2003 Suzuki Ignis

JapanGasolineFWDHatchback

Photos

Specifications

Vehicle Details

Year
2003
Make
Suzuki
Model
Ignis
Body Style
Hatchback
Generation
MH
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.3 DOHC 16V VVT Manual
Engine Configuration
Inline
Power (hp)
94 hp
Power (kW)
69 kW
Torque
118 Nm (87 lb-ft)
Top speed
160 km/h (99 mph)
Displacement
1,328 cc

Dimensions

Length
3,890 mm (153.1 in)
Width
1,630 mm (64.2 in)
Height
1,605 mm (63.2 in)
Wheelbase
2,360 mm (92.9 in)
Curb weight
930 kg (2,050 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
4,100 rpm
Engine Fluids
Synthetic Oil (viscosity)
Yes
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
  • 10W-50
  • 15W-40
  • 20W-50
Engine Oil, Volume
3.8 litres
Engine Configuration
Bore
78 mm (3.1 in)
Stroke
69.5 mm (2.7 in)
Compression Ratio
9.5 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston
Service Intervals
Spark Plug
105,000 km (65,244 mi)
Oil Change & Engine Filter
15,000 km / 1 years

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut

Fuel

General
Tank Volume
41 litres
Emission
Emission Standard
Euro 4
Fuel Consumption NEDC
City
8.3 litres / 100 km
Highway
5.5 litres / 100 km
Combined
6.5 litres / 100 km
Emission NEDC
CO₂, Combined
154 g/km

Dimensions & Weight

Exterior

Track, Front
1,420 mm (55.9 in)
Track, Rear
1,410 mm (55.5 in)
Turning Circle
10 m
Ground Clearance
170 mm (6.7 in)

Interior

Head Room, Front
985 mm (38.8 in)

Weight

Gross Weight
1,470 kg (3,241 lb)
Max Trailer Load, braked 12%
800 kg (1,764 lb)
Max Trailer Load, unbraked
350 kg (772 lb)
Cargo Capacity
540 kg (1,190 lb)
Max Roof Load
50 kg (110 lb)
Max Towbar Download
50 kg (110 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-D
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Rear
Manual
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Roof Railing
Yes
Spoiler
Optional
Antenna
Optional
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)
Colour
Black
Other Equipment › Spoiler
Fixed
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
54.1
Fastening Type
Lug Bolts
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Climate Control
Air Condition
Optional
Number of Vents, Front
4 pcs
Connectivity
Radio
Optional
Connectivity › Radio
CD
Optional
Displays
Center Display
Optional
Interior Storage › Storage Compartments
Glove Compartment
Yes
Lights
Read Light
Front
Other Equipment
Clock
Optional
12V Outlet
Front
Carpets
Yes
Cigarette Lighter
Yes
Other Equipment › Clock
Digital
Optional

Steering Wheel

Colour
Grey

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
236 litres
Depth
520 mm (20.5 in)
Depth, Back Seat Collapsed
1,130 mm (44.5 in)

Design

Interior Decor Material
Plastic
Interior Decor Colour
Grey
Transmission Knob Material
Plastic

Seats

Colour & Material
Upholstery
Textile
Seat Colour
Grey
Stitching Colour
Grey
Front Seats › Adjustments, Driver
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Second Seat Row
Collapsible
Yes
Number of Seats
3
Type of Seat
Adult

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black

Brake Systems

Anti-lock Braking System (ABS)
Yes

Other Features

Central Locking
Optional

Airbags

Feature
Frontal Airbag
Side Chest Airbag

Other

Identification

VIN Location
Engine Compartment, Bulkhead
  • Centre
  • Right
Left Side Casing of Window
Yes
Longerun Frame
Behind Right Rear Wheel

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
Supermini
Australian Classification
Light Car
European Segment
B-Segment
Car.info Classification
Small Family Car
