2005 Mercedes-Benz CLS

GermanyGasolineRWDCoupe

Photos

Specifications

Vehicle Details

Year
2005
Make
Mercedes-Benz
Model
CLS
Body Style
Coupe
Generation
C219
Seats
4
Doors
4
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic

Powertrain

Engine Name
500 7G-Tronic
Engine Configuration
V
Power (hp)
306 hp
Power (kW)
225 kW
Torque
460 Nm (339 lb-ft)
Top speed
250 km/h (155 mph)
0–60 mph
5.8 seconds (estimated)
0–100 km/h
6.1 seconds
Displacement
4,966 cc

Dimensions

Length
4,910 mm (193.3 in)
Width
1,851 mm (72.9 in)
Height
1,403 mm (55.2 in)
Wheelbase
2,854 mm (112.4 in)
Curb weight
1,710 kg (3,770 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Torque
2,700 - 4,250 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
Engine Oil, Volume
8 litres
Engine Configuration
Bore
97 mm (3.8 in)
Stroke
84 mm (3.3 in)
Compression Ratio
10 :1
Engine Configuration
V-Engine
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Service Intervals
Air Filter
80,000 km / 4 years
Fuel Filter
250,000 km / 15 years
Spark Plug
100,000 km / 4 years
Brake Fluid
30,000 km / 2 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
250,000 km / 15 years
Interior Filter
30,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
Yes

Fuel

General
Tank Volume
80 litres
Emission
Emission Standard
Euro 4
Fuel Consumption NEDC
City
16.4 litres / 100 km
Highway
8.3 litres / 100 km
Combined
11.6 litres / 100 km
Emission NEDC
CO₂, Combined
268 g/km

Dimensions & Weight

Exterior

Track, Front
1,593 mm (62.7 in)
Track, Rear
1,603 mm (63.1 in)
Turning Circle
11.2 m
Ground Clearance
103 mm (4.1 in)

Interior

Head Room, Front
960 mm (37.8 in)

Weight

Gross Weight
2,275 kg (5,016 lb)
Cargo Capacity
565 kg (1,246 lb)
Max Roof Load
100 kg (220 lb)

Exterior

Chassis & Body

Chassis
Chassis
Coupé

Equipment

Side Mirrors
Turning Signal
Yes
Windscreen Wipers
Windscreen Wipers: Connector type, Front
Side Lock
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Tinted Windows
  • Second Row
  • Rear Window
Other Equipment
Sunroof
Optional
Tow Hook
  • Front
  • Rear
Normal Roof
Yes

Lights

Main Beam
Xenon
Low Beam
Xenon
Fog Lights
Yes
Fog Lights
Front
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
112
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
66.6
Fastening Type
Lug Bolts
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
Media Format
MP3
Bluetooth
Yes
Connectivity › Media Format
CD
Yes
DVD
Optional
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Yes
Interior Storage › Storage Compartments
Glove Compartment
Lockable
Armrest Hatch
  • Front
  • Back
Under Seats
Front
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Lights
Read Light
Front
Guide Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Analogue
12V Outlet
Front
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Sport
Yes
Material
Leather
Steering Mechanism
Rack and Pinion
Channels
Yes
Volume
Yes
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
505 litres

Seats

Colour & Material
Upholstery
Leather
Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Headrest, Tilt
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Headrest, Tilt
Yes
Front Seats
Power Seat, Driver
Yes
Power Seat, Passenger
Yes
Heated Seats
Yes
Armrest
Middle
Second Seat Row
Armrest
Yes
Collapsible
Manual
Type of Seat
Adult
Second Seat Row › Headrests
Outer Seats
Height Adjustment

Features

Comfort Features

Keyless Start
Optional
Cruise Control
Yes
Speed Limiter
Yes

Other Features

GPS
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Rain Sensors
Yes
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Curtain Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Optional

Other

Identification

VIN Location
Pillar
B-Pillar, Right
Passenger Seat
in Front of

Car Classification

American Classification
Mid-Size Luxury Car
British Classification
Executive Car
Australian Classification
Large Car
European Segment
E-Segment
Car.info Classification
Executive Car

Spare Parts BETA

Bulb Types
Low Beam
  • D2S (xenon)
  • H7
Main Beam
H7
Bi-Xenon
D2S
Fog Light, Front
  • H3
  • H11
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Turn Indicators, Front
BAU15s (PY21W)
Read Light
SV8.5 (C10W)
Trunk
SV8.5 (C5W)
License Plate Light
SV8.5 (C5W)
