TransmissionAutomatic (Electrohydraulic), 5-speed Diesel OilYesEngine Oil, Volume9 litres Engine Coolant, Volume10 litres Engine Fluids › Engine Coolant
- OAT
- BASF Glysantin G05
- Mopar OEM Coolant (red)
- HOAT
- Comma/Glysantin G48 (blue/green)
- Valvoline Zerex G-05
- Valvoline Zerex G-48
Car Battery
- Voltage
- 12 V
- Battery Capacity
- 100 Ah
- Secondary Battery
- Optional
- Alternator Charge Current
- 90 - 200 A
- Alternator Voltage
- 14 V
Engine Configuration
- Bore
- 88 mm (3.5 in)
- Stroke
- 88.3 mm (3.5 in)
- Compression Ratio
- 18 :1
- Engine Configuration
- Inline
- Turbocharger
- Yes
- Synchronization
- Timing Chain
- Engine Placement
- Front
- Engine Mount
- Longitudinally
- Type of Combustion Engine
Service Intervals
- Air Filter
- 3 years
- Fuel Filter
- 15,000 km (9,321 mi)
- Brake Fluid
- 2 years
- Oil Change & Engine Filter
- 16,000 km / 1 years
- Engine Coolant
- 256,000 km / 15 years
- Transmission, Fluid
- 128,000 km (79,536 mi)
- Transmission, Fluid Filter
- 128,000 km (79,536 mi)
- Rear Axle, Oil
- 192,000 km (119,303 mi)
Fuel SystemElectronic (Direct) Fuel Injection Engine CoolingLiquid Cooling 1 :1
Front Brakes
- Diameter
- 276 mm (10.9 in)
- Width
- 22 mm (0.9 in)
- Cooling
- Ventilated
Rear Brakes
- Diameter
- 272 mm (10.7 in)
- Width
- 14 mm (0.6 in)
Front22 - 25 mm (0.9 - 1.0 in) Rear22 - 25 mm (0.9 - 1.0 in) Head Room, Front1,194 mm (47.0 in)Head Room, Third Row963 mm (37.9 in) Hip Room, Front1,651 mm (65.0 in) Shoulder Room, Front1,727 mm (68.0 in) Conventional
Rear DoorsSliding (Right) Instrument Cluster › Trip Computer › Display
- Type
- Monochrome
- Shape
- Square
Climate Control
- Number of Climate Zones
- 1
- Air Condition
- Yes
- Micro Filter
- Yes
- Outside Temperature Indicator
- Yes
- Number of Vents, Front
- 6 pcs
- Controls
- Rotary Dials
Climate Control › Air Condition
Connectivity
- Media Format
- Cassette
- Phone Preparation
- Optional
Connectivity › Media Format
Speakers
- Total Number of Speakers
- 2 pcs
Interior Storage › Storage Compartments
- Glove Compartment
- Yes
- Under Seats
- Front
- Door
- Driver Side
- Passenger Side
- Total Number of Compartments
- 6 pcs
Interior Storage › Storage Compartments › Glove Compartment
Interior Storage › Cup Holders
Interior Storage › Cup Holders › Front
Other Equipment
- Clock
- Yes
- 12V Outlet
- Front
- Carpets
- Yes
- Ashtray
- Front
- Cigarette Lighter
- Yes
Other Equipment › Clock
- Digital
- Instrument Cluster
Other Equipment › Carpets
- Material
- Rubber
- Colour
- Black
Yes
Height Adjustable Retractor
Type of Belt
- Three-Point-Belt
- Front Seats
On-board Diagnostic, Port LocationSteering Wheel, Lower Left 2,365 mm (93.1 in)Dimensions › Wheel Base
- L1
