2010 Chrysler Town & Country

United StatesGasolineFWDMinivan

Photos

Specifications

Vehicle Details

Year
2010
Make
Chrysler
Model
Town & Country
Body Style
Minivan
Generation
RT
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
Town & Country 4.0 V6 Automatic
Engine Configuration
V
Power (hp)
254 hp
Power (kW)
187 kW
Torque
351 Nm (259 lb-ft)
Top speed
219 km/h (136 mph)
0–60 mph
8.2 seconds
0–100 km/h
8.7 seconds
Displacement
3,952 cc

Dimensions

Length
5,142 mm (202.4 in)
Width
1,952 mm (76.9 in)
Height
1,750 mm (68.9 in)
Wheelbase
3,078 mm (121.2 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
4,100 rpm
Engine Fluids
Engine Oil, Volume
5.2 litres
Transmission Fluid, Volume
3.8 litres
Engine Coolant, Volume
15.4 litres
Engine Configuration
Bore
96 mm (3.8 in)
Stroke
91 mm (3.6 in)
Compression Ratio
10.3 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Belt
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Multi-Point) Fuel Injection
Camshaft Type
OHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
Automatic, 6-speed

Fuel

General
Tank Volume
75 litres
Emission
Emission Standard
Euro 5

Brakes

Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Dimensions & Weight

Exterior

Track, Front
1,663 mm (65.5 in)
Track, Rear
1,645 mm (64.8 in)
Turning Circle
11.9 m
Ground Clearance
154 mm (6.1 in)

Interior

Head Room, Front
1,011 mm (39.8 in)
Head Room, Rear
996 - 1,008 mm (39.2 - 39.7 in)
Head Room, Third Row
963 mm (37.9 in)
Leg Room, Front
1,031 mm (40.6 in)
Leg Room, Rear
922 mm (36.3 in)
Leg Room, Third Row
808 mm (31.8 in)
Shoulder Room, Front
1,600 mm (63.0 in)
Shoulder Room, Rear
1,643 mm (64.7 in)
Shoulder Room, Third Row
1,575 mm (62.0 in)

Weight

Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
MPV

Equipment

Side Mirrors
Folding
Electrical
Heated
Yes
Windows
Window Lifts, Front
Powered
Other Equipment
Sunroof
Optional
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)

Lights

Main Beam
Halogen
Low Beam
Halogen
Fog Lights
Yes

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Connectivity
Radio
Yes
Media Format
  • CD
  • DVD
  • MP3
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
Optional

Seats

Front Seats
Power Seat, Driver
Yes
Power Seat, Passenger
Yes
Heated Seats
Yes
Second Seat Row
Collapsible
Yes
Features
Heated Seats
Third/Fourth Seat Row
Third Seat Row
Yes
Colour & Material
Upholstery
Leather

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
915 litres
Width, Between Wheel Arches
1,245 mm (49.0 in)
Height
1,172 mm (46.1 in)

Features

Comfort Features

Cameras: Camera Position
Rear

Other Features

GPS
Optional

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes
IIHS
Test Year
2014
Small Overlap Front: Driver Side
Poor
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good
Latch Ease of Use
Acceptable

Airbags

Feature
Frontal Airbag
Side Chest Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Minivan
British Classification
Large MPV
Australian Classification
People Mover
European Segment
M-Segment
Car.info Classification
Large MPV
