2011 Kia Picanto

South KoreaLpgFWDHatchback

Photos

Specifications

Vehicle Details

Year
2011
Make
Kia
Model
Picanto
Body Style
Hatchback
Generation
TA
Seats
5
Doors
5
Fuel
Lpg
Drivetrain
FWD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.0 LPG Manual
Engine Configuration
Inline
Power (hp)
67 hp
Power (kW)
49 kW
Torque
94 Nm (69 lb-ft)
Top speed
156 km/h (97 mph)
0–60 mph
13.6 seconds (estimated)
0–100 km/h
14.3 seconds
Displacement
998 cc

Dimensions

Length
3,595 mm (141.5 in)
Width
1,595 mm (62.8 in)
Height
1,480 mm (58.3 in)
Wheelbase
2,385 mm (93.9 in)
Curb weight
880 kg (1,940 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,400 rpm
Rev. at Max Torque
3,400 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 5W-20
  • 5W-30
  • 10W-30
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 10W-30
  • 15W-40
  • 20W-50
Engine Oil, Volume
2.9 litres
Engine Configuration
Engine Configuration
Inline
Synchronization
Timing Chain
Service Intervals
Air Filter
45,000 km / 3 years
Fuel Filter
60,000 km / 4 years
Spark Plug
60,000 km / 4 years
Brake Fluid
30,000 km / 2 years
Oil Change & Engine Filter
15,000 km / 1 years
Engine Coolant
30,000 km / 2 years
Interior Filter
15,000 km / 1 years

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Brakes Material
Steel
Brake Caliper Colour
Grey

Suspensions

Suspension, Front
Independent
MacPherson Strut
Spring, Rear
Torsion
Suspension, Rear
Semi-dependent
Yes

Fuel

General
Tank Volume
35 litres
Emission
Emission Standard
Euro 5
Fuel Consumption NEDC
City
7.4 litres / 100 km
Highway
5 litres / 100 km
Combined
6.1 litres / 100 km
City (LPG)
8.3 litres / 100 km
Highway (LPG)
7.1 litres / 100 km
Combined (LPG)
7.7 litres / 100 km
Emission NEDC
CO₂, Combined
107 g/km
CO₂, Combined (LPG)
99 g/km

Dimensions & Weight

Exterior

Track, Front
1,415 mm (55.7 in)
Track, Rear
1,418 mm (55.8 in)
Overhang, Front
700 mm (27.6 in)
Overhang, Rear
510 mm (20.1 in)
Turning Circle
9.8 m
Ground Clearance
141 - 142 mm (5.6 - 5.6 in)

Interior

Head Room, Front
1,020 mm (40.2 in)

Weight

Gross Weight
1,340 kg (2,954 lb)
Max Trailer Load, braked 12%
700 kg (1,543 lb)
Max Trailer Load, unbraked
400 kg (882 lb)
Cargo Capacity
460 kg (1,014 lb)
Max Roof Load
60 kg (132 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Heated
Optional
Turning Signal
Optional
Windscreen Wipers
Rear Wiper
Optional
Rear Washer System
Optional
Windows
Heated Windows
Rear
Heat-Insulating Windows
Optional
Windows › Heat-Insulating Windows
Front
Optional
Other Equipment
Normal Roof
Yes
Spoiler
Optional
Antenna
Whip
Other Equipment › Spoiler
Fixed
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Daytime Running Light
Halogen
Fog Lights
Optional
Special Features
Headlight Range Adjustment
Manual

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
54.1
Fastening Type
Lug Nuts
Tightening Torque
88 - 107 Nm
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Optional
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Air Condition
Optional
Pollen Filter
Optional
Connectivity
Radio
Optional
Connectivity › Radio
AM
Optional
FM
Optional
CD
Optional
MP3
Optional
WMA
Optional
Connectivity › Media Inputs
AUX
Optional
USB
Optional
Speakers
Total Number of Speakers
2 - 6 pcs
Tweeters
2 pcs
Midrange Speakers
2 - 4 pcs
Interior Storage › Storage Compartments
Glove Compartment
Yes
Back Pocket
Optional
Card Holder
Yes
Under Seats
Optional
Door
  • Driver Side
  • Passenger Side
Interior Storage › Storage Compartments › Under Seats
Front
Optional
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Lights
Read Light
Front
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
12V Outlet
Front
Carpets
Yes
Other Equipment › Carpets
Material
Textile

Steering Wheel

Multifunction Steering Wheel
Optional
Power Steering
Yes
Adjustments
Tilt
Colour
Black
Steering Mechanism
Rack and Pinion
Channels
Optional
Volume
Optional
Mute Audio
Optional

Trunk

Rear Trunk
Yes
Release Button
Yes
Cover
Optional
Flat Surface
Yes
Light
Yes
Rear Trunk
Volume
200 litres
Volume, Back Seat Collapsed
870 litres
Depth
450 mm (17.7 in)
Depth, Back Seat Collapsed
1,110 mm (43.7 in)
Width
1,000 mm (39.4 in)
Height
770 mm (30.3 in)
Cover
Foldable
Optional

Design

Entry Guard Material
Plastic

Seats

Colour & Material
Upholstery
Textile
Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Optional
Backrest Angle
Yes
Headrest, Height
Optional
Front Seats
Number of Driver Seat Adjustments, Total
4
Number of Passenger Seat Adjustments, Total
4
Heated Seats
Optional
Front Seats › Adjustments, Passenger
Seat Depth
Yes
Backrest Angle
Yes
Headrest, Height
Optional
Front Seats › Heated Seats
Cushion
Optional
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Split Fold Ratio
60/40

Features

Other Features

GPS
Optional
Start & Stop
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Optional
Hill Start Assist (HSA)
Optional

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Optional
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Other Features

Immobiliser
Yes
Central Locking
Optional
Child Safety Locks
Yes
Active Headrests
Optional
Central Locking
Remote
Optional

Safety Testing

General
Test Year
2011
Adult Occupant
86 %
Child Occupant
83 %
Vulnerable Road Users
47 %
Safety Assist
43 %
Overall
4/5 stars
Overall Score
34.26
ANCAP Safety Rating
5
ASEAN NCAP
Test Year
2013
Adult Occupant
4/5 stars
Child Occupant
4/5 stars
Child Occupant
73 %
Adult Occupant
Frontal Offset
15.12
Side Impact
14.14
Pole
2
Safety Assist
Seat Belt Reminders
3

Airbags

Feature
Frontal Airbag
Side Head Airbag
Knee Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
7 years
12V Battery
2 years
Paintwork
150,000 km / 5 years
Rust Damage
150,000 km / 7 years
Roadside Assistance
Yes
Roadside Assistance
Roadside Assistance
150,000 km / 7 years

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Left
Trunk
on Floor

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
City Car
Australian Classification
Microcar
European Segment
A-Segment
Car.info Classification
Mini Car

Spare Parts BETA

Bulb Types
Low Beam
  • H4
  • H7
Main Beam
  • H4
  • H7
Datyime Running Light
BA15s (P21W)
Fog Light, Front
H27W/2
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BA15s (P21W)
License Plate Light
W2.1×9.5d (W5W)
