2009 Ford E-Series E-450 Super Duty
Generation1st Generation 3rd Facelift TransmissionAutomatic (Electrohydraulic), 5-speed 28.8 litres
Car Battery
- Voltage
- 12 V
- Battery Capacity
- 65 - 72 Ah
- Cold Start Power
- 650 - 750 A
- Secondary Battery
- Optional
- Alternator Charge Current
- 120 - 225 A
- Alternator Voltage
- 14 V
Engine Configuration
- Bore
- 90.2 mm (3.6 in)
- Stroke
- 105.8 mm (4.2 in)
- Compression Ratio
- 9 :1
- Engine Configuration
- V-Engine
- Naturally Aspirated
- Yes
- Synchronization
- Timing Chain
- Engine Placement
- Front
- Engine Mount
- Longitudinally
- Type of Combustion Engine
Service Intervals
- Air Filter
- 48,000 km (29,826 mi)
- Fuel Filter
- 48,000 km (29,826 mi)
- Spark Plug
- 145,000 km (90,099 mi)
- Oil Change & Engine Filter
- 12,000 km (7,456 mi)
- Engine Coolant
- 169,000 km (105,012 mi)
- Transmission, Fluid
- 77,250 km (48,001 mi)
- Transmission, Fluid Filter
- 77,250 km (48,001 mi)
Fuel SystemElectronic (Multi-Point) Fuel Injection Engine CoolingLiquid Cooling Accessory Belt241,000 km (149,750 mi)4th Gear1 :1Front23 - 25.4 mm (0.9 - 1.0 in) Head Room, Front1,067 mm (42.0 in)Leg Room, Front1,016 mm (40.0 in) Hip Room, Front1,664 mm (65.5 in) Shoulder Room, Front1,730 mm (68.1 in) Door HandlesPull-upPlatform
- Ford Motor Company
- VN Platform (VN58/VN127)
Odometer Limit1,000,000 km/miles Climate Control
- Climate Control
- Manual
- Number of Climate Zones
- 1
- Air Condition
- Yes
- Number of Vents, Front
- 4 pcs
- Controls
- Rotary Dials
Connectivity › Radio
- AM
- Optional
- FM
- Optional
- XM
- Optional
Connectivity › Media Format
Connectivity › Media Inputs
Connectivity › Media Inputs › USB
- USB-A
- Optional
- Number of Ports
- 1 pcs
Displays
- Center Display
- 6.5"
- Equalizer
- Optional
Displays › Center Display Controls
- Touchscreen
- Optional
- Buttons
- Optional
Displays › Center Display Controls › Buttons
Speakers
- Total Number of Speakers
- 2 - 4 pcs
Rear-view Mirror
- Compass
- Optional
- Oustide Temperature
- Optional
Interior Storage › Storage Compartments
- Glove Compartment
- Yes
- Coin Holder
- Yes
- Door
- Driver Side
- Passenger Side
Interior Storage › Cup Holders
Interior Storage › Cup Holders › Front
Other Equipment › Make-up Mirror
- Driver Side
- Optional
- Passenger Side
- Optional
- Make-up Light
- Optional
Other Equipment
- Clock
- Optional
- 12V Outlet
- Front
- Carpets
- Optional
- Ashtray
- Optional
- Cigarette Lighter
- Optional
Other Equipment › Ashtray
Optional
Passenger
Height Adjustable Retractor
Type of Belt
- Three-Point-Belt
- Front Seats
Commercial Chassis
4,470 mm (176.0 in)
Dimensions › Overhang, Rear
- L2
- 1,740 mm (68.5 in)
- L3
- 1,283 mm (50.5 in)
Dimensions › Turning Circle
Other Equipment
- Antenna
- Whip
- Air Intakes
- 1-port
- Number of Exhaust Pipes
- 1
- Mud Flaps
- Optional
- Side Steps
- Optional
Other Equipment › Mud Flaps
Other Equipment › Side Steps
Number of Passenger Seat Adjustments, Manual4 - 6 Number of Passenger Seat Adjustments, Powered6 Number of Passenger Seat Adjustments, Total4 - 8 Power Seat, DriverOptional Power Seat, PassengerOptional Front Seats › Adjustments, Passenger
- Seat Depth
- Yes
- Seat Height
- Optional
- Backrest Angle
- Manual
- Lumbar Support
- Optional
-
LCVDrivetrain
RWD Transmission
Automatic (Electrohydraulic), 5-speed
