2010 Volkswagen Sagitar

GermanyGasolineFWDSedan

Photos

Specifications

Vehicle Details

Year
2010
Make
Volkswagen
Model
Sagitar
Body Style
Sedan
Generation
1st Generation (Type 9L)
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic Dual-clutch
  • Manual, 5
  • 7-speed

Powertrain

Engine Name
1.4 TSI
Engine Configuration
Inline
Power (hp)
131 hp
Power (kW)
96 kW
Torque
220 Nm (162 lb-ft)
Top speed
203 km/h (126 mph)
0–60 mph
9.7 seconds (estimated)
0–100 km/h
10.2 seconds
Displacement
1,390 cc

Dimensions

Length
4,544 mm (178.9 in)
Width
1,760 mm (69.3 in)
Height
1,461 mm (57.5 in)
Wheelbase
2,578 mm (101.5 in)
Curb weight
1,405 kg (3,097 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,000 rpm
Rev. at Max Torque
1,750 - 3,500 rpm
Engine Configuration
Bore
76.5 mm (3.0 in)
Stroke
75.6 mm (3.0 in)
Engine Configuration
Inline
Turbocharger
Single-turbo
Synchronization
Timing Belt
Engine Placement
Front
Engine Mount
Transversally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Cast Iron
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling

Transmission & Drivetrain

Transmission
  • Automatic Dual-clutch
  • Manual, 5
  • 7-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Solid

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
Front
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
55 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption NEDC
Combined
6.4 – 6.5 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,539 mm (60.6 in)
Track, Rear
1,528 mm (60.2 in)
Ground Clearance
125 mm (4.9 in)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
Volkswagen Group
A Platform (PQ35)

Interior

Steering Wheel

Power Steering
Electro-mechanical
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
527 litres

Seats

Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Yes
Second Seat Row › Headrests › Centre Seat
Height Adjustment
Yes
