2013 Chevrolet Camaro ZL1

United StatesGasolineRWDConvertible

Photos

Specifications

Vehicle Details

Year
2013
Make
Chevrolet
Model
Camaro
Variant
ZL1
Body Style
Convertible
Generation
5th Generation
Seats
4
Doors
2
Fuel
Gasoline
Drivetrain
RWD
Transmission
  • Automatic
  • Manual, 6-speed

Powertrain

Engine Name
ZL1 Convertible
Engine Configuration
V
Power (hp)
587 hp
Power (kW)
432 kW
Torque
754 Nm (556 lb-ft)
Top speed
250 km/h (155 mph)
0–60 mph
4 seconds
0–100 km/h
4.3 seconds
Displacement
6,162 cc

Dimensions

Length
4,836 mm (190.4 in)
Width
1,918 mm (75.5 in)
Height
1,389 mm (54.7 in)
Wheelbase
2,852 mm (112.3 in)
Curb weight
1,961 kg (4,323 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,100 rpm
Rev. at Max Torque
3,800 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Oil, Volume
9.5 litres
Engine Configuration
Bore
103.25 mm (4.1 in)
Stroke
92 mm (3.6 in)
Compression Ratio
9.1 :1
Engine Configuration
V-Engine
Supercharger
Yes
Synchronization
Timing Chain
Engine Placement
Front
Type of Combustion Engine
Piston
Fuel System
Electronic Fuel Injection
Camshaft Type
OHC

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 6-speed
Gear Ratio
1st Gear
2.66 :1
2nd Gear
1.78 :1
3rd Gear
1.3 :1
4th Gear
1 :1
5th Gear
0.8 :1
6th Gear
0.63 :1
Final Drive
3.73 :1
Reverse
2.9 :1

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Aluminium
Front Brakes
Diameter
370 mm (14.6 in)
Width
32 mm (1.3 in)
Cooling
Ventilated
Rear Brakes
Diameter
365 mm (14.4 in)
Width
28 mm (1.1 in)
Cooling
Ventilated

Fuel

General
Tank Volume
72 litres
Fuel Consumption NEDC
City
16.8 litres / 100 km
Highway
12.4 litres / 100 km
Combined
14.7 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,618 mm (63.7 in)
Track, Rear
1,628 mm (64.1 in)
Turning Circle
11.5 m
Ground Clearance
102 mm (4.0 in)

Interior

Head Room, Front
960 mm (37.8 in)
Head Room, Rear
908 mm (35.7 in)
Leg Room, Front
1,077 mm (42.4 in)
Leg Room, Rear
760 mm (29.9 in)
Shoulder Room, Front
1,444 mm (56.9 in)
Shoulder Room, Rear
1,079 mm (42.5 in)

Weight

Max Roof Load
0 kg (0 lb)

Exterior

Chassis & Body

Chassis
Chassis
Cabriolet Soft-top
Pillars
A
Doors
Front Doors
Conventional
Platform
General Motors Platforms
Zeta Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Automatic Anti-glare
Driver side
Heated
Yes
House Colour
Same as Car
Windscreen Wipers
Number of Wiper Speeds
2
Windscreen Wipers: Connector type, Front
Hook
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Other Equipment
Spoiler
Fixed
Antenna
Glass-integrated
Air Intakes
1-port
Number of Exhaust Pipes
2

Lights

Main Beam
Xenon
Low Beam
Xenon
Rear Lights
Halogen
Daytime Running Light
Halogen
Fog Lights
Yes
Fog Lights
Front
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
120
Nut/Bolt Dimensions
M14x1.5
Central Bore (CB), front
67.1
Fastening Type
Lug Nuts
Tightening Torque
190 Nm
Number of Spokes
5
Rim Colour
Silver

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Manual
Number of Climate Zones
1
Air Condition
Yes
Micro Filter
Yes
Outside Temperature Indicator
Yes
Number of Vents, Front
7 pcs
Connectivity
Radio
  • AM
  • FM
  • XM
Media Format
  • CD
  • MP3
Media Inputs
USB
Bluetooth
Phone
Connectivity › Media Inputs
AUX
Yes
Displays
Center Display
7"
Speakers
Total Number of Speakers
6 - 9 pcs
Tweeters
6 - 9 pcs
Rear-view Mirror
Anti-glare
Automatic
Interior Storage › Storage Compartments
Glove Compartment
Yes
Armrest Hatch
Yes
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Lights
Read Light
  • Front
  • Rear
Other Equipment
12V Outlet
Front

Steering Wheel

Multifunction Steering Wheel
Yes
Adjustments
  • Tilt
  • Telescope
Material
Leather
Colour
Black
Steering Ratio
16.1 :1
Answer Phone
Yes
Volume
Yes
Mute Audio
Yes
Multifunction Steering Wheel
Menu Navigation
Yes

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
290 litres
Volume (Roof Folded)
222 litres

Design

Interior Decor Material
Plastic
Interior Decor Colour
Black
Colour
  • Beige
  • Black
  • Grey
Colour
Brown
Optional
Red
Optional

Seats

Front Seats
Power Seat, Driver
Yes
Power Seat, Passenger
Yes
Heated Seats
Yes
Type of Seat
Sport Seats
Second Seat Row
Number of Seats
2

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Optional
Cruise Control
Yes
Cameras: Camera Position
Rear

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Feature
Seat Belt Reminder
Belt Pretensioner

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Differential Lock
Limited Slip Differential (LSD)

Sensors

Parking Sensors
Rear
Light Sensor
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes
Emergency Call
Yes

Safety Testing

General
Not Tested by Euro NCAP
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Curtain Airbag
Airbag cut-off Switch

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Left Side Casing of Window
Yes

Car Classification

Australian Classification
Sports Car
European Segment
S-Segment
Car.info Classification
Sports Car

Awards

World
Car Design of the Year
2010
