2014 Brilliance H230 H220

ChinaGasolineFWDHatchback

Photos

Specifications

Vehicle Details

Year
2014
Make
Brilliance
Model
H230
Variant
H220
Body Style
Hatchback
Generation
1st Generation
Seats
5
Doors
5
Fuel
Gasoline
Drivetrain
FWD
Transmission
  • Automatic
  • Manual, 5
  • 6-speed

Powertrain

Engine Name
1.5
Engine Configuration
Inline
Power (hp)
105 hp
Power (kW)
77 kW
Torque
143 Nm (105 lb-ft)
Top speed
170 km/h (106 mph)
0–60 mph
11.7 seconds (estimated)
0–100 km/h
12.3 seconds
Displacement
1,498 cc

Dimensions

Length
4,190 mm (165.0 in)
Width
1,703 mm (67.0 in)
Height
1,482 mm (58.3 in)
Wheelbase
2,570 mm (101.2 in)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,800 rpm
Rev. at Max Torque
3,800 - 4,200 rpm
Engine Configuration
Bore
75 mm (3.0 in)
Stroke
84.8 mm (3.3 in)
Compression Ratio
10 :1
Engine Configuration
Inline

Transmission & Drivetrain

Transmission
  • Automatic
  • Manual, 5
  • 6-speed

Brakes

Parking Brake
Manual
Rear Brakes
Drum Brakes

Fuel

General
Tank Volume
42 litres
Emission
Emission Standard
Euro 4
Fuel Consumption NEDC
Combined
7 litres / 100 km

Dimensions & Weight

Exterior

Track, Front
1,465 mm (57.7 in)
Track, Rear
1,460 mm (57.5 in)
Overhang, Front
910 mm (35.8 in)
Overhang, Rear
710 mm (28.0 in)
Turning Circle
10 m
Ground Clearance
114 mm (4.5 in)

Interior

Shoulder Room, Rear
1,320 mm (52.0 in)
Head Room (est.), Rear
930 - 955 mm (36.6 - 37.6 in)
Leg Room (est.), Rear
830 - 880 mm (32.7 - 34.6 in)

Exterior

Chassis & Body

Chassis
Chassis
Hatchback
Pillars
A-C
Doors
Front Doors
Conventional
Rear Doors
Conventional

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
House Colour
Same as Car
Windscreen Wipers
Number of Wiper Speeds
2
Rear Wiper
Yes
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Other Equipment
Sunroof
Openable
Spoiler
Fixed
Antenna
Whip
Air Intakes
1-port
Number of Exhaust Pipes
1

Lights

Main Beam
Halogen
Low Beam
Halogen
Rear Lights
Halogen
Fog Lights
Yes
Fog Lights
Rear
Yes

Rims & Tires

Number of Bolts
5 pcs
Bolt Distance
100
Nut/Bolt Dimensions
M12x1.25
Central Bore (CB), front
54.1

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Speedometer
Analogue
Tachometer
Analogue
Fuel Gauge
Digital
Instrument Cluster › Trip Computer
Display
Yes
Climate Control
Climate Control
Manual
Air Condition
Yes
Number of Vents, Front
4 pcs
Connectivity
Radio
  • AM
  • FM
Media Format
CD
Connectivity › Media Inputs
AUX
Yes
USB
Yes
Connectivity › Media Inputs › USB
Number of Ports
1 pcs
Displays
Center Display
Yes
Speakers
Total Number of Speakers
4 - 6 pcs
Midrange Speakers
2 pcs
Rear-view Mirror
Seatbelt Warning Indicator
Yes
Interior Storage › Storage Compartments
Glove Compartment
Yes
Sunglass Compartment
Optional
Total Number of Compartments
8 pcs
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
4
Rear
2
Lights
Read Light
Front
Other Equipment
Driver Side
Optional

Steering Wheel

Power Steering
Yes
Adjustments
Tilt
Material
Leather
Colour
Black

Trunk

Rear Trunk
Yes
Rear Trunk
Volume
250 litres
Volume, Back Seat Collapsed
1,190 litres

Design

Interior Decor Material
Plastic
Interior Decor Colour
Black
Transmission Knob Material
Leather
Colour
Silver

Seats

Colour & Material
Upholstery
Textile
Seat Colour
Black
Stitching Colour
White
Front Seats › Adjustments, Driver
Seat Depth
Yes
Seat Height
Yes
Cushion Edge
Yes
Backrest Angle
Yes
Front Seats
Power Seat, Driver
Yes
Power Seat, Passenger
Yes

Features

Other Features

GPS
Optional

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
Yes
Rear Centre Seat Belt
Yes
Centre Rear Seat
Yes
Belt Pretensioner
  • Driver: Yes
  • Passenger: Yes
  • Rear: -

Brake Systems

Power Brakes
Yes
Anti-lock Braking System (ABS)
Yes
Electronic Brakeforce Distribution (EBD)
Yes

Sensors

Parking Sensors
Rear

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Central Locking
Yes
Child Safety Locks
Yes

Airbags

Feature
Frontal Airbag
Side Head Airbag
Curtain Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Car Classification

American Classification
Subcompact Car/Economy Car
European Segment
B-Segment
Car.info Classification
Small Family Car
