2010 Saab 9-3 ePower

SwedenElectricFWDWagon

Specifications

Vehicle Details

Year
2010
Make
Saab
Model
9-3
Variant
ePower
Body Style
Wagon
Generation
YS3F Facelift
Seats
5
Doors
5
Fuel
Electric
Drivetrain
FWD
Transmission
Automatic (Fixed)

Powertrain

Engine Name
ePower 35.5 kWh
Engine Configuration
Electric
Power (hp)
184 hp
Power (kW)
135 kW
Top speed
160 km/h (99 mph)
0–60 mph
6.8 seconds (estimated)
0–100 km/h
7.1 seconds
Electric range
200 km (124 mi)
Battery
35.5 kWh

Dimensions

Length
4,670 mm (183.9 in)
Width
1,762 mm (69.4 in)
Height
1,498 mm (59.0 in)
Wheelbase
2,675 mm (105.3 in)

Engine & Performance

Engine

Engine Fluids
Synthetic Oil (viscosity)
  • 0W-30
  • 0W-40
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
  • 15W-40
  • 20W-40
Configuration Combustion
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Fuel Injection
Camshaft Type
DOHC
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Electronic
Yes
Configuration Electric
Type of Electric Car
Electric
Front Engines
Yes
Battery Capacity, Gross
35.5 kWh
Configuration Electric › Front Engines
Power (kW)
135 kW
Number of Engines
1

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Leather
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
302 - 314 mm (11.9 - 12.4 in)
Cooling
Ventilated
Rear Brakes
Diameter
292 mm (11.5 in)

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Energy & Range

Emission
Emission Standard
Euro 6
Fuel Consumption NEDC
City
0 litres / 100 km
Highway
0 litres / 100 km
Combined
0 litres / 100 km
Electric Range
200 km (124 mi)
Emission NEDC
CO₂, Combined
0 g/km

Dimensions & Weight

Exterior

Width, with Mirrors
2,038 mm (80.2 in)
Track, Front
1,524 mm (60.0 in)
Track, Rear
1,506 mm (59.3 in)
Overhang, Front
981 mm (38.6 in)
Overhang, Rear
1,014 mm (39.9 in)
Turning Circle
10.8 m
Ground Clearance
150 mm (5.9 in)

Interior

Head Room, Front
985 mm (38.8 in)
Head Room, Rear
987 mm (38.9 in)
Leg Room, Front
1,053 mm (41.5 in)
Leg Room, Rear
892 mm (35.1 in)
Hip Room, Front
1,456 mm (57.3 in)
Hip Room, Rear
1,458 mm (57.4 in)
Shoulder Room, Front
1,414 mm (55.7 in)
Shoulder Room, Rear
1,400 mm (55.1 in)

Weight

Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon
Pillars
A-D
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional
Platform
General Motors Platforms
Epsilon Platform (Epsilon I)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
User Memory
Optional
Heated
Yes
Automatic Tilt Down
Optional
House Colour
Same as Car
Mirror Shape, Driver side
Aspheric
Windscreen Wipers
Speed Sensing Intermittent
Yes
Intermittent Control
Yes
Rear Wiper
Yes
Rear Washer System
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered (Safety Lock)
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Safety Glass
Yes
Windows › Window Lifts, Features
Pinch Protection
  • Driver
  • Passenger
  • Rear
One-touch up/down
  • Driver
  • Passenger
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Windows › Safety Glass
Front
Laminated
Side
Tempered
Rear
Tempered
Other Equipment
Sunroof
Optional
Tow Hook
  • Front
  • Rear
Roof Railing
Yes
Antenna
Whip
Mud Flaps
Optional
Electric
Optional
Other Equipment › Sunroof
Sun Blind
Optional
Other Equipment › Sunroof › Sun Blind
Tinted Glass
Optional
Other Equipment › Roof Railing
Roof Railing Type
Raised Rails (Open Rails)
Colour
Black
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Rear Lights
Halogen
Fog Lights
Yes
Special Features
Automatic Headlight Activation
Fog Lights
Rear
Halogen
Special Features
Adaptive Headlights
Optional
Headlight Washers
Optional
Headlight Range Adjustment
Yes

