2010 Ford Focus CC

United StatesGasolineFWDConvertible

Specifications

Vehicle Details

Year
2010
Make
Ford
Model
Focus
Variant
CC
Body Style
Convertible
Generation
DA3/DB3 Facelift
Seats
4
Doors
2
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic
  • Manual, 4
  • 5-speed

Powertrain

Engine Name
2.0
Engine Configuration
Inline
Power (hp)
145 hp
Power (kW)
107 kW
Torque
185 Nm (136 lb-ft)
Top speed
208 km/h (129 mph)
0–60 mph
9.8 seconds (estimated)
0–100 km/h
10.3 seconds
Displacement
1,999 cc

Dimensions

Length
4,509 mm (177.5 in)
Width
1,834 mm (72.2 in)
Height
1,456 mm (57.3 in)
Wheelbase
2,640 mm (103.9 in)
Curb weight
1,450 kg (3,197 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
4,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 5W-20
  • 5W-30
Engine Configuration
Bore
87.5 mm (3.4 in)
Stroke
83.1 mm (3.3 in)
Compression Ratio
10.8 :1
Engine Configuration
Inline
Naturally Aspirated
Yes
Synchronization
Timing Chain
Type of Combustion Engine
Piston

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 4
  • 5-speed

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
55 litres
Emission
Emission Standard
  • Euro 4
  • Euro 5
Fuel Consumption NEDC
City
10.6 litres / 100 km
Highway
5.7 litres / 100 km
Combined
7.5 litres / 100 km
Emission NEDC
CO₂, Combined
179 g/km

Dimensions & Weight

Exterior

Track, Front
1,535 mm (60.4 in)
Track, Rear
1,531 mm (60.3 in)
Turning Circle
10.9 m
Ground Clearance
155 mm (6.1 in)

Interior

Head Room, Front
1,005 mm (39.6 in)

Weight

Gross Weight
1930 – 1950 kg (4,255 – 4,299 lb)
Max Trailer Load, braked 12%
1250 – 1350 kg (2,756 – 2,976 lb)
Max Trailer Load, unbraked
750 kg (1,653 lb)
Cargo Capacity
469 – 500 kg (1,034 – 1,102 lb)
Max Roof Load
0 kg (0 lb)

Exterior

Chassis & Body

Chassis
Chassis
Coupé-Cabriolet
Doors
Front Doors
Conventional
Platform
Ford Motor Company
C1 Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Heated Washer Nozzles
Optional
Windscreen Wipers: Connector type, Front
Side Lock
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Heated Windows
Optional
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Windows › Window Lifts, Features
Pinch Protection
Optional
One-touch up/down
Driver
Windows › Window Lifts, Features › Pinch Protection
Driver
Optional
Passenger
Optional
Windows › Heated Windows
Front
Optional
Other Equipment
Sunroof
Optional
Normal Roof
Yes
Antenna
Whip
Windblocker
Optional
Mud Flaps
Optional
Other Equipment › Sunroof
Tinted Glass
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Fog Lights
Optional
Special Features
Main Beam Assist
Optional
Headlight Washers
Optional
Headlight Range Adjustment
Optional

