2013 Ford Fiesta

United StatesGasoline2WDHatchback

Specifications

Vehicle Details

Year
2013
Make
Ford
Model
Fiesta
Body Style
Hatchback
Generation
JA8 Facelift
Seats
2
Doors
3
Fuel
Gasoline
Drivetrain
2WD
Transmission
Manual, 5-speed

Powertrain

Engine Name
1.0 Manual
Engine Configuration
Inline
Power (hp)
80 hp
Power (kW)
59 kW
Torque
105 Nm (77 lb-ft)
Displacement
998 cc

Dimensions

Length
3,969 mm (156.3 in)
Width
1,722 mm (67.8 in)
Height
1,495 mm (58.9 in)
Wheelbase
2,489 mm (98.0 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,300 rpm
Rev. at Max Torque
4,100 rpm
Engine Configuration
Bore
71.9 mm (2.8 in)
Stroke
81.9 mm (3.2 in)
Compression Ratio
12 :1
Engine Configuration
Inline
Naturally Aspirated
Yes
Synchronization
Timing Belt
Type of Combustion Engine
Piston
Service Intervals
Timing Interval
240,000 km / 10 years
Air Filter
60,000 km / 3 years
Spark Plug
60,000 km / 3 years
Brake Fluid
3 years
Oil Change & Engine Filter
20,000 km / 1 years
Engine Coolant
160,000 km / 6 years
Interior Filter
20,000 km / 1 years
Accessory Belt
160,000 km (99,419 mi)

Fuel

General › Fuel Cap Position
Rear
Left

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Leather
Optional
Front Brakes
Disc Brakes
Rear Brakes
Drum Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Dimensions & Weight

Exterior

Track, Front
1,475 mm (58.1 in)
Track, Rear
1,460 mm (57.5 in)
Turning Circle
10.1 m
Ground Clearance
140 mm (5.5 in)

Interior

Head Room, Front
991 mm (39.0 in)
Leg Room, Front
1,111 mm (43.7 in)
Shoulder Room, Front
1,350 mm (53.1 in)

Weight

Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-B
Chassis Construction
Unibody
Body Material
Steel
Roof Material
Steel
Doors
Front Doors
Conventional
Platform
Ford Motor Company
B3 Platform (Global B Platform)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Turning Signal
Yes
House Colour
Same as Car
Windscreen Wipers
Rear Wiper
Yes
Rear Washer System
Yes
Windows
Window Lifts, Front
Powered
Heated Windows
Optional
Heat-Insulating Windows
  • Front
  • First Row
Windows › Heated Windows
Front
Optional
Other Equipment
Spoiler
Fixed
Antenna
Whip
Mud Flaps
Optional
Other Equipment › Mud Flaps
Front
Optional
Rear
Optional

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Optional
Special Features
Come Home/Leaving Lights
Special Features
Main Beam Assist
Optional

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
108
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
63.4
Tightening Torque
135 Nm
Rim Type
Disc Wheel
Spare Wheel
Optional
Spare Wheel
Full-size
Optional
Spare Wheel › Full-size
Steel
Optional

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Analogue
Odometer Limit
1,000,000 km/miles
Instrument Cluster › Trip Computer
Display
Yes
Instrument Cluster › Trip Computer › Display
Type
Monochrome
Shape
Square
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Number of Vents, Front
4 pcs
Controls
  • Buttons
  • Rotary Dials
Connectivity
Radio
Optional
Radio Preparation
Yes
App-Connect
Apple CarPlay
Bluetooth
Optional
Connectivity › Radio
AM
Optional
FM
Optional
RDS
Optional
Connectivity › Media Format
CD
Optional
Memory Card Reader
Optional
MP3
Optional
Connectivity › Media Format › Memory Card Reader
SD
Optional
Connectivity › Media Inputs
AUX
Optional
USB
Optional
Connectivity › Media Inputs › USB
USB-A
Optional
Connectivity › Bluetooth
Phone
Optional
Audio
Optional
Displays
Center Display
8.8 - 12.7"
Displays › Center Display Controls
Buttons
Optional
Displays › Center Display Controls › Buttons
Buttons Middle Console
10 pcs
Speakers
Total Number of Speakers
4 pcs
Interior Storage › Storage Compartments
Glove Compartment
  • Light
  • Lockable (Manual)
Armrest Hatch
Optional
Back Pocket
Yes
Door
  • Driver Side
  • Passenger Side
Interior Storage › Storage Compartments › Armrest Hatch
Front
Optional
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Interior Storage › Cup Holders › Front
Placement
Middle Console
Lights
Read Light
Front
Guide Light
Entry Guard
Ambient Light
Optional
Lights › Guide Light
Footwell
Optional
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Yes
12V Outlet
Front
Carpets
Optional
Ashtray
Optional
Cigarette Lighter
Optional
Other Equipment › Clock
Digital
Instrument Cluster
Other Equipment › Ashtray
Front
Optional

