2006 Chrysler 300C SRT-8

United StatesGasolineRWDWagon

Photos

Specifications

Vehicle Details

Year
2006
Make
Chrysler
Model
300C
Variant
SRT-8
Body Style
Wagon
Generation
1st Generation
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic, 5-speed

Powertrain

Engine Name
SRT-8 Touring Automatic
Engine Configuration
V
Power (hp)
431 hp
Power (kW)
317 kW
Torque
569 Nm (420 lb-ft)
Top speed
265 km/h (165 mph)
0–60 mph
5 seconds
0–100 km/h
5.2 seconds
Displacement
6,063 cc

Dimensions

Length
5,015 mm (197.4 in)
Width
1,881 mm (74.1 in)
Height
1,481 mm (58.3 in)
Wheelbase
3,050 mm (120.1 in)
Curb weight
1,935 kg (4,266 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
4,600 rpm
Engine Fluids
Synthetic Oil (viscosity)
0W-40
Engine Oil, Volume
6.6 litres
Engine Configuration
Bore
103 mm (4.1 in)
Stroke
90.9 mm (3.6 in)
Compression Ratio
10.3 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
Cam-in-block (Pushrod)
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Spark Plug
96,000 km (59,652 mi)
Brake Fluid
2 years

Transmission & Drivetrain

Transmission
Automatic, 5-speed

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
68 - 71 litres
Fuel Consumption NEDC
City
21 litres / 100 km
Highway
9.9 litres / 100 km
Combined
14 litres / 100 km
Emission NEDC
CO₂, Combined
330 g/km

Dimensions & Weight

Exterior

Track, Front
1,600 mm (63.0 in)
Track, Rear
1,605 mm (63.2 in)
Turning Circle
11.9 m
Ground Clearance
144 mm (5.7 in)

Interior

Head Room, Front
946 mm (37.2 in)
Head Room, Rear
966 mm (38.0 in)
Leg Room, Front
1,024 mm (40.3 in)
Leg Room, Rear
1,020 mm (40.2 in)
Hip Room, Front
1,420 mm (55.9 in)
Hip Room, Rear
1,420 mm (55.9 in)
Shoulder Room, Front
1,510 mm (59.4 in)
Shoulder Room, Rear
1,466 mm (57.7 in)

Weight

Gross Weight
2,410 kg (5,313 lb)
Max Trailer Load, braked 12%
1,725 kg (3,803 lb)
Max Trailer Load, unbraked
450 kg (992 lb)
Cargo Capacity
475 kg (1,047 lb)
Max Roof Load
68 kg (150 lb)
Max Towbar Download
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon
Pillars
A-D
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Chrysler Platforms
LX Platform (LX)

Equipment

Side Mirrors
Mirror Type
Conventional
Folding
Electrical
Heated
Yes
Windscreen Wipers
Rear Wiper
Yes
Windscreen Wipers: Connector type, Front
Hook
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Roof Railing
Optional
Antenna
Optional

Lights

Main Beam
Xenon
Low Beam
Xenon
Rear Lights
Halogen
Fog Lights
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
115
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
71.6
Fastening Type
Lug Nuts
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
Media Format
MP3
Connectivity › Media Format
CD
Multiple CD Changer
DVD
Optional
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Optional
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Lights
Read Light
Front
Other Equipment
Clock
Analogue
Carpets
Optional

Steering Wheel

Power Steering
Yes

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Rear Trunk
Volume
630 litres
Volume, Back Seat Collapsed
1,602 litres

Design

Entry Guard Material
Aluminium

Seats

Colour & Material
Upholstery
Leather
Front Seats › Adjustments, Driver
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats
Power Seat, Driver
Yes
Type of Seat
Sport Seats
Second Seat Row
Armrest
Yes
Collapsible
Yes
Number of Seats
3
Type of Seat
Adult

Features

Comfort Features

Cruise Control
Yes

Other Features

GPS
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Centre Rear Seat
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear
Rain Sensors
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Left Side Casing of Window
Yes

Car Classification

American Classification
Mid-Size Luxury Car
British Classification
Executive Car
Australian Classification
Large Car
European Segment
E-Segment
Car.info Classification
Executive Car

Awards

North American
Car of the Year
2005
Motor Trend
Car of the Year
2005