- 2,997 mm (118.0 in)
- L2
- 3,556 mm (140.0 in)
- L3
- 4,013 mm (158.0 in)
Dimensions › Overhang, Rear
- L1
- 1,064 mm (41.9 in)
- L2
- 1,225 mm (48.2 in)
- L3
- 1,715 mm (67.5 in)
Dimensions › Turning Circle
- L1
- 11.14 m
- L2
- 13.6 m
- L3
- 15.1 m
Side Door › Side Door Height
- H1
- 1,520 mm (59.8 in)
- H2
- 1,520 mm (59.8 in)
Side Door › Side Door Width
- L1
- 1,045 mm (41.1 in)
- L2
- 1,045 mm (41.1 in)
- L3
- 1,045 mm (41.1 in)
Side Door › Ground to Door Height
- L1H1
- 655 mm (25.8 in)
- L1H2
- 650 mm (25.6 in)
- L2H1
- 655 mm (25.8 in)
- L2H2
- 650 mm (25.6 in)
- L3H2
- 650 mm (25.6 in)
Rear Doors › Rear Doors Height
Rear Doors
- Rear Doors Width
- 1,560 mm (61.4 in)
Rear Doors › Sill Height
- L1H1
- 655 mm (25.8 in)
- L1H2
- 650 mm (25.6 in)
- L2H1
- 655 mm (25.8 in)
- L2H2
- 650 mm (25.6 in)
- L3H2
- 650 mm (25.6 in)
Cargo Space › Cargo Volume
- L1H1
- 2,380 litres
- L1H2
- 2,380 litres
- L2H1
- 3,680 litres
- L2H2
- 3,680 litres
- L3H2
- 5,350 litres
Cargo Space › Depth
- L1
- 1,618 mm (63.7 in)
- L2
- 2,369 mm (93.3 in)
- L3
- 3,329 mm (131.1 in)
Cargo Space › Height
- H1
- 1,631 mm (64.2 in)
- H2
- 1,854 mm (73.0 in)
Cargo Space
- Space Width
- 1,735 mm (68.3 in)
Cargo Space › Space Width, Between Wheel Arches
- L1
- 1,270 mm (50.0 in)
- L2
- 1,270 mm (50.0 in)
- L3
- 1,270 mm (50.0 in)
Weight
- Curb Weight
- 2087
- 2108
- 2238
- 2263
- 2378 kg (5,243 lb)
Weight › Cargo Capacity
- L1H1
- 1,792 kg (3,951 lb)
- L1H2
- 1,770 kg (3,902 lb)
- L2H1
- 1,640 kg (3,616 lb)
- L2H2
- 1,615 kg (3,560 lb)
- L3H2
- 1,500 kg (3,307 lb)
Weight › Max Roof Load
- H1
- 300 kg (661 lb)
- H2
- 150 kg (331 lb)
Optional
Windows › Heated Windows
- Front
- Optional
- Rear
- Optional
Windows › Tinted Windows
- Second Row
- Optional
- Rear Window
- Optional
Other Equipment
- Sunroof
- Optional
- Tow Hook
- Front
- Roof Railing
- Optional
- Antenna
- Whip
- Air Intakes
- 1-port
- Number of Exhaust Pipes
- 1
- Side Steps
- Optional
Other Equipment › Sunroof
Other Equipment › Tow Hook
Other Equipment › Side Steps
Number of Driver Seat Adjustments, Total6 - 10 Number of Passenger Seat Adjustments, Manual6 - 10 Number of Passenger Seat Adjustments, Total6 - 10 Dual Passenger SeatOptional Front Seats › Adjustments, Passenger
- Seat Depth
- Manual
- Seat Height
- Manual
- Cushion Edge
- Optional
- Backrest Angle
- Manual
- Lumbar Support
- Optional
- Headrest, Height
- Manual
Front Seats › Heated Seats
- Cushion
- Optional
- Number of Heat Levels
- 2
Front Seats › Heated Seats › Cushion
Colour & Material
- Upholstery
- Textile
- Seat Colour
- Grey
LCVVariantSprinter Standard2003–2009 Powertrain2.7 CDI Automatic Drivetrain
RWD Fuel
Diesel Transmission
Automatic (Electrohydraulic), 5-speed
