Generation1st Generation 2nd Facelift TransmissionAutomatic (Electrohydraulic), 4-speed 27.2 litres
Car Battery
- Voltage
- 12 V
- Battery Capacity
- 65 - 72 Ah
- Cold Start Power
- 650 - 750 A
- Secondary Battery
- Optional
- Alternator Charge Current
- 120 - 225 A
- Alternator Voltage
- 14 V
Engine Configuration
- Bore
- 90.2 mm (3.6 in)
- Stroke
- 105.8 mm (4.2 in)
- Compression Ratio
- 9 :1
- Engine Configuration
- V-Engine
- Naturally Aspirated
- Yes
- Synchronization
- Timing Chain
- Engine Placement
- Front
- Engine Mount
- Longitudinally
- Type of Combustion Engine
Service Intervals
- Air Filter
- 48,000 km (29,826 mi)
- Spark Plug
- 145,000 km (90,099 mi)
- Oil Change & Engine Filter
- 12,000 km (7,456 mi)
- Engine Coolant
- 169,000 km (105,012 mi)
- Accessory Belt
- 241,000 km (149,750 mi)
Fuel SystemElectronic (Multi-Point) Fuel Injection Engine CoolingLiquid Cooling 4th Gear0.7 :1Head Room, Front1,067 mm (42.0 in)Head Room, Rear1,021 mm (40.2 in) Leg Room, Front1,016 mm (40.0 in) Leg Room, Rear980 - 983 mm (38.6 - 38.7 in) Hip Room, Front1,664 mm (65.5 in) Hip Room, Rear1,689 mm (66.5 in) Shoulder Room, Front1,730 mm (68.1 in) Shoulder Room, Rear1,821 mm (71.7 in) Rear Doors- Sliding Right
- Dual Swing-out
Platform
- Ford Motor Company
- VN Platform (VN58/VN127)
Climate Control
- Climate Control
- Manual
- Air Condition
- Yes
- Outside Temperature Indicator
- Optional
- Number of Vents, Front
- 4 pcs
- Controls
- Rotary Dials
Climate Control › Air Condition
- Refrigerant
- R134A
- Refrigerant, Capacity
- 1,134 g
Connectivity › Media Format
Speakers
- Total Number of Speakers
- 4 pcs
Rear-view Mirror
- Compass
- Optional
- Oustide Temperature
- Optional
Interior Storage › Storage Compartments
- Glove Compartment
- Yes
- Coin Holder
- Yes
- Door
- Driver Side
- Passenger Side
Interior Storage › Cup Holders
Interior Storage › Cup Holders › Front
Other Equipment › Make-up Mirror
- Driver Side
- Optional
- Passenger Side
- Optional
- Make-up Light
- Optional
Other Equipment
- Clock
- Optional
- 12V Outlet
- Front
- Carpets
- Optional
- Ashtray
- Optional
- Cigarette Lighter
- Optional
Other Equipment › Ashtray
Van
Australian ClassificationVan European SegmentM-Segment Car.info ClassificationCargo Van 55.7 %
Weight Distribution, rear44.3 % 3,505 mm (138.0 in)
Dimensions › Overhang, Rear
- L1
- 1,113 mm (43.8 in)
- L2
- 1,621 mm (63.8 in)
Dimensions › Turning Circle
Side Door › Side Door Height
Side Door › Side Door Width
- L1
- 1,138 mm (44.8 in)
- L2
- 1,138 mm (44.8 in)
Side Door › Ground to Door Height
- L1H1
- 711 mm (28.0 in)
- L1H2
- 726 mm (28.6 in)
Rear Doors › Rear Doors Height
Rear Doors
- Rear Doors Width
- 1,369 mm (53.9 in)
Rear Doors › Sill Height
- L1H1
- 711 mm (28.0 in)
- L2H1
- 726 mm (28.6 in)
Cargo Space › Cargo Volume
- L1H1
- 6,530 litres
- L1H2
- 7,682 litres
Cargo Space › Depth
- L1
- 3,109 mm (122.4 in)
- L2
- 3,617 mm (142.4 in)
Cargo Space
- Space Width
- 1,869 mm (73.6 in)
Cargo Space › Space Width, Between Wheel Arches
Optional
Rear Windows, Pop-outOptional Windows › Heat-Insulating Windows
- Second Row
- Optional
- Rear
- Optional
Windows › Tinted Windows
- Second Row
- Optional
- Rear Window
- Optional
Windows › Rear Windows, Pop-out
Other Equipment
- Antenna
- Optional
- Air Intakes
- 1-port
- Number of Exhaust Pipes
- 1
- Side Steps
- Optional
Other Equipment › Side Steps
Number of Passenger Seat Adjustments, Manual4 - 6 Number of Passenger Seat Adjustments, Powered6 Number of Passenger Seat Adjustments, Total4 - 8 Power Seat, DriverOptional Power Seat, PassengerOptional Front Seats › Adjustments, Passenger
- Seat Depth
- Yes
- Seat Height
- Optional
- Backrest Angle
- Manual
- Lumbar Support
- Optional
Height Adjustable Retractor
Type of Belt
- Three-Point-Belt
- Front Seats
LCVPowertrain5.4 V8 SEFI 2V Automatic Drivetrain
RWD Transmission
Automatic (Electrohydraulic), 4-speed
