2008 Cadillac STS

United StatesGasolineRWDSedan

Photos

Specifications

Vehicle Details

Year
2008
Make
Cadillac
Model
STS
Body Style
Sedan
Generation
1st Generation Facelift
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
3.6 V6 Hydra-Matic
Engine Configuration
V
Power (hp)
306 hp
Power (kW)
225 kW
Torque
369 Nm (272 lb-ft)
Displacement
3,564 cc

Dimensions

Length
4,986 mm (196.3 in)
Width
1,844 mm (72.6 in)
Height
1,463 mm (57.6 in)
Wheelbase
2,956 mm (116.4 in)
Curb weight
1,750 kg (3,858 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,300 rpm
Rev. at Max Torque
5,200 rpm
Redline
6,700 rpm
Engine Fluids
Synthetic Oil (viscosity)
5W-30
Engine Oil, Volume
5.7 litres
Engine Coolant, Volume
10.6 litres
Engine Configuration
Bore
94 mm (3.7 in)
Stroke
85 mm (3.3 in)
Compression Ratio
11.3 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
64,000 km (39,768 mi)
Spark Plug
160,000 km (99,419 mi)
Brake Fluid
2 years
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Transmission, Fluid
160,000 km (99,419 mi)
Transmission, Fluid Filter
160,000 km (99,419 mi)
Interior Filter
40,000 km (24,855 mi)

Transmission & Drivetrain

Transmission
Automatic, 6-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
4.06 :1
2nd Gear
2.37 :1
3rd Gear
1.55 :1
4th Gear
1.15 :1
5th Gear
0.85 :1
6th Gear
0.67 :1
Final Drive
3.42 :1
Reverse
3.2 :1

Brakes

Parking Brake
Manual
Pedal
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
303 - 355 mm (11.9 - 14.0 in)
Width
355 mm (14.0 in)
Cooling
Ventilated
Rear Brakes
Diameter
298 - 365 mm (11.7 - 14.4 in)
Width
26 mm (1.0 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
Yes
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Multi-link
Anti-roll Bar
Front
33 mm (1.3 in)
Rear
17 - 19 mm (0.7 - 0.7 in)

Fuel

General
Tank Volume
66 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption EPA
City
17 MPG
Highway
26 MPG

Dimensions & Weight

Exterior

Track, Front
1,569 mm (61.8 in)
Track, Rear
1,581 mm (62.2 in)
Turning Circle
11.5 - 11.8 m

Interior

Head Room, Front
983 mm (38.7 in)
Head Room, Rear
962 mm (37.9 in)
Leg Room, Front
1,082 mm (42.6 in)
Leg Room, Rear
972 mm (38.3 in)
Hip Room, Front
1,387 mm (54.6 in)
Hip Room, Rear
1,412 mm (55.6 in)
Shoulder Room, Front
1,488 mm (58.6 in)
Shoulder Room, Rear
1,458 mm (57.4 in)

Weight

Max Roof Load
75 kg (165 lb)
Weight Distribution, front
52 %
Weight Distribution, rear
48 %

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Chassis Construction
Unibody
Roof Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
Sigma Platform (Sigma I)

Equipment

Windscreen Wipers
Speed Sensing Intermittent
Yes
Intermittent Control
Yes
Rear Wiper
Yes
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Electric
Optional

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
115
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
70.3
Fastening Type
Lug Nuts
Tightening Torque
140 Nm

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Connectivity
Radio
Yes
Bluetooth
Optional
Connectivity › Media Format
CD
Yes
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional

Steering Wheel

Multifunction Steering Wheel
Yes

Trunk

Rear Trunk
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
464 litres

Seats

Colour & Material
Upholstery
Leather
Front Seats
Heated Seats
Optional
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40

Features

Comfort Features

Keyless Entry
Yes
Cruise Control
Yes

Other Features

GPS
Optional

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Other Features

Anti-theft Alarm
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Airbag cut-off Switch

Other

Car Classification

American Classification
Mid-Size Luxury Car
British Classification
Executive Car
Australian Classification
Large Car
European Segment
E-Segment
Car.info Classification
Executive Car
