2009 Renault Clio Symbol

FranceGasoline2WDSedan

Specifications

Vehicle Details

Year
2009
Make
Renault
Model
Clio
Variant
Symbol
Body Style
Sedan
Generation
BB/CB Phase IV
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
2WD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.4 Manual
Power (hp)
98 hp
Power (kW)
72 kW
Torque
127 Nm (94 lb-ft)
Displacement
1,390 cc

Dimensions

Length
4,260 mm (167.7 in)
Width
1,640 mm (64.6 in)
Height
1,430 mm (56.3 in)
Wheelbase
2,470 mm (97.2 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
3,750 rpm

Fuel

General › Fuel Cap Position
Rear
Right

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Semi-dependent
Twist-Beam

Dimensions & Weight

Exterior

Ground Clearance
120 mm (4.7 in)

Weight

Max Roof Load
70 kg (154 lb)
Max Towbar Download
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
Renault-Nissan Platforms
B Platform (B)

Equipment

Side Mirrors
Mirror Type
Conventional
Heated
Optional
Windows
Window Lifts, Front
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Roof Railing
Optional
Antenna
Whip

Lights

Rear Lights
Halogen
Fog Lights
Optional

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
60.1
Fastening Type
Lug Bolts
Tightening Torque
90 Nm
Spare Wheel
Optional
Spare Wheel
Temporary
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Optional
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Climate Control
Air Condition
Optional
Pollen Filter
Optional
Outside Temperature Indicator
Optional
Connectivity
Radio
Optional
Connectivity › Radio
AM
Optional
FM
Optional
CD
Optional
Interior Storage › Storage Compartments
Glove Compartment
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
Yes
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Other Equipment
12V Outlet
Front
Carpets
Optional
Ashtray
Front
Cigarette Lighter
Yes

Steering Wheel

Multifunction Steering Wheel
Optional
Power Steering
Electric
Adjustments
Tilt
Number of Spokes
3
Material
Plastic
Colour
Grey
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
506 litres

Design

Colour
  • Beige
  • Black
  • Grey

Seats

Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Backrest Angle
Manual
Headrest, Height
Manual
Headrest, Tilt
Manual

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Rear
Optional

Other Features

Anti-theft Alarm
Optional
Central Locking
Remote

Safety Testing

General
Test Year
2000
Adult Occupant
4/5 stars
Pedestrian
2/4 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Engine Compartment, Inner Wing
Right
Left Side Casing of Window
Yes
Pillar
B-Pillar, Right

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
Supermini
Australian Classification
Light Car
European Segment
B-Segment
Car.info Classification
Small Family Car

Spare Parts BETA

Bulb Types
Low Beam
  • D2S (xenon)
  • H4
  • H7
Main Beam
  • H1
  • H4
  • H7
Fog Light, Front
H11
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
BA15s (P21W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Side
W2.1×9.5d (W5W)
Turn Indicators, Rear
  • BA15s (P21W)
  • BAU15s (PY21W)
Read Light
SV8.5 (C5W)
License Plate Light
SV8.5 (C5W)