Steering Wheel

Multifunction Steering Wheel
Optional
Power Steering
Electro-mechanical
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Automatic Open
Key Button
Carpet
Optional
Flat Surface
Yes
Light
Yes
Hatch Opening Type
From Roof
Rear Trunk
Depth
1,296 mm (51.0 in)
Width
1,000 mm (39.4 in)
Height
806 mm (31.7 in)
Carpet
Rubber
Optional
Rubber/Rug
Optional

Design

Pedals
Standard
Pedals
Aluminium
Optional

Seats

Colour & Material
Stitching Colour
White
Front Seats › Adjustments, Driver
Seat Depth
Manual
Seat Height
Manual
Lumbar Support
Optional
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Adjustments, Passenger
Seat Depth
Manual
Seat Height
Optional
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Heated Seats
Optional
Armrest
Optional
Front Seats › Heated Seats
Cushion
Optional

Features

Comfort Features

Keyless Entry
Optional
Keyless Start
Optional
Cruise Control
Optional
Cameras
Optional
Rear Camera Preparation
Yes
Voice Control
Optional
Cameras
Rear
Optional
Voice Control
Media
Optional
Phone
Optional

Other Features

GPS
Optional
GPS Preparation
Yes
Smartphone App
Optional
Horn
Dual Note
GPS
SD-Card
Optional

Accessories

Tire Repair Kit
Yes
Warning Triangle
Optional
First Aid Kit
Optional
Trunk Modules
Optional
Bicycle Holder
Optional

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Four-channel
Traction Control System (TCS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes
Brake Pad Wear Indicator
Yes

Sensors

Parking Sensors
Optional
Light Sensor
Optional
Rain Sensors
Optional
Parking Sensors
Front
Optional
Rear
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Optional
Central Locking
Remote
Emergency Call
Optional

Safety Testing

General
Test Year
2008
Adult Occupant
5/5 stars
Child Occupant
4/5 stars
Pedestrian
3/4 stars
ASEAN NCAP
Test Year
2011
Adult Occupant
5/5 stars
Adult Occupant, Points
15.73
Child Occupant
66 %
Frontal Crash
Front Driver Side
5/5 stars
Front Passenger Side
4/5 stars
Side Crash
Side Crash, Driver
4/5 stars
Side Crash, Passenger
5/5 stars
Front Seat Rating
4/5 stars
Combined Rear Seat Rating
5/5 stars
Side Barrier Rating
5/5 stars
Overall Side Pole Star Rating
4/5 stars
Rollover
Rollover Resistance
14.3 %
Overall Safety Rating
4/5 stars
Overall Frontal Rating
4/5 stars
Overall Side Rating
5/5 stars
Rollver
4/5 stars

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Airbag cut-off Switch

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Right
Passenger Seat
in Front of

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
Supermini
Australian Classification
Light Car
European Segment
B-Segment
Car.info Classification
Small Family Car

Spare Parts BETA

Bulb Types
Low Beam
H7
Main Beam
H15
Datyime Running Light
H15
Fog Light, Front
H11
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Positioning-/Parking Lights, Rear
W2.1×9.5d (W5W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Side
W2.1×9.5d (WY5W)
Turn Indicators, Rear
BAU15s (PY21W)
Read Light
W2.1×9.5d (W5W)
Trunk
W2.1×9.5d (W5W)
License Plate Light
W2.1×9.5d (W5W)
