2013 Jeep Compass

United StatesGasolineFWDSUV

Photos

Specifications

Vehicle Details

Year
2013
Make
Jeep
Model
Compass
Body Style
SUV
Generation
MK Facelift
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic Continuously variable
  • Manual, 5
  • 6-speed

Powertrain

Engine Name
2.0
Engine Configuration
Inline
Power (hp)
156 hp
Power (kW)
115 kW
Torque
190 Nm (140 lb-ft)
Top speed
183 km/h (114 mph)
0–60 mph
10.1 seconds (estimated)
0–100 km/h
10.6 seconds
Displacement
1,998 cc

Dimensions

Length
4,465 mm (175.8 in)
Width
1,812 mm (71.3 in)
Height
1,651 mm (65.0 in)
Wheelbase
2,365 mm (93.1 in)
Curb weight
1,449 kg (3,194 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
6,300 rpm
Rev. at Max Torque
5,100 rpm
Engine Fluids
Synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Semi-synthetic Oil (viscosity)
  • 5W-30
  • 5W-40
  • 10W-30
  • 10W-40
Engine Oil, Volume
4.7 litres
Engine Configuration
Bore
86 mm (3.4 in)
Stroke
86 mm (3.4 in)
Compression Ratio
10.5 :1
Engine Configuration
Inline
Synchronization
Timing Chain
Type of Combustion Engine
Piston

Transmission & Drivetrain

Transmission
  • Automatic Continuously variable
  • Manual, 5
  • 6-speed

Brakes

Parking Brake
Manual
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Front Brakes
Cooling
Ventilated

Fuel

General
Tank Volume
51 litres
Emission
Emission Standard
Euro 5
Emission Class
E
Fuel Consumption NEDC
City
10.2 – 11.1 litres / 100 km
Highway
6.1 – 6.7 litres / 100 km
Combined
7.6 – 8.3 litres / 100 km
Emission NEDC
CO₂, Combined
175 – 194 g/km

Dimensions & Weight

Exterior

Track, Front
1,520 mm (59.8 in)
Track, Rear
1,520 mm (59.8 in)
Turning Circle
10.8 m
Ground Clearance
200 mm (7.9 in)

Interior

Head Room, Front
1,034 mm (40.7 in)
Head Room, Rear
1,013 mm (39.9 in)
Leg Room, Front
1,031 mm (40.6 in)
Leg Room, Rear
1,001 mm (39.4 in)
Hip Room, Front
1,328 mm (52.3 in)
Hip Room, Rear
1,295 mm (51.0 in)
Shoulder Room, Front
1,387 mm (54.6 in)
Shoulder Room, Rear
1,372 mm (54.0 in)

Weight

Gross Weight
2,010 kg (4,431 lb)
Max Trailer Load, braked 12%
1,200 kg (2,646 lb)
Max Trailer Load, unbraked
450 kg (992 lb)
Cargo Capacity
475 – 561 kg (1,047 – 1,237 lb)
Max Roof Load
68 kg (150 lb)
Max Towbar Download
60 kg (132 lb)

Exterior

Chassis & Body

Chassis
Chassis
SUV
Platform
Mitsubishi Platform
GS Platform

Equipment

Side Mirrors
Heated
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Other Equipment
Sunroof
Optional
Roof Railing
Yes
Other Equipment › Roof Railing
Roof Railing Type
Flush Rails (Closed Rails)

Lights

Main Beam
Halogen
Low Beam
Halogen
Fog Lights
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
114.3
Nut/Bolt Dimensions
M12x1.5
Central Bore (CB), front
67.1
Fastening Type
Lug Nuts
Tightening Torque
135 Nm

Interior

Equipment

Instrument Cluster
Trip Computer
Optional
Tachometer
Analogue
Climate Control
Air Condition
Yes
Pollen Filter
Yes
Outside Temperature Indicator
Yes
Climate Control › Air Condition
Refrigerant
R134A
Connectivity
Radio
Yes
Media Format
  • DVD
  • MP3
Bluetooth
Optional
Connectivity › Media Format
CD
Yes
USB
Optional
Displays
Center Display
Optional

Steering Wheel

Multifunction Steering Wheel
Optional

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
460 litres
Volume, Back Seat Collapsed
1,270 litres

Seats

Colour & Material
Upholstery
Textile
Front Seats
Power Seat, Driver
Optional
Second Seat Row
Collapsible
Yes

Features

Comfort Features

Cruise Control
Yes
Cruise Control
Rear
Optional

Other Features

GPS
Optional

Safety & Security

Assist Systems

Electronic Stability Control (ESC)
Yes
Hill Start Assist (HSA)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Electronic Brake Assist (BA/EBA)
Yes

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes

Safety Testing

General
Test Year
2012
Adult Occupant
61 %
Child Occupant
76 %
Vulnerable Road Users
23 %
Safety Assist
43 %
Overall
2/5 stars
Overall Score
29.21
ANCAP Safety Rating
4
Adult Occupant
Frontal Offset
11.21
Side Impact
16
Pole
2
Safety Assist
Seat Belt Reminders
0

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Side Head Airbag

Seat Belt

Belt Load Limiter
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Identification

VIN Location
Left Side Casing of Window
Yes
Driver Seat
Door
Passenger Seat
Door

Car Classification

American Classification
Compact SUV
British Classification
Compact SUV
Australian Classification
Medium SUV
European Segment
J-Segment JC-Segment
Car.info Classification
Medium SUV

Spare Parts BETA

Bulb Types
Low Beam
  • H11
  • HIR2
Main Beam
HIR2
Fog Light, Front
H11
Reversing Light
W3×16d (W21W)
Turn Indicators, Rear
WX3×16d (WY21W)
License Plate Light
W2.1×9.5d (W5W)
