8 photos
Vehicles
›
Make
›
Ford
›
Model
›
E-Series
2008 Ford
E-Series
E-350
Super Duty
United States
Gasoline
RWD
LCV
Updated Aug 27, 2026
8 photos
8 photos
Photos
Specifications
Vehicle Details
Powertrain
Dimensions
Engine & Performance
Dimensions & Weight
Exterior
Interior
Features
Safety & Security
Other
Vehicle Details
Year
2008
Make
Ford
Model
E-Series
Variant
E-350 Super Duty
Body Style
LCV
Generation
1st Generation 2nd Facelift
Seats
7
Doors
4
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic (Electrohydraulic), 5-speed
Powertrain
Engine Name
6.8 V10 SEFI 2V TorqShift
Engine Configuration
V
Power (hp)
309 hp
Power (kW)
227 kW
Torque
569 Nm (420 lb-ft)
Displacement
6,760 cc
Dimensions
Width
2,017 mm
(79.4 in)
Engine & Performance
Engine
Engine Specification
Rev. at Max Power
4,250 rpm
Rev. at Max Torque
3,250 rpm
Engine Fluids
Synthetic Oil (viscosity)
5W-20
Engine Oil, Volume
5.7 litres
Engine Coolant, Volume
28.8 litres
Car Battery
Voltage
12 V
Battery Capacity
65 - 72 Ah
Cold Start Power
650 - 750 A
Secondary Battery
Optional
Alternator Charge Current
120 - 225 A
Alternator Voltage
14 V
Engine Configuration
Bore
90.2 mm
(3.6 in)
Stroke
105.8 mm
(4.2 in)
Compression Ratio
9 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
OHC
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Transmission & Drivetrain
Transmission
Automatic (Electrohydraulic), 5-speed
Gear Selector
Stalk
Gear Selector Location
Steering Column
Overdrive
Yes
Gear Ratio
1st Gear
3.11 :1
2nd Gear
2.11 :1
3rd Gear
1.55 :1
5th Gear
0.71 :1
Final Drive
3.73 :1
Reverse
2.88 :1
Fuel
General
Tank Volume
132 - 140 litres
General › Fuel Cap Position
Rear
Left
Brakes
Parking Brake
Manual
Pedal
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
345 mm
(13.6 in)
Width
12.42 mm
(0.5 in)
Rear Brakes
Diameter
345 mm
(13.6 in)
Width
12.42 mm
(0.5 in)
Suspensions
Spring, Front
Coil
Spring, Rear
Leaf (Longitudinal Spring)
Anti-roll Bar
Yes
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Dependent
Beam Axle (Dead Axle)
Anti-roll Bar
Front
25.4 mm
(1.0 in)
Dimensions & Weight
Exterior
Width, with Mirrors
2,692 mm
(106.0 in)
Track, Front
1,763 mm
(69.4 in)
Track, Rear
1,692 mm
(66.6 in)
Overhang, Front
988 mm
(38.9 in)
Interior
Head Room, Front
1,067 mm
(42.0 in)
Leg Room, Front
1,016 mm
(40.0 in)
Hip Room, Front
1,664 mm
(65.5 in)
Shoulder Room, Front
1,730 mm
(68.1 in)
Shoulder Room, Rear
1,821 mm
(71.7 in)
LCV Specific
General
Version
L1H1
L1H2
L2H1
L2H2
Dimensions › Length
L1
5,504 mm
(216.7 in)
L2
6,012 mm
(236.7 in)
Dimensions › Wheel Base
L1
3,505 mm
(138.0 in)
L2
3,505 mm
(138.0 in)
Dimensions › Overhang, Rear
L1
1,113 mm
(43.8 in)
L2
1,621 mm
(63.8 in)
Dimensions › Turning Circle
L1
14.81 m
L2
16.7 m
Side Door › Side Door Height
H1
1,224 mm
(48.2 in)
Side Door › Side Door Width
L1
1,138 mm
(44.8 in)
L2
1,138 mm
(44.8 in)
Side Door › Ground to Door Height
L1H1
711 mm
(28.0 in)
L1H2
726 mm
(28.6 in)
Rear Doors › Rear Doors Height
L1H1
1,257 mm
(49.5 in)
Rear Doors
Rear Doors Width
1,369 mm
(53.9 in)
Rear Doors › Sill Height
