TransmissionAutomatic (Electrohydraulic), 5-speed 10 litresEngine Fluids › Engine Coolant
- OAT
- BASF Glysantin G05
- Mopar OEM Coolant (red)
- HOAT
- Valvoline Zerex G-05
- Valvoline Zerex G-48
Car Battery
- Voltage
- 12 V
- Battery Capacity
- 100 Ah
- Secondary Battery
- Optional
- Alternator Charge Current
- 180 - 220 A
- Alternator Voltage
- 14 V
Engine Configuration
- Bore
- 83 mm (3.3 in)
- Stroke
- 92 mm (3.6 in)
- Compression Ratio
- 18 :1
- Engine Configuration
- V-Engine
- Turbocharger
- Yes
- Synchronization
- Timing Chain
- Engine Placement
- Front
- Engine Mount
- Longitudinally
- Type of Combustion Engine
Service Intervals
- Brake Fluid
- 2 years
- Oil Change & Engine Filter
- 16,000 km / 2 years
- Engine Coolant
- 288,000 km / 15 years
- Transmission, Fluid
- 96,000 km / 10 years
- Transmission, Fluid Filter
- 96,000 km / 10 years
- Rear Axle, Oil
- 288,000 km (178,955 mi)
Fuel SystemElectronic (Direct) Fuel Injection Engine CoolingLiquid Cooling 1 :1
Front Brakes
- Diameter
- 300 mm (11.8 in)
- Width
- 25 mm (1.0 in)
- Cooling
- Ventilated
Rear Brakes
- Diameter
- 298 mm (11.7 in)
- Width
- 14 mm (0.6 in)
- Cooling
- Ventilated
Powered Opening/ClosingOptional Air ConditionYesOutside Temperature IndicatorYes Number of Vents, Front4 pcs Climate Control › Air Condition
Connectivity
- Radio
- Optional
- Bluetooth
- Optional
- Phone Preparation
- Optional
Connectivity › Media Format
- CD
- Optional
- MP3
- Optional
- WMA
- Optional
Speakers
- Total Number of Speakers
- 8 pcs
Interior Storage › Storage Compartments
- Glove Compartment
- Yes
- Back Pocket
- Yes
- Sunglass Compartment
- Yes
- Card Holder
- Yes
- Under Seats
- Optional
- Door
- Driver Side
- Passenger Side
Interior Storage › Storage Compartments › Glove Compartment
- Cooled
- Optional
- Lockable
- Optional
Interior Storage › Storage Compartments › Under Seats
Interior Storage › Cup Holders
Interior Storage › Cup Holders › Front
- Placement
- Middle Console
- Top of Front Panel
Other Equipment
- Clock
- Yes
- 12V Outlet
- Front
- Carpets
- Yes
- Cigarette Lighter
- Yes
Other Equipment › Clock
- Digital
- Instrument Cluster
Other Equipment › Carpets
- Material
- Rubber
- Colour
- Black
Parking Heater › Cabin Heater
- Engine Heater
- Optional
- Remote
- Optional
- Timer
- Optional
Yes
Height Adjustable Retractor
Type of Belt
- Three-Point-Belt
- Front Seats
- Outer Rear Seats
- Centre Rear Seat
On-board Diagnostic, Port LocationSteering Wheel, Lower Left 2,731 mm (107.5 in)
Dimensions › Wheel Base
- L1
- 3,665 mm (144.3 in)
- L2
- 4,325 mm (170.3 in)
Dimensions › Overhang, Rear
- L1
- 1,240 mm (48.8 in)
- L2
- 1,615 mm (63.6 in)
Dimensions › Turning Circle
Side Door › Side Door Height
- H1
- 1,520 mm (59.8 in)
- H2
- 1,820 mm (71.7 in)
Side Door › Side Door Width
- L1
- 1,300 mm (51.2 in)
- L2
- 1,300 mm (51.2 in)
Side Door › Ground to Door Height
- L1H2
- 513 mm (20.2 in)
- L2H2
- 505 mm (19.9 in)
Rear Doors › Rear Doors Height
- L1H1
- 1,540 mm (60.6 in)
- H2
- 1,840 mm (72.4 in)
Rear Doors
- Rear Doors Width
- 1,565 mm (61.6 in)
Rear Doors › Sill Height
- L1H1
- 701 mm (27.6 in)
- L1H2
- 701 mm (27.6 in)
- L2H2
- 696 mm (27.4 in)
Cargo Space › Cargo Volume
- L1H1
- 4,001 litres
- L1H2
- 4,500 litres
- L2H2
- 5,301 litres
Cargo Space › Depth
- L1
- 3,265 mm (128.5 in)
- L2
- 4,300 mm (169.3 in)
Cargo Space › Height
- H1
- 1,650 mm (65.0 in)
- H2
- 1,940 mm (76.4 in)
Cargo Space
- Space Width
- 1,780 mm (70.1 in)
Cargo Space › Space Width, Between Wheel Arches
- L1
- 1,350 mm (53.1 in)
- L2
- 1,350 mm (53.1 in)
Weight
- Curb Weight
- 2546
- 2582
- 2760 kg (6,085 lb)
Weight › Gross Weight
- L1H1
- 3,878 kg (8,550 lb)
- L1H2
- 3,878 kg (8,550 lb)
- L2H2
- 3,878 kg (8,550 lb)
Weight › Cargo Capacity
- L1H1
- 1,332 kg (2,937 lb)
- L1H2
- 1,296 kg (2,857 lb)
- L2H2
- 1,118 kg (2,465 lb)
Optional
Rear Washer SystemOptional Windows
- Window Lifts, Front
- Powered
- Heated Windows
- Rear
- Tinted Windows
- Optional
Windows › Tinted Windows
- Second Row
- Optional
- Rear Window
- Optional
Other Equipment
- Sunroof
- Optional
- Antenna
- Whip
- Air Intakes
- 1-port
- Number of Exhaust Pipes
- 1
Other Equipment › Sunroof
Number of Passenger Seat Adjustments, Manual6 - 10 Number of Passenger Seat Adjustments, Total6 - 10 Dual Passenger SeatOptional Front Seats › Adjustments, Passenger
- Seat Depth
- Manual
- Seat Height
- Manual
- Cushion Tilt
- Optional
- Backrest Angle
- Manual
- Lumbar Support
- Optional
- Headrest, Height
- Manual
Front Seats › Heated Seats
- Cushion
- Optional
- Number of Heat Levels
- 2
Front Seats › Heated Seats › Cushion
- Backrest
- Optional
- Neck
- Optional
Second Seat Row › Headrests
- Outer Seats
- Height Adjustment
- Centre Seat
- Yes
Second Seat Row
- Number of Seats
- 3
- Type of Seat
- Adult
Third/Fourth Seat Row
- Third Seat Row
- Yes
- Fourth Seat Row
- Yes
Third/Fourth Seat Row › Third Seat Row
- Number of Seats
- 3
- Seat Angle
- Front Facing
Optional
Curtain Airbag
DriverOptional
PassengerOptional
Rear-
LCVVariantSprinter Standard2003–2009 Powertrain3.0 V6 CRD Automatic Drivetrain
RWD Transmission
Automatic (Electrohydraulic), 5-speed 2007–2009