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
5 pcs
Bolt Distance
110
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
65.1
Fastening Type
Lug Bolts
Tightening Torque
110 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Shape
Square
Climate Control
Climate Control
Automatic
Number of Climate Zones
2
Air Condition
Yes
Micro Filter
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Controls
Buttons
Connectivity
Radio
  • AM
  • FM
Bluetooth
Optional
Connectivity › Media Format
CD
Optional
DVD
Optional
MP3
Optional
WMA
Optional
Connectivity › Media Inputs
AUX
Optional
Connectivity › Media Inputs › AUX
Front
Optional
Connectivity › Bluetooth
Phone
Optional
Displays
Center Display
6.5"
Displays › Center Display
Touchscreen
Optional
Speakers
Total Number of Speakers
7 - 10 pcs
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
  • Light
  • Lockable (Manual)
Armrest Hatch
Front
Back Pocket
Yes
Sunglass Compartment
Optional
Coin Holder
Optional
Card Holder
Optional
Under Seats
Optional
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage › Storage Compartments › Under Seats
Front
Optional
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
  • Front
  • Rear
Guide Light
  • Entry Guard
  • Bottom of the Doors
Lights › Guide Light
Footwell
Optional
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
Front
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger
Other Equipment › Clock
Digital
Instrument Cluster
Other Equipment › 12V Outlet
Rear
Optional
Trunk
Optional
Other Equipment › Carpets
Front
Optional
Rear
Optional
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Yes
Power Steering
Hydraulic
Adjustments
  • Tilt
  • Telescope
Material
Leather
Colour
Black
Steering Mechanism
Rack and Pinion
Multifunction Steering Wheel
Menu Navigation
Buttons
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Channels
Yes
Volume
Buttons
Mute Audio
Yes

Trunk

Rear Trunk
Yes
Cover
Foldable
Barrier Net/Grid
Optional
Carpet
Optional
Flat Surface
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
419 litres
Volume, Back Seat Collapsed
1,287 litres
Depth
1,010 mm (39.8 in)
Depth, Back Seat Collapsed
1,777 mm (70.0 in)
Width
993 mm (39.1 in)
Opening Width
1,331 mm (52.4 in)
Carpet
Rubber
Optional

Design

Transmission Knob Material
Leather
Pedals
Standard
Pedals
Aluminium
Optional

Seats

Colour & Material
Upholstery
  • Leatherette
  • Textile
Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Yes
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Armrest
Middle
Front Seats › Heated Seats
Cushion
Optional
Front Seats › Heated Seats › Cushion
Backrest
Optional
Second Seat Row
Armrest
Yes
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40
Second Seat Row › Headrests
Outer Seats
Height Adjustment

Features

Comfort Features

Cruise Control
Optional
Speed Limiter
Optional
Parking Heater
Optional
Cameras
Optional
Rear Camera Preparation
Optional
Parking Heater
Cabin Heater
Optional
Parking Heater › Cabin Heater
Engine Heater
Optional
Remote
Optional
Timer
Optional
Cameras
Rear
Optional

Other Features

GPS
Optional
Horn
Dual Note

Accessories

Tool Kit and Jack
Yes
Tire Repair Kit
Optional
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional
Trunk Modules
Optional
Bicycle Holder
Optional
Coat Hanger
Optional

Safety & Security

Airbags

Other Airbags
Pedestrian Airbag
No
Middle Airbag
No
Door-mounted Airbags
No
Seat Belt Airbag
No
Seat Cushion
No
Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Curtain Airbag
Center Airbag
Airbag cut-off Switch

Seat Belt

Height Adjustable Retractor
Yes
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Optional

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes

Sensors

Parking Sensors
Optional
Light Sensor
Yes
Rain Sensors
Yes
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Remote
Immobiliser
Electronic
Yes
Anti-theft Alarm
Interior Monitoring
Yes

Safety Testing

General
Test Year
2002
Adult Occupant
5/5 stars
Pedestrian
1/4 stars

Child Protection

Feature
Isofix
Integrated Child Seat

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Left Side Casing of Window
Yes
Pillar
B-Pillar, Right

Car Classification

American Classification
Entry-Level Luxury Car
British Classification
Compact Executive Car
Australian Classification
Medium Car
European Segment
D-Segment
Car.info Classification
Medium Executive Car

Similar wagons

Suggested vehicles
