2006 Mazda 5

JapanGasolineFWDMinivan

Photos

Specifications

Vehicle Details

Year
2006
Make
Mazda
Model
5
Body Style
Minivan
Generation
CR
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic
  • Manual, 4
  • 5-speed

Powertrain

Engine Name
2.3 MZR
Engine Configuration
Inline
Power (hp)
159 hp
Power (kW)
117 kW

Dimensions

Length
4,505 mm (177.4 in)
Width
1,755 mm (69.1 in)
Height
1,665 mm (65.6 in)
Wheelbase
2,750 mm (108.3 in)

Engine & Performance

Engine

Engine Fluids
Synthetic Oil (viscosity)
  • 5W-20
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Configuration
Engine Configuration
Inline
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 4
  • 5-speed

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Dimensions & Weight

Exterior

Track, Front
1,530 mm (60.2 in)
Track, Rear
1,520 mm (59.8 in)
Turning Circle
10.6 m
Ground Clearance
140 mm (5.5 in)

Interior

Head Room, Front
1,030 mm (40.6 in)
Head Room, Rear
1,000 mm (39.4 in)
Head Room, Third Row
940 mm (37.0 in)
Leg Room, Front
1,030 mm (40.6 in)
Leg Room, Rear
895 mm (35.2 in)
Leg Room, Third Row
780 mm (30.7 in)
Shoulder Room, Front
1,410 mm (55.5 in)
Shoulder Room, Rear
1,412 mm (55.6 in)
Shoulder Room, Third Row
1,250 mm (49.2 in)

Weight

Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
MPV
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Sliding (Left | Right)
Platform
Mazda Platforms
BK

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Roof Railing
Yes
Antenna
Optional
Number of Exhaust Pipes
1
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)
Colour
Black

Lights

Main Beam
Xenon
Low Beam
Xenon
Fog Lights
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Fastening Type
Lug Nuts
Tightening Torque
117 - 89 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Oil Pressure
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Climate Control
Automatic
Air Condition
Yes
Outside Temperature Indicator
Yes
Number of Vents, Front
4 pcs
Connectivity
Radio
  • AM
  • FM
Media Format
CD
Displays
Center Display
Optional
Rear-view Mirror
Anti-glare
Manual
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Back Pocket
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Guide Light
Yes
Other Equipment
Make-up Mirror
Passenger Side
Clock
Yes
Carpets
Optional
Other Equipment › Clock
Digital
Center Display

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electro-hydraulic
Number of Spokes
3
Material
Plastic
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Channels
Yes
Volume
Buttons
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
538 litres
Volume, Back Seat Collapsed
1,615 litres

Design

Interior Decor Material
Plastic
Transmission Knob Material
Plastic
Colour
Black

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Yes
Front Seats
Heated Seats
Optional
Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Third/Fourth Seat Row
Third Seat Row
Optional
Colour & Material
Upholstery
Textile
Seat Colour
Black
Stitching Colour
Black

Features

Comfort Features

Cruise Control
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes

Safety Testing

General
Test Year
2005
Adult Occupant
5/5 stars
Child Occupant
3/5 stars
Pedestrian
2/4 stars

Airbags

Frontal Airbag
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Pillar
B-Pillar, Right

Car Classification

American Classification
MPV
British Classification
Compact MPV
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Medium MPV

Spare Parts BETA

Bulb Types
Low Beam
H7
Main Beam
HB3
Fog Light, Front
H11
Rear/Brake Light
W3×16q (W21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Rear
WX3×16d (WY21W)
Read Light
W2.1×9.5d (W5W)
License Plate Light
W2.1×9.5d (W5W)
