2006 Mercedes-Benz B-Class

GermanyGasolineFWDHatchback

Photos

Specifications

Vehicle Details

Year
2006
Make
Mercedes-Benz
Model
B-Class
Body Style
Hatchback
Generation
W245
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic Continuously variable
  • Manual, 5-speed

Powertrain

Engine Name
B 150
Engine Configuration
Inline
Power (hp)
95 hp
Power (kW)
70 kW
Torque
140 Nm (103 lb-ft)
Top speed
168 km/h (104 mph)
0–60 mph
12.6 seconds (estimated)
0–100 km/h
13.2 seconds
Displacement
1,498 cc

Dimensions

Length
4,270 mm (168.1 in)
Width
1,777 mm (70.0 in)
Height
1,604 mm (63.1 in)
Wheelbase
2,778 mm (109.4 in)
Curb weight
1,200 kg (2,646 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,200 rpm
Rev. at Max Torque
3,500 - 4,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
Engine Oil, Volume
5 litres
Engine Configuration
Bore
83 mm (3.3 in)
Stroke
69.2 mm (2.7 in)
Compression Ratio
11 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Service Intervals
Air Filter
80,000 km / 4 years
Fuel Filter
250,000 km / 15 years
Spark Plug
70,000 km / 4 years
Brake Fluid
2 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
250,000 km / 15 years
Interior Filter
40,000 km / 2 years

Transmission & Drivetrain

Transmission
  • Automatic Continuously variable
  • Manual, 5-speed

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
Yes

Fuel

General
Tank Volume
54 litres
Emission
Emission Standard
Euro 4
Fuel Consumption NEDC
City
8.3 – 8.5 litres / 100 km
Highway
5.6 – 6 litres / 100 km
Combined
6.6 – 6.8 litres / 100 km
Emission NEDC
CO₂, Combined
158 – 163 g/km

Dimensions & Weight

Exterior

Track, Front
1,552 mm (61.1 in)
Track, Rear
1,547 mm (60.9 in)
Turning Circle
12 m
Ground Clearance
119 - 140 mm (4.7 - 5.5 in)

Interior

Head Room, Front
1,030 mm (40.6 in)

Weight

Gross Weight
1,835 kg (4,045 lb)
Max Trailer Load, braked 12%
1,000 kg (2,205 lb)
Max Trailer Load, unbraked
400 kg (882 lb)
Cargo Capacity
585 – 635 kg (1,290 – 1,400 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out

Equipment

Side Mirrors
Mirror Type
Conventional
Turning Signal
Yes
Windscreen Wipers
Windscreen Wipers: Connector type, Front
Pinch Tab
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Yes
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Sunroof
Optional
Tow Hook
  • Front
  • Rear
Normal Roof
Yes

Lights

Rear Lights
Halogen
Daytime Running Light
Halogen
Fog Lights
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
112
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
66.6
Fastening Type
Lug Bolts
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Tachometer
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
Optional
Bluetooth
Optional
Connectivity › Media Format
CD
Optional
DVD
Optional
Memory Card Reader
Optional
MP3
Optional
WMA
Optional
Connectivity › Media Inputs
AUX
Optional
USB
Optional
Displays
Center Display
Optional
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
1
Interior Storage › Cup Holders › Front
Placement
Middle Console
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side

Steering Wheel

Multifunction Steering Wheel
Yes
Sport
Optional
Number of Spokes
4
Colour
Black

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
458 litres
Volume, Back Seat Collapsed
1,530 litres

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Armrest
Middle
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Headrests
Outer Seats
Height Adjustment

Features

Comfort Features

Cruise Control
Optional

Other Features

GPS
Optional

Accessories

Warning Triangle
Yes
First Aid Kit
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Yes

Safety Testing

General
Test Year
2006
Adult Occupant
5/5 stars
Child Occupant
4/5 stars
Pedestrian
2/4 stars
Overall Score
33.57
ANCAP Safety Rating
5
Adult Occupant
Frontal Offset
12.57
Side Impact
16
Pole
2
Safety Assist
Seat Belt Reminders
3

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Pillar
B-Pillar, Right

Car Classification

American Classification
MPV
British Classification
Compact MPV
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Medium MPV

Spare Parts BETA

Bulb Types
Low Beam
  • D1S (xenon)
  • H7
Main Beam
H7
Bi-Xenon
D1S
Fog Light, Front
H11
Fog Light, Rear
BA15s (P21W)
Cornering Light
H7
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BA15s (P21W)
Reversing Light
BA15s (P21W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BAU15s (PY21W)
Glove Compartment
SV8.5 (C5W)
Read Light
SV8.5 (C10W)
License Plate Light
SV8.5 (C5W)
