2011 Ford F-Series F-150

United StatesGasoline4WDPickup

Photos

Specifications

Vehicle Details

Year
2011
Make
Ford
Model
F-Series
Variant
F-150
Body Style
Pickup
Generation
12th Generation (P415)
Seats
2
Doors
2
Fuel
Gasoline
Drivetrain
4WD
Transmission
Automatic, 6-speed

Powertrain

Engine Name
3.5 V6 Ecoboost 4x4 Automatic
Engine Configuration
V
Power (hp)
370 hp
Power (kW)
272 kW
Torque
570 Nm (420 lb-ft)
Displacement
3,496 cc

Dimensions

Length
5,415 mm (213.2 in)
Width
2,017 mm (79.4 in)
Height
1,900 mm (74.8 in)
Wheelbase
3,198 mm (125.9 in)

Engine & Performance

Engine

Engine Fluids
Synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Configuration
Engine Configuration
V-Engine
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection

Transmission & Drivetrain

Transmission
Automatic, 6-speed

Fuel

General › Fuel Cap Position
Rear
Left
General
Lockable Fuel Cap
Yes

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated
Rear Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Leaf
Suspension, Front
Independent
Double Wishbone

Dimensions & Weight

Exterior

Width, with Mirrors
2,464 mm (97.0 in)
Overhang, Front
973 mm (38.3 in)
Overhang, Rear
1,245 mm (49.0 in)
Ground Clearance
224 - 208 mm (8.8 - 8.2 in)

Interior

Head Room, Front
1,041 mm (41.0 in)
Leg Room, Front
1,052 mm (41.4 in)
Hip Room, Front
1,537 mm (60.5 in)
Shoulder Room, Front
1,692 mm (66.6 in)

Exterior

Chassis & Body

Chassis
Chassis
Pickup
Pillars
A-B
Chassis Construction
Body-on-Frame
Protective Moldings
Optional
Doors
Front Doors
Conventional
Door Handles
Pull-out
Platform
Ford Motor Company
P Platform (P2)

Equipment

Side Mirrors
Mirror Type
Conventional
User Memory
Optional
Heated
Optional
Turning Signal
Optional
Side Mirrors › Mirror Type
Driver side
Optional
Windscreen Wipers
Speed Sensing Intermittent
Optional
Intermittent Control
Yes
Windows › Window Lifts, Features
One-touch up/down
Optional
Windows › Window Lifts, Features › One-touch up/down
Driver
Optional
Passenger
Optional
Windows
Heated Windows
Optional
Heat-Insulating Windows
  • Front
  • First Row
  • Rear
Tinted Windows
Yes
Rear Windows, Sliding
Optional
Windows › Heated Windows
Rear
Optional
Windows › Tinted Windows
Rear Window
Optional
Other Equipment
Sunroof
Optional
Tow Hook
Front
Antenna
Roof-integrated
Windblocker
Optional
Side Steps
Optional
Other Equipment › Sunroof
Sun Blind
Optional
Other Equipment › Tow Hook
Rear
Optional
Other Equipment › Side Steps
Deployable
Optional
Stationary
Optional

Lights

Rear Lights
Halogen
Fog Lights
Optional
Special Features
Automatic Headlight Activation
Optional
Headlight Range Adjustment
Manual (Electric)

Colour

Non-painted
Bumper (Front | Rear)
Door Handles
Non-painted

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Number of Bolts
6 pcs
Bolt Distance
135
Nut/Bolt Dimensions
M14x2
Central Bore (CB), front
87.1
Fastening Type
Lug Nuts
Tightening Torque
204 Nm
Rim Type
Disc Wheel
Spare Wheel
Full-size (Steel)

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Voltmeter
Analogue
Oil Pressure
Analogue
Coolant Temperature
Analogue
Odometer Limit
1,000,000 km/miles
Compass
Optional
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Shape
Square
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Optional
Controls
  • Buttons
  • Rotary Dials
Connectivity
Radio
  • AM
  • FM
App-Connect
Optional
Connectivity › Radio
XM
Optional
HD Radio
Optional
Connectivity › Media Format
CD
Optional
Memory Card Reader
Optional
MP3
Optional
Connectivity › Media Format › Memory Card Reader
SD
Optional
Connectivity › Media Inputs
AUX
Optional
USB
Optional
Connectivity › Media Inputs › USB
Armrest Hatch/Mid-console
Optional
USB-A
Optional
Displays
Center Display
4.2 - 8"
Center Display Controls
  • Buttons
  • Rotary Dial
Displays › Center Display Controls
Touchscreen
Optional
Speakers
Subwoofer
Optional
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Compass
Optional
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Front
Sunglass Compartment
Optional
Door
  • Driver Side
  • Passenger Side
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
4
Interior Storage › Cup Holders › Front
Placement
  • Middle Console
  • Driver Door
  • Passenger Door
Lights
Read Light
Front
Guide Light
  • Entry Guard
  • Bottom of the Doors
Ambient Light
Optional
Other Equipment
Make-up Mirror
Passenger Side
Clock
Yes
12V Outlet
Front
110V Outlet
Optional
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Make-up Mirror
Driver Side
Optional
Make-up Light
Optional
Other Equipment › Clock
Digital
Center Display
Other Equipment › 110V Outlet
Rear
Optional
Other Equipment › Carpets
Front
Optional
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Optional
Power Steering
Electric
Number of Spokes
4
Steering Mechanism
Rack and Pinion
Adjustments
Tilt
Yes
Telescope
Optional
User Memory
Optional

Seats

Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Optional
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Seat Height
Optional
Backrest Angle
Yes
Lumbar Support
Optional
Headrest, Height
Manual
Front Seats
Power Seat, Driver
Optional
Power Seat, Passenger
Optional
Heated Seats
Optional
Ventilated Seats
Optional
Front Seats › Heated Seats
Cushion
Optional
Front Seats › Heated Seats › Cushion
Backrest
Optional
Front Seats › Ventilated Seats
Driver
Optional
Passenger
Optional

Design

Pedals
Standard
Pedals
Blue
Optional
Brown
Optional
Red
Optional

Features

Comfort Features

Keyless Entry
Optional
Remote Engine Start
Optional
Garage Remote Control
Optional
Cruise Control
Optional
Parking Heater
Optional
Parking Heater Preparation
Optional
Cameras
Optional
Voice Control
Optional
Parking Heater
Engine Heater
Optional
Cameras
Rear
Optional
Voice Control
Media
Optional
Phone
Optional

Other Features

GPS
Optional
GPS Preparation
Optional
Horn
Dual Note
GPS
USB
Optional
GPS › USB
CD
Optional

Accessories

Tool Kit and Jack
Optional
Tire Repair Kit
Optional
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional
Trunk Modules
Optional
Bicycle Holder
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
Front Seats

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes
Hill Descent Control (HDC)
Optional
Electronic Stability Control (ESC)
Roll Stability Control (RSC)
Yes

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes

Sensors

Parking Sensors
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Optional
Child Safety Locks
Manual
Immobiliser
Electronic
Yes
Child Safety Locks
Electrical
Optional

Safety Testing

General
Not Tested by Euro NCAP
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Other

Car Classification

American Classification
Full-Size Pickup Truck
British Classification
Pick-up
Australian Classification
Pickup
European Segment
J-Segment JE-Segment
Car.info Classification
Pickup

Awards

North American
Truck of the Year
2009