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Optional
Number of Bolts
5 pcs
Bolt Distance
108
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
63.4
Tightening Torque
130 Nm
Rim Colour
Silver
Rim Type
Disc Wheel
Spare Wheel
Optional
Spare Wheel
Full-size
Optional
Temporary
Optional
Spare Wheel › Full-size
Steel
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Controls
  • Buttons
  • Rotary Dials
Connectivity
Radio
  • AM
  • FM
  • RDS
Bluetooth
Optional
Phone Preparation
Optional
Connectivity › Radio
DAB
Optional
Connectivity › Media Format
CD
Yes
DVD
Optional
Memory Card Reader
Optional
MP3
Optional
Connectivity › Media Format › Memory Card Reader
SD
Optional
Connectivity › Media Inputs
AUX
Yes
USB
Optional
Connectivity › Media Inputs › USB
USB-A
Optional
Connectivity › Bluetooth
Phone
Optional
Audio
Optional
Displays
Center Display
5 - 7"
Equalizer
Optional
Displays › Center Display
Touchscreen
Optional
Buttons
Optional
Speakers
Total Number of Speakers
6 pcs
Interior Storage › Storage Compartments
Glove Compartment
Light
Armrest Hatch
Optional
Back Pocket
Yes
Sunglass Compartment
Optional
Coin Holder
Yes
Card Holder
Yes
Door
  • Driver Side
  • Passenger Side
Interior Storage › Storage Compartments › Glove Compartment
Cooled
Optional
Interior Storage › Storage Compartments › Armrest Hatch
Front
Optional
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Guide Light
Entry Guard
Ambient Light
Optional
Lights › Guide Light
Footwell
Optional
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
12V Outlet
Front
230V Outlet
Optional
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Make-up Mirror
Make-up Light
Optional
Other Equipment › 230V Outlet
Front
Optional
Other Equipment › Carpets
Front
Optional
Rear
Optional
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Electro-hydraulic
Adjustments
  • Tilt
  • Telescope
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Media
Yes
Multifunction Steering Wheel › Media
Channels
Yes
Volume
Buttons

Trunk

Rear Trunk
Yes
Carpet
Optional
Light
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
534 litres
Volume (Roof Folded)
248 litres
Depth
912 mm (35.9 in)
Width, Between Wheel Arches
924 mm (36.4 in)
Carpet
Rubber/Rug
Optional

Design

Interior Decor Colour
Black
Accent
Aluminium
Pedals
Standard
Pedals
Aluminium
Optional

Seats

Front Seats › Adjustments, Driver
Seat Height
Yes
Backrest Angle
Optional
Lumbar Support
Optional
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Height
Optional
Backrest Angle
Optional
Lumbar Support
Optional
Headrest, Height
Manual
Front Seats
Power Seat, Driver
Optional
Heated Seats
Optional
Armrest
Optional
Type of Seat
Sport Seats
Front Seats › Heated Seats
Cushion
Optional
Front Seats › Heated Seats › Cushion
Backrest
Optional
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
From Trunk
Split Fold Ratio
60/40
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Yes

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Optional
Parking Heater
Optional
Cameras
Optional
Rear Camera Preparation
Yes
Voice Control
Optional
Cameras
Rear
Optional
Voice Control
Media
Optional
Navigation
Optional
Phone
Optional

Other Features

GPS
Optional
GPS Preparation
Yes
Horn
Dual Note
GPS
SD-Card
Optional
GPS › SD-Card
DVD
Optional
CD
Optional

Accessories

Tire Repair Kit
Yes
Warning Triangle
Optional
First Aid Kit
Optional
Trunk Modules
Optional
Bicycle Holder
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Rain Sensors
Optional
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote

Safety Testing

General
Test Year
2004
Adult Occupant
5/5 stars
Child Occupant
4/5 stars
Pedestrian
2/4 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Optional

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Right
Passenger Seat
in Front of

Car Classification

American Classification
Compact Car
British Classification
Small Family Car
Australian Classification
Small Car
European Segment
C-Segment
Car.info Classification
Medium Family Car

Spare Parts BETA

Bulb Types
Low Beam
  • D1S (xenon)
  • H7
Main Beam
H1
Fog Light, Front
H11
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Positioning-/Parking Lights, Rear
W2.1×9.5d (W5W)
Rear/Brake Light
  • BA15s (P21W)
  • W2.1×9.5d (W5W)
Reversing Light
BA15s (P21W)
Turn Indicators, Front
BA15s (P21W)
Turn Indicators, Side
W2.1×9.5d (WY5W)
Turn Indicators, Rear
BAU15s (PY21W)
Make-up Mirrors
W2.1×9.5d (W5W)
Read Light
W2.1×9.5d (W5W)
Trunk
W2.1×9.5d (W5W)
License Plate Light
W2.1×9.5d (W5W)
