2013 Ford Fiesta

United StatesGasoline4WDHatchback

Photos

Specifications

Vehicle Details

Year
2013
Make
Ford
Model
Fiesta
Body Style
Hatchback
Generation
JA8
Seats
5
Doors
3
Fuel
Gasoline
Drivetrain
4WD
Transmission
Automatic (Sequential), 6-speed

Powertrain

Engine Name
RS WRC Sequential
Engine Configuration
Inline
Power (hp)
304 hp
Power (kW)
224 kW
Torque
450 Nm (332 lb-ft)
Displacement
1,596 cc

Dimensions

Length
3,950 mm (155.5 in)
Width
1,722 mm (67.8 in)
Height
1,481 mm (58.3 in)
Wheelbase
2,489 mm (98.0 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,000 rpm
Rev. at Max Torque
4,000 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 0W-20
  • 0W-30
  • 5W-20
  • 5W-30
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
  • 15W-40
  • 20W-40
  • 20W-50
Engine Configuration
Bore
83 mm (3.3 in)
Stroke
73.9 mm (2.9 in)
Engine Configuration
Inline
Turbocharger
Yes
Service Intervals
Brake Fluid
2 years
Oil Change & Engine Filter
20,000 km / 1 years

Fuel

General › Fuel Cap Position
Rear
Left

Brakes

Parking Brake
Manual
Lever
Parking Brake › Manual
Material
Plastic
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Sports Suspension
Yes
Suspension, Front
Independent
MacPherson Strut

Dimensions & Weight

Exterior

Track, Front
1,493 mm (58.8 in)
Track, Rear
1,480 mm (58.3 in)
Turning Circle
10.2 m
Ground Clearance
168 mm (6.6 in)

Interior

Head Room, Front
1,010 mm (39.8 in)

Weight

Max Roof Load
50 kg (110 lb)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Chassis Construction
Unibody
Doors
Front Doors
Conventional
Platform
Ford Motor Company
B3 Platform (Global B Platform)

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Heated
Yes
Turning Signal
Yes
House Colour
Same as Car
Windows
Heated Windows
Rear
Heat-Insulating Windows
  • Front
  • First Row
  • Second Row
  • Rear
Tinted Windows
Optional
Windows › Heated Windows
Front
Optional
Windows › Tinted Windows
Second Row
Optional
Rear Window
Optional
Other Equipment
Normal Roof
Yes
Spoiler
Fixed

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Yes
Fog Lights
Front
Halogen

Colour

Colour
White

Rims & Tires

Number of Bolts
4 pcs
Bolt Distance
108
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
63.4
Fastening Type
Lug Nuts
Tightening Torque
110 Nm
Rim Material
Alloy
Rim Colour
White
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Speedometer
Analogue
Tachometer
Analogue
Odometer Limit
1,000,000 km/miles
Climate Control
Number of Vents, Front
4 pcs
Lights
Read Light
Front

Steering Wheel

Power Steering
Electric
Adjustments
  • Tilt
  • Telescope
Number of Spokes
3
Material
Sueded Microfiber
Colour
Black
Steering Mechanism
Rack and Pinion

Trunk

Rear Trunk
Yes
Flat Surface
Yes
Hatch Opening Type
From Roof
Rear Trunk
Volume
295 litres
Volume, Back Seat Collapsed
979 litres
Depth
580 mm (22.8 in)
Depth, Back Seat Collapsed
1,300 mm (51.2 in)
Width
1,000 mm (39.4 in)
Height
820 mm (32.3 in)

Design

Transmission Knob Material
Plastic
Pedals
Sport
Colour
Black

Seats

Colour & Material
Upholstery
  • Suede Microfiber
  • Textile
Seat Colour
Black
Stitching Colour
Black
Front Seats
Type of Seat
Sport Seats

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
Seat Belt Colour
Black
Feature
Seat Belt Reminder
Belt Pretensioner
Belt Load Limiter

Assist Systems

Electronic Stability Control (ESC)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Safety Testing

General
Test Year
2008
Adult Occupant
5/5 stars
Child Occupant
4/5 stars
Pedestrian
3/4 stars
Overall Score
34.45
ANCAP Safety Rating
5
ASEAN NCAP
Test Year
2011
Adult Occupant
5/5 stars
Adult Occupant, Points
15.73
Child Occupant
66 %
Adult Occupant
Frontal Offset
14.9
Side Impact
15.55
Pole
2
Safety Assist
Seat Belt Reminders
2

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag
Knee Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Pillar
B-Pillar, Right
Passenger Seat
Yes

Car Classification

American Classification
Subcompact Car/Economy Car
British Classification
Supermini
Australian Classification
Light Car
European Segment
B-Segment
Car.info Classification
Small Family Car

Spare Parts BETA

Bulb Types
Low Beam
H7
Main Beam
  • H1
  • H15
Fog Light, Front
H11
Fog Light, Rear
BA15s (P21W)
Positioning-/Parking Lights, Front
W2.1×9.5d (W5W)
Positioning-/Parking Lights, Rear
W2.1×9.5d (W5W)
Rear/Brake Light
BAY15d (P21/5W)
Reversing Light
W2.1×9.5d (W16W)
Turn Indicators, Front
BAU15s (PY21W)
Turn Indicators, Side
W2.1×9.5d (WY5W)
Turn Indicators, Rear
BAU15s (PY21W)
Read Light
W2.1×9.5d (W5W)
Trunk
W2.1×9.5d (W5W)
License Plate Light
W2.1×9.5d (W5W)
