tank Volume
100 litres

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Double Wishbone

Dimensions & Weight

Exterior

Track, Front
1,706 mm (67.2 in)
Track, Rear
1,682 mm (66.2 in)

Exterior

Chassis & Body

Chassis
Chassis
Coupé
