2012 Kia Rio

South KoreaGasolineFWDSedan

Photos

Specifications

Vehicle Details

Year
2012
Make
Kia
Model
Rio
Body Style
Sedan
Generation
UB
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
FWD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.2 CVVT Manual
Engine Configuration
Inline
Power (hp)
86 hp
Power (kW)
63 kW
Torque
120 Nm (89 lb-ft)
Top speed
172 km/h (107 mph)
0–60 mph
12.5 seconds (estimated)
0–100 km/h
13.1 seconds
Displacement
1,248 cc

Dimensions

Length
4,050 mm (159.4 in)
Width
1,720 mm (67.7 in)
Height
1,460 mm (57.5 in)
Wheelbase
2,570 mm (101.2 in)
Curb weight
1,029 kg (2,269 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
4,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 5W-20
  • 5W-30
  • 10W-30
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 10W-30
  • 15W-40
  • 20W-50
Engine Oil, Volume
3.5 litres
Engine Configuration
Bore
71 mm (2.8 in)
Stroke
78.8 mm (3.1 in)
Compression Ratio
10.5 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Fuel Injection
Service Intervals
Air Filter
60,000 km / 4 years
Spark Plug
60,000 km / 4 years
Engine Coolant
30,000 km / 2 years
Interior Filter
30,000 km / 2 years

Brakes

Parking Brake
Manual
Lever
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Diameter
256 - 280 mm (10.1 - 11.0 in)
Cooling
Ventilated
Rear Brakes
Diameter
262 mm (10.3 in)

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut

Fuel

General
Tank Volume
43 litres
General › Fuel Cap Position
Rear
Left
Emission
Emission Standard
Euro 6
Fuel Consumption NEDC
City
6.3 litres / 100 km
Highway
4.4 litres / 100 km
Combined
5.1 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,520 mm (59.8 in)
Track, Rear
1,530 mm (60.2 in)
Turning Circle
10.4 m
Ground Clearance
140 mm (5.5 in)

Weight

Gross Weight
1,560 kg (3,439 lb)
Max Trailer Load, braked 12%
900 kg (1,984 lb)
Max Trailer Load, unbraked
450 kg (992 lb)
Cargo Capacity
531 kg (1,171 lb)
Max Roof Load
70 kg (154 lb)
Max Towbar Download
50 kg (110 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
Hyundai-Kia Platforms
Small Automobile Platform (PB)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Mirror Shape, Driver side
Convex
Mirror Shape, Passenger side
Convex
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Other Equipment
Normal Roof
Yes
Mud Flaps
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Yes
Fog Lights
Rear
Halogen
Special Features
Headlight Range Adjustment
Manual (Electric)

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
54.1
Fastening Type
Lug Nuts
Tightening Torque
88 - 107 Nm

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Coolant Temperature
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Number of Climate Zones
1
Air Condition
Yes
Micro Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
Yes
Media Format
  • CD
  • MP3
  • WMA
Media Inputs
USB
Connectivity › Media Inputs
AUX
Yes
Rear-view Mirror
Adjustments
Mechanical
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
  • Light
  • Lockable (Manual)
Armrest Hatch
Optional
Back Pocket
Yes
Sunglass Compartment
Optional
Coin Holder
Optional
Card Holder
Yes
Under Seats
Optional
Door
  • Driver Side
  • Passenger Side
  • Rear
Interior Storage › Storage Compartments › Armrest Hatch
Front
Optional
Interior Storage › Storage Compartments › Under Seats
Front
Optional
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Lights
Read Light
Front
Guide Light
Entry Guard
Lights › Read Light
Rear
Optional
Other Equipment
Driver Side
Optional
Clock
Yes
12V Outlet
Front
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Driver Side
Passenger Side
Optional
Other Equipment › Clock
Digital
Instrument Cluster
Other Equipment › 12V Outlet
Rear
Optional
Trunk
Optional
Other Equipment › Carpets
Front
Optional
Rear
Optional
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Yes

Seats

Colour & Material
Upholstery
Textile

Trunk

Rear Trunk
Yes
Light
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
290 litres
Volume, Back Seat Collapsed
925 litres

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Optional
Speed Limiter
Optional
Cameras
Optional
Cameras
Rear
Optional

Other Features

GPS
Optional
Start & Stop
Optional
Horn
Dual Note

Accessories

Tool Kit and Jack
Yes
Tire Repair Kit
Optional
Compressor
Optional
Fire Extinguisher
Optional
Warning Triangle
Optional
First Aid Kit
Optional
Trunk Modules
Optional
Bicycle Holder
Optional
Coat Hanger
Optional

Safety & Security

Seat Belt

Height Adjustable Retractor
Yes
Rear Centre Seat Belt
Yes
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter
Height Adjustable Retractor
Manual
Yes
Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Sensors

Parking Sensors
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Child Safety Locks
Manual
Immobiliser
Electronic
Yes

Safety Testing

General
Test Year
2011
Adult Occupant
92 %
Child Occupant
84 %
Vulnerable Road Users
46 %
Safety Assist
86 %
Overall
5/5 stars
Overall Score
34.99
ANCAP Safety Rating
5
Adult Occupant
Frontal Offset
14.99
Side Impact
15
Pole
2
Safety Assist
Seat Belt Reminders
3
Frontal Crash
Front Driver Side
4/5 stars
Front Passenger Side
4/5 stars
Side Crash
Side Crash, Driver
4/5 stars
Side Crash, Passenger
5/5 stars
Front Seat Rating
4/5 stars
Combined Rear Seat Rating
5/5 stars
Side Barrier Rating
4/5 stars
Overall Side Pole Star Rating
5/5 stars
Rollover
Rollover Resistance
11.6 %
Overall Safety Rating
4/5 stars
Overall Frontal Rating
4/5 stars
Overall Side Rating
5/5 stars
Rollver
4/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
7 years
12V Battery
2 years
Paintwork
150,000 km / 5 years
Rust Damage
150,000 km / 7 years
Roadside Assistance
Yes
Roadside Assistance
Roadside Assistance
150,000 km / 7 years

Identification

VIN Location
Left Side Casing of Window
Yes
Right Side Casing of Window
Yes
Pillar
  • B-Pillar, Left
  • B-Pillar, Right
Passenger Seat
in Front of
Front of Hood
Yes

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
Supermini
Australian Classification
Light Car
European Segment
B-Segment
Car.info Classification
Small Family Car

Spare Parts BETA

Bulb Types
Low Beam
H4
Main Beam
H4
Datyime Running Light
BA15s (P21W)
Fog Light, Front
H8
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Rear
BAU15s (PY21W)
License Plate Light
W2.1×9.5d (W5W)
