2010 Cadillac SRX

United StatesGasolineFWDSUV

Photos

Specifications

Vehicle Details

Year
2010
Make
Cadillac
Model
SRX
Body Style
SUV
Generation
2nd Generation
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic (Electrohydraulic), 6-speed

Powertrain

Engine Name
3.0 V6 Hydra-Matic
Engine Configuration
V
Power (hp)
269 hp
Power (kW)
198 kW
Torque
301 Nm (222 lb-ft)
Displacement
2,994 cc

Dimensions

Length
4,834 mm (190.3 in)
Width
1,912 mm (75.3 in)
Height
1,670 mm (65.7 in)
Wheelbase
2,807 mm (110.5 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
7,000 rpm
Rev. at Max Torque
3,200 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Oil, Volume
5.7 litres
Engine Coolant, Volume
11.9 litres
Engine Configuration
Bore
89 mm (3.5 in)
Stroke
80.3 mm (3.2 in)
Compression Ratio
11.7 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
80,000 km (49,710 mi)
Spark Plug
160,000 km (99,419 mi)
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Transmission, Fluid
160,000 km (99,419 mi)
Transmission, Fluid Filter
160,000 km (99,419 mi)
Interior Filter
40,000 km (24,855 mi)

Transmission & Drivetrain

Transmission
Automatic (Electrohydraulic), 6-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console
Type of Two Wheel Drive
FWD
Gear Ratio
1st Gear
4.48 :1
2nd Gear
2.87 :1
3rd Gear
1.84 :1
4th Gear
1.41 :1
5th Gear
1 :1
6th Gear
0.74 :1
Final Drive
3.39 :1
Reverse
2.88 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
345 mm (13.6 in)
Width
30 mm (1.2 in)
Cooling
Ventilated
Rear Brakes
Diameter
315 mm (12.4 in)
Width
23 mm (0.9 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Semi-Trailing Arm

Fuel

General
Tank Volume
79.5 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption EPA
City
18 MPG
Highway
25 MPG

Dimensions & Weight

Exterior

Track, Front
1,622 mm (63.9 in)
Track, Rear
1,617 mm (63.7 in)
Turning Circle
12.2 m
Ground Clearance
179 mm (7.0 in)

Interior

Head Room, Front
1,009 mm (39.7 in)
Head Room, Rear
976 mm (38.4 in)
Leg Room, Front
1,047 mm (41.2 in)
Leg Room, Rear
923 mm (36.3 in)
Hip Room, Front
1,408 mm (55.4 in)
Hip Room, Rear
1,391 mm (54.8 in)
Shoulder Room, Front
1,481 mm (58.3 in)
Shoulder Room, Rear
1,431 mm (56.3 in)

Weight

Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Pillars
A-D
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
Theta Platform (Theta Premium)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
User Memory
Optional
Heated
Yes
Side Mirrors › Adjustments
Driver side
Optional
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Other Equipment
Sunroof
Optional
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)
Colour
Silver

Lights

Rear Lights
LED
Daytime Running Light
LED
Fog Lights
Optional

Colour

Finish
Metallic

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Nut/Bolt Dimensions
M12x1.5
Fastening Type
Lug Nuts
Tightening Torque
150 - 190 Nm
Spare Wheel
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Micro Filter
Yes
Connectivity
Radio
Yes
Media Inputs
USB
Bluetooth
Phone
Connectivity › Radio
DVD
Optional
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Optional
Displays › Center Display
Touchscreen
Optional
Speakers
Speaker Brand
Bose
Interior Storage › Storage Compartments
Armrest Hatch
Yes
Interior Storage
Cup Holders
Yes

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Yes
Adjustments
  • Tilt
  • Telescope
Channels
Yes
Volume
Yes
Mute Audio
Yes
Multifunction Steering Wheel
Cruise Control
Yes

Trunk

Rear Trunk
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
844 litres
Volume, Back Seat Collapsed
1,730 litres
Sill Height
764 mm (30.1 in)

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Front Seats
Power Seat, Driver
Optional
Heated Seats
Optional
Armrest
Yes
Ventilated Seats
Optional
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40
Heated Seats
Optional

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Remote Engine Start
Optional
Cruise Control
Yes
Cameras
Optional
Cameras
Rear
Optional

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes
IIHS
Test Year
2010
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Latch Ease of Use
Marginal

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Curtain Airbag

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left

Car Classification

American Classification
Compact SUV
British Classification
Compact SUV
Australian Classification
Medium SUV
European Segment
J-Segment
Car.info Classification
Medium SUV
