2006 Dodge Caliber

United StatesDieselFWDHatchback

Photos

Specifications

Vehicle Details

Year
2006
Make
Dodge
Model
Caliber
Body Style
Hatchback
Generation
1st Generation
Seats
5
Doors
5
Fuel
Diesel
Drivetrain
FWD
Transmission
Manual, 6-speed

Powertrain

Engine Name
2.0 TDI Manual
Engine Configuration
Inline
Power (hp)
140 hp
Power (kW)
103 kW
Torque
310 Nm (229 lb-ft)
Top speed
196 km/h (122 mph)
0–60 mph
8.9 seconds (estimated)
0–100 km/h
9.3 seconds
Displacement
1,968 cc

Dimensions

Length
4,415 mm (173.8 in)
Width
1,800 mm (70.9 in)
Height
1,535 mm (60.4 in)
Wheelbase
2,635 mm (103.7 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
4,000 rpm
Rev. at Max Torque
1,750 - 2,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-40
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
  • 15W-40
Engine Oil, Volume
4.3 litres
Engine Configuration
Bore
81 mm (3.2 in)
Stroke
95.5 mm (3.8 in)
Compression Ratio
18 :1
Engine Configuration
Inline
Turbocharger
Yes
Synchronization
Timing Belt
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Engine Cooling
Liquid Cooling
Service Intervals
Timing Interval
120,000 km (74,565 mi)
Air Filter
30,000 km (18,641 mi)
Fuel Filter
45,000 km (27,962 mi)
Brake Fluid
2 years
Oil Change & Engine Filter
10,000 km / 0.5 years
Interior Filter
15,000 km (9,321 mi)

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes

Suspensions

Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General › Fuel Cap Position
Rear
Left
Fuel Consumption NEDC
City
7.9 litres / 100 km
Highway
5 litres / 100 km
Combined
6.1 litres / 100 km
Emission NEDC
CO₂, Combined
163 g/km

Dimensions & Weight

Exterior

Track, Front
1,520 mm (59.8 in)
Track, Rear
1,520 mm (59.8 in)
Turning Circle
10.8 m
Ground Clearance
167 - 206 mm (6.6 - 8.1 in)

Interior

Head Room, Front
970 mm (38.2 in)

Weight

Max Roof Load
68 kg (150 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-D
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Folding
Electrical
House Colour
Black
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Spoiler
Fixed
Antenna
Roof-integrated
Electric
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Fog Lights
Optional

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Fastening Type
Lug Nuts
Rim Colour
Silver

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Climate Control
Manual
Air Condition
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
Media Format
MP3
Connectivity › Media Format
CD
Yes
DVD
Optional
Connectivity › Media Inputs
AUX
Yes
USB
Optional
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Yes
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
2
Lights
Read Light
Front
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
12V Outlet
Front
Carpets
Optional

Steering Wheel

Multifunction Steering Wheel
Optional
Power Steering
Yes
Adjustments
Tilt
Number of Spokes
4
Colour
Black
Steering Mechanism
Rack and Pinion
Volume
Optional

Trunk

Rear Trunk
Yes
Carpet
Optional
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
524 litres
Volume, Back Seat Collapsed
1,339 litres
Carpet
Rubber
Optional

Design

Colour
Silver

Seats

Front Seats › Adjustments, Driver
Seat Height
Yes
Front Seats
Heated Seats
Optional
Armrest
Middle
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40

Features

Comfort Features

Keyless Entry
Optional
Cruise Control
Optional

Other Features

GPS
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes
Child Safety Locks
Yes

Safety Testing

General
Test Year
2007
Adult Occupant
4/5 stars
Child Occupant
4/5 stars
Pedestrian
1/4 stars
Test Year
2007
Overall Score
29.14
ANCAP Safety Rating
4
Adult Occupant
Frontal Offset
11.14
Side Impact
16
Pole
2
Whiplash Protection (Assessment)
Not Assessed
Pedestrian
Protection (Assessment)
Poor
Safety Assist
Seat Belt Reminders
0
IIHS
Test Year
2007
Moderate Overlap Front
Good
Side
Marginal
Roof Strength
Acceptable
Head Restraints & Seats
Good

Airbags

Feature
Frontal Airbag
Side Head Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Passenger Seat
Under
On-board Diagnostic, Port Type
OBD-II

Car Classification

American Classification
Compact Car
British Classification
Small Family Car
Australian Classification
Small Car
European Segment
C-Segment
Car.info Classification
Medium Family Car