L1H1
711 mm
(28.0 in)
L2H1
726 mm
(28.6 in)
Cargo Space › Depth
L1
3,109 mm
(122.4 in)
L2
3,617 mm
(142.4 in)
Cargo Space
Space Width
1,869 mm
(73.6 in)
Cargo Space › Space Width, Between Wheel Arches
L1
1,334 mm
(52.5 in)
Exterior
Chassis & Body
Chassis
Chassis
LCV
Pillars
A-D
A-D + Extra Pillar(s)
Chassis Construction
Body-on-Frame (Ladder Frame)
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Dual Swing-out
Platform
Ford Motor Company
VN Platform (VN58/VN127)
Equipment
Side Mirrors
Mirror Type
Conventional
Folding
Manual
House Colour
Non-painted
Windscreen Wipers
Number of Wiper Speeds
2
Intermittent Control
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Heat-Insulating Windows
Front
First Row
Second Row
Rear
Sun Visors
Optional
Tinted Windows
Optional
Rear Windows, Pop-out
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Windows › Rear Windows, Pop-out
Manual
Optional
Other Equipment
Sunroof
Optional
Antenna
Whip
Air Intakes
1-port
Number of Exhaust Pipes
1
Side Steps
Optional
Other Equipment › Sunroof
Sun Blind
Optional
Other Equipment › Side Steps
Stationary
Optional
Lights
Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Special Features
Headlight Range Adjustment
Manual
Colour
Door Handles
Non-painted
Rims & Tires
Tire Pressure Monitoring System (TPMS)
Direct
Number of Bolts
8 pcs
Fastening Type
Lug Nuts
Tightening Torque
190 Nm
Rim Colour
Silver
Rim Type
Disc Wheel
Spare Wheel
Full-size (Steel)
Interior
Equipment
Instrument Cluster
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Voltmeter
Analogue
Oil Pressure
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Climate Control
Manual
Air Condition
Yes
Outside Temperature Indicator
Optional
Number of Vents, Front
4 pcs
Controls
Rotary Dials
Back Seat Controls
Optional
Climate Control › Air Condition
Refrigerant
R134A
Refrigerant, Capacity
1,134 g
Climate Control › Back Seat Controls
Rotary Dials
Optional
Connectivity
Radio
AM
FM
TV Receiver
Optional
Connectivity › Media Format
CD
Optional
MP3
Optional
Displays
Entertainment Screens
Optional
Equalizer
Optional
Displays › Entertainment Screens
Middle of Roof
Optional
Speakers
Total Number of Speakers
4 - 6 pcs
Subwoofer
Optional
Rear-view Mirror
Compass
Optional
Oustide Temperature
Optional
Interior Storage › Storage Compartments
Glove Compartment
Yes
Coin Holder
Yes
Door
Driver Side
Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Rear
Other Equipment › Make-up Mirror
Driver Side
Optional
Passenger Side
Optional
Make-up Light
Optional
Other Equipment
Clock
Yes
12V Outlet
Front
Rear
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Clock
Digital
Dashboard
Other Equipment › Ashtray
Front
Optional
Steering Wheel
Multifunction Steering Wheel
Optional
Power Steering
Hydraulic
Adjustments
Tilt
Number of Spokes
2
Colour
Black
Steering Ratio
17 :1
Steering Mechanism
Recirculating Ball
Multifunction Steering Wheel
Number of Buttons
5 pcs
Trunk
Release Button
Yes
Light
Yes
Hatch Opening Type
Two-parted Doors
Design
Interior Decor Material
Plastic
Transmission Knob Material
