2011 Cadillac CTS

United StatesGasolineAWDCoupe

Photos

Specifications

Vehicle Details

Year
2011
Make
Cadillac
Model
CTS
Body Style
Coupe
Generation
2nd Generation
Seats
4
Doors
2
Fuel
Gasoline
Drivetrain
AWD
Transmission
Automatic (Electrohydraulic), 6-speed

Powertrain

Engine Name
CTS4 Coupé (EU) 3.6 V6 AWD Hydra-Matic
Engine Configuration
V
Power (hp)
311 hp
Power (kW)
229 kW
Torque
370 Nm (273 lb-ft)
Top speed
225 km/h (140 mph)
0–60 mph
6.4 seconds (estimated)
0–100 km/h
6.7 seconds
Displacement
3,564 cc

Dimensions

Length
4,789 mm (188.5 in)
Width
1,883 mm (74.1 in)
Height
1,422 mm (56.0 in)
Wheelbase
2,880 mm (113.4 in)
Curb weight
2,040 kg (4,497 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,300 rpm
Rev. at Max Torque
5,200 rpm
Redline
7,000 rpm
Engine Fluids
Engine Oil, Volume
5.7 litres
Engine Coolant, Volume
10.3 litres
Engine Configuration
Bore
94 mm (3.7 in)
Stroke
85.6 mm (3.4 in)
Compression Ratio
11.3 :1
Engine Configuration
V-Engine
Naturally Aspirated
Yes
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
80,000 km / 4 years
Spark Plug
160,000 km (99,419 mi)
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Transmission, Fluid
160,000 km (99,419 mi)
Transmission, Fluid Filter
160,000 km (99,419 mi)
Interior Filter
40,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic (Electrohydraulic), 6-speed
Gear Selector
Stick
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
4.02 :1
2nd Gear
2.36 :1
3rd Gear
1.53 :1
4th Gear
1.15 :1
5th Gear
0.85 :1
6th Gear
0.67 :1
Final Drive
3.23 :1
Reverse
3.06 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
315 - 346 mm (12.4 - 13.6 in)
Width
32 mm (1.3 in)
Cooling
Ventilated
Rear Brakes
Diameter
315 - 340 mm (12.4 - 13.4 in)
Width
26 mm (1.0 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
Yes
Suspension, Front
Independent
Double Wishbone
Suspension, Rear
Independent
Multi-link
Anti-roll Bar
Front
33 mm (1.3 in)
Rear
19 - 20 mm (0.7 - 0.8 in)

Fuel

General
Tank Volume
68 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 5
Emission Class
F
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption NEDC
City
16.1 litres / 100 km
Highway
7.9 litres / 100 km
Combined
10.9 litres / 100 km
Emission NEDC
CO₂, City
377 g/km
CO₂, Highway
185 g/km
CO₂, Combined
255 g/km

Dimensions & Weight

Exterior

Track, Front
1,570 mm (61.8 in)
Track, Rear
1,595 mm (62.8 in)
Turning Circle
11 m

Interior

Head Room, Front
937 mm (36.9 in)
Head Room, Rear
879 mm (34.6 in)
Leg Room, Front
1,078 mm (42.4 in)
Leg Room, Rear
890 mm (35.0 in)
Hip Room, Front
1,385 mm (54.5 in)
Hip Room, Rear
1,212 mm (47.7 in)
Shoulder Room, Front
1,424 mm (56.1 in)
Shoulder Room, Rear
1,294 mm (50.9 in)

Weight

Max Roof Load
75 kg (165 lb)
Weight Distribution, front
52 %
Weight Distribution, rear
48 %

Exterior

Chassis & Body

Chassis
Chassis
Coupé
Pillars
A-C
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Door Handles
Handle-less
Platform
General Motors Platforms
Sigma Platform (Sigma II)

Equipment

Other Equipment
Normal Roof
Yes

Interior

Steering Wheel

Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
344 litres

Seats

Second Seat Row
Number of Seats
2
Type of Seat
Adult

Other

Car Classification

European Segment
S-Segment
