20 photos
2007 Ford Edge
United States
Gasoline
FWD
SUV
20 photos
20 photos
Photos
Specifications
Vehicle Details
Powertrain
Dimensions
Engine & Performance
Dimensions & Weight
Exterior
Interior
Safety & Security
Other
Vehicle Details
Year
2007
Make
Ford
Model
Edge
Body Style
SUV
Generation
1st Generation (U387)
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic, 6-speed
Powertrain
Engine Name
3.5 V6 Ti-VCT Automatic
Engine Configuration
V
Power (hp)
269 hp
Power (kW)
198 kW
Torque
339 Nm (250 lb-ft)
Displacement
3,496 cc
Dimensions
Length
4,717 mm
(185.7 in)
Width
1,925 mm
(75.8 in)
Height
1,707 mm
(67.2 in)
Wheelbase
2,824 mm
(111.2 in)
Curb weight
1,848 kg
(4,074 lb)
Engine & Performance
Engine
Engine Specification
Rev. at Max Power
6,250 rpm
Rev. at Max Torque
4,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
0W-30
0W-40
5W-30
5W-40
10W-30
10W-40
Semi-synthetic Oil (viscosity)
5W-30
5W-40
10W-30
10W-40
15W-40
20W-40
Engine Configuration
Bore
92.5 mm
(3.6 in)
Stroke
86.7 mm
(3.4 in)
Compression Ratio
10.3 :1
Engine Configuration
V-Engine
Transmission & Drivetrain
Transmission
Automatic, 6-speed
Brakes
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Fuel
General
Tank Volume
76 litres
Fuel Consumption NEDC
City
13.1 litres / 100 km
Highway
9.4 litres / 100 km
Combined
11.2 litres / 100 km
Dimensions & Weight
Exterior
Track, Front
1,653 mm
(65.1 in)
Track, Rear
1,648 mm
(64.9 in)
Turning Circle
11.74 m
Ground Clearance
203 mm
(8.0 in)
Interior
Exterior
Chassis & Body
Chassis
Chassis
SUV
Pillars
A-D
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Interior
Seats
Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Safety & Security
Seat Belt
Type of Belt
Three-Point-Belt
Front Seats
Seat Belt Colour
Black
Feature
Driver
Passenger
Rear
Seat Belt Reminder
Other
Car Classification
American Classification
Mid-Size SUV
British Classification
Large 4x4
Australian Classification
Large SUV
European Segment
J-Segment
Car.info Classification
Large SUV
Head Room, Front
1,016 mm
(40.0 in)
Head Room, Rear
998 mm
(39.3 in)
Leg Room, Front
1,034 mm
(40.7 in)
Leg Room, Rear
1,006 mm
(39.6 in)
Shoulder Room, Front
1,496 mm
(58.9 in)
Shoulder Room, Rear
1,494 mm
(58.8 in)
Weight
Gross Weight
2,334 kg
(5,146 lb)
Max Trailer Load, braked 12%
1,588 kg
(3,501 lb)
Cargo Capacity
486 kg
(1,071 lb)
Max Roof Load
75 kg
(165 lb)
Ford Motor Company
CD3 Platform
Equipment
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Other Equipment
Normal Roof
Yes
Rims & Tires
Number of Bolts
5 pcs
Bolt Distance
114.3
Central Bore (CB), front
67.1
Fastening Type
Lug Nuts
Tightening Torque
220 Nm
Headrest, Height
Manual
Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Trunk
Rear Trunk
Yes
Rear Trunk
Volume
932 litres
Volume, Back Seat Collapsed
1,971 litres
Driver
Yes
Passenger
Yes
Rear
-
Belt Pretensioner
Driver
Yes
Passenger
Yes
Rear
-
Brake Systems
Anti-lock Braking System (ABS)
Yes
Safety Testing
General
Not Tested by Euro NCAP
Yes
Airbags
Feature
Driver
Passenger
Rear
Frontal Airbag
Driver
Yes
Passenger
Yes
Rear
-
Side Head Airbag
Driver
Edge
8.9
€67,000
MSRP · EUR
Body
Yes
Passenger
-
Rear
-
SUV
Variant
Edge Standard
2007–2024
Edge SUV Generations
1 of 3
1st Generation (U387)
2007–2014
Year
2007
Powertrain
3.5 V6 Ti-VCT Automatic
Horsepower
269 hp
Drivetrain
FWD
Fuel
Gasoline
Transmission
Automatic, 6-speed
SUV
FWD
Gasoline
Automatic, 6-speed
