2012 Honda Insight

JapanHybrid GasolineFWDHatchback

Photos

Specifications

Vehicle Details

Year
2012
Make
Honda
Model
Insight
Body Style
Hatchback
Generation
ZE2 Facelift
Seats
5
Doors
5
Fuel
Hybrid Gasoline
Drivetrain
FWD
Transmission
Automatic (Continuously variable)

Powertrain

Engine Name
1.3 IMA CVT
Engine Configuration
Inline
Power (hp)
102 hp
Power (kW)
75 kW
Torque
199 Nm (147 lb-ft)
Top speed
182 km/h (113 mph)
0–60 mph
11.8 seconds (estimated)
0–100 km/h
12.4 seconds
Battery
0.58 kWh
Displacement
1,339 cc

Dimensions

Length
4,390 mm (172.8 in)
Width
1,695 mm (66.7 in)
Height
1,425 mm (56.1 in)
Wheelbase
2,545 mm (100.2 in)
Curb weight
1,176 kg (2,593 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,800 rpm
Rev. at Max Torque
4,500 rpm
Engine Fluids
Synthetic Oil (viscosity)
0W-20
Engine Oil, Volume
3.6 litres
Configuration Combustion
Bore
73 mm (2.9 in)
Stroke
80 mm (3.1 in)
Compression Ratio
10.8 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Engine Mount
Transversally
Configuration Electric
Type of Electric Car
Hybrid
Front Engines
Yes
Battery Capacity, Gross
0.58 kWh
Configuration Electric › Front Engines
Power (kW)
10 kW
Number of Engines
1

Transmission & Drivetrain

Transmission
Automatic (Continuously variable)

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
40 litres
Emission
Emission Standard
Euro 5
Fuel Consumption NEDC
City
4.5 litres / 100 km
Highway
4.2 litres / 100 km
Combined
4.3 litres / 100 km
Emission NEDC
CO₂, Combined
99 g/km

Dimensions & Weight

Exterior

Track, Front
1,495 mm (58.9 in)
Track, Rear
1,475 mm (58.1 in)
Turning Circle
11.1 m
Ground Clearance
145 mm (5.7 in)

Interior

Head Room, Front
984 mm (38.7 in)
Head Room, Rear
891 mm (35.1 in)
Leg Room, Front
1,074 mm (42.3 in)
Leg Room, Rear
851 mm (33.5 in)
Hip Room, Front
1,310 mm (51.6 in)
Hip Room, Rear
1,238 mm (48.7 in)
Shoulder Room, Front
1,338 mm (52.7 in)
Shoulder Room, Rear
1,279 mm (50.4 in)

Weight

Gross Weight
1,650 kg (3,638 lb)
Cargo Capacity
474 kg (1,045 lb)
Max Roof Load
50 kg (110 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback

Equipment

Side Mirrors
Folding
Electrical
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Tinted Windows
  • Second Row
  • Rear Window
Other Equipment
Normal Roof
Yes

Lights

Fog Lights
Optional

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
56.1
Fastening Type
Lug Nuts
Tightening Torque
108 Nm

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Tachometer
Digital
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Automatic
Air Condition
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
Yes
Media Format
CD
Media Inputs
USB
Bluetooth
Optional
Connectivity › Media Inputs
AUX
Optional
Displays
Center Display
Optional

Steering Wheel

Multifunction Steering Wheel
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
339 litres

Seats

Second Seat Row
Collapsible
Yes

Features

Comfort Features

Cruise Control
Yes

Other Features

GPS
Optional
Start & Stop
Yes

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Rain Sensors
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes

Safety Testing

General
Test Year
2009
Adult Occupant
90 %
Child Occupant
74 %
Vulnerable Road Users
76 %
Safety Assist
86 %
Overall
5/5 stars
Overall Score
36.39
ANCAP Safety Rating
5
Adult Occupant
Frontal Offset
15.54
Side Impact
15.85
Pole
2
Safety Assist
Seat Belt Reminders
3
Rollover
Rollover Resistance
11.3 %
Rollver
4/5 stars
IIHS
Test Year
2010
Moderate Overlap Front
Good
Side
Good
Roof Strength
Good
Head Restraints & Seats
Good

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Side Pelvis Airbag
Knee Airbag
Airbag cut-off Switch

Seat Belt

Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Engine Compartment, Bulkhead
Centre
Left Side Casing of Window
Yes
Pillar
  • B-Pillar, Left
  • B-Pillar, Right

Car Classification

American Classification
Compact Car
British Classification
Small Family Car
Australian Classification
Small Car
European Segment
C-Segment
Car.info Classification
Medium Family Car
