2011 Honda Fit Shuttle Hybrid

JapanHybrid GasolineFWDWagon

Photos

Specifications

Vehicle Details

Year
2011
Make
Honda
Model
Fit
Variant
Shuttle Hybrid
Body Style
Wagon
Generation
1st Generation
Seats
5
Doors
5
Fuel
Hybrid Gasoline
Drivetrain
FWD
Transmission
Automatic (Continuously variable)

Powertrain

Engine Name
Hybrid CVT
Engine Configuration
Inline
Power (hp)
88 hp
Power (kW)
65 kW
Torque
121 Nm (89 lb-ft)
Displacement
1,339 cc

Dimensions

Length
4,410 mm (173.6 in)
Width
1,695 mm (66.7 in)
Height
1,540 mm (60.6 in)
Wheelbase
2,500 mm (98.4 in)
Curb weight
1,200 kg (2,646 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,800 rpm
Rev. at Max Torque
4,500 rpm
Configuration Combustion
Bore
73 mm (2.9 in)
Stroke
80 mm (3.1 in)
Compression Ratio
10.8 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Configuration Electric
Type of Electric Car
Hybrid
Electric Engine Power
10 kW
Electric Engine Horsepower (Metric)
14 hp
Torque
121 Nm (89 lb-ft)
Rear Engines
Yes
AC Charge Type
Single-phase
Charging Plugs
Type 2
Configuration Electric › Rear Engines
Electric Power (kW)
10 kW
Horsepower
14 hp
RPM at Max Power
1,500 rpm
Number of Engines
1

Transmission & Drivetrain

Transmission
Automatic (Continuously variable)

Fuel

General
Tank Volume
40 litres
WLTP Consumption
Combined (l/100km)
4 litres / 100 km
Emission WLTP
CO
1.15 mg/km
NMHC
0.01 mg/km
NOx
0.01 mg/km
Emission NEDC
CO₂, Combined
89.3 - 92.9 g/km

Dimensions & Weight

Exterior

Track, Front
1,480 mm (58.3 in)
Track, Rear
1,470 mm (57.9 in)
Turning Circle
10.2 m
Ground Clearance
150 mm (5.9 in)

Interior

Head Room, Front
990 mm (39.0 in)
Head Room, Rear
970 mm (38.2 in)
Knee Room, Front
500 mm (19.7 in)
Knee Room, Rear
455 mm (17.9 in)
Hip Room, Rear
1,260 mm (49.6 in)
Shoulder Room, Rear
1,415 mm (55.7 in)

Weight

Max Roof Load
75 kg (165 lb)
Max Towbar Download
45 kg (99 lb)

Exterior

Chassis & Body

Chassis
Chassis
Station Wagon

Interior

Trunk

Rear Trunk
Yes