Plastic
Entry Guard Material
Plastic
Entry Guard Material
Black
Optional
Brown
Optional
Seats
Front Seats › Adjustments, Driver
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Lumbar Support
Optional
Front Seats
Number of Driver Seat Adjustments, Powered
10 - 12
Number of Driver Seat Adjustments, Total
10 - 12
Number of Passenger Seat Adjustments, Powered
10 - 12
Number of Passenger Seat Adjustments, Total
10 - 12
Power Seat, Driver
Yes
Power Seat, Passenger
Yes
Heated Seats
Optional
Armrest
Middle
Type of Seat
Comfort Seat (Driver | Passenger)
Front Seats › Adjustments, Passenger
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Lumbar Support
Optional
Second Seat Row
Armrest
Yes
Type of Seat
Adult
Second Seat Row › Armrest
Powered Seats
Optional
Seat Depth
Optional
Backrest Angle
Optional
Third/Fourth Seat Row
Third Seat Row
Yes
Third/Fourth Seat Row › Third Seat Row
Collapsible
Yes
Type of Seat
Adult
Third/Fourth Seat Row › Third Seat Row › Collapsible
Fold Type
Powered
Split Fold Ratio
No Split
Features
Comfort Features
Keyless Entry
Optional
Remote Engine Start
Optional
Cruise Control
Optional
Speed Limiter
Optional
Parking Heater
Optional
Parking Heater
Engine Heater
Optional
Other Features
Horn
Dual Note
Accessories
Tool Kit and Jack
Yes
Coat Hanger
Optional
Safety & Security
Airbags
Other Airbags
Pedestrian Airbag
No
Middle Airbag
No
Door-mounted Airbags
No
Seat Belt Airbag
No
Seat Cushion
No
Feature
Driver
Passenger
Rear
Frontal Airbag
Driver
Yes
Passenger
Yes
Rear
No
Side Chest Airbag
Driver
No
Passenger
No
Rear
No
Side Head Airbag
Driver
No
Passenger
No
Rear
No
Side Pelvis Airbag
Driver
No
Passenger
No
Rear
No
Knee Airbag
Driver
No
Passenger
No
Rear
No
Curtain Airbag
Driver
No
Passenger
No
Rear
No
Center Airbag
Driver
No
Passenger
No
Rear
No
Airbag cut-off Switch
Driver
No
Passenger
No
Rear
No
Seat Belt
Height Adjustable Retractor
Yes
Feature
Driver
Passenger
Rear
Belt Pretensioner
Driver
Yes
Passenger
Yes
Rear
-
Belt Load Limiter
Driver
Yes
Passenger
-
Rear
-
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Front Seats
Brake Systems
Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Optional
Other Features
Immobiliser
Optional
Central Locking
Optional
Reversing Alarm
Optional
Number of Remote Keys
2
Number of Standard Keys
2
Total Number of Keys
4
Central Locking
Remote
Optional
Child Protection
Isofix
Passenger: No
Rear: No
Other
Identification
VIN Location
Left Side Casing of Window
Yes
On-board Diagnostic, Port Location
Steering Wheel, Lower Middle
Car Classification
American Classification
Passenger Van
British Classification
Minibus
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Passenger Van
E-Series
Model
5 variants
€67,000
MSRP · EUR
8.9
Body
LCV
Variant
E-Series E-350 Super Duty
2000–2022
Configuration
Conversion Van
E-Series E-350 Super Duty LCV Generations
3 of 6
1st Generation 2nd Facelift
2008
Year
2008
Powertrain
6.8 V10 SEFI 2V TorqShift
Horsepower
309 hp
Drivetrain
RWD
Fuel
Transmission
Automatic (Electrohydraulic), 5-speed
Gasoline
LCVLCV
RWD
Gasoline
