2014 Cadillac CTS

United StatesGasolineRWDSedan

Photos

Specifications

Vehicle Details

Year
2014
Make
Cadillac
Model
CTS
Body Style
Sedan
Generation
3rd Generation
Seats
5
Doors
4
Fuel
Gasoline
Drivetrain
RWD
Transmission
Automatic (Electrohydraulic), 6-speed

Powertrain

Engine Name
2.0 T Hydra-Matic
Engine Configuration
Inline
Power (hp)
276 hp
Power (kW)
203 kW
Torque
400 Nm (295 lb-ft)
Top speed
240 km/h (149 mph)
0–60 mph
6.3 seconds (estimated)
0–100 km/h
6.6 seconds
Displacement
1,998 cc

Dimensions

Length
4,966 mm (195.5 in)
Width
1,834 mm (72.2 in)
Height
1,438 mm (56.6 in)
Wheelbase
2,910 mm (114.6 in)
Curb weight
1,709 kg (3,768 lb)

Engine & Performance

Engine

Engine Specification
Rev. at Max Power
5,500 rpm
Rev. at Max Torque
1,700 - 5,500 rpm
Redline
7,000 rpm
Engine Fluids
Engine Oil, Volume
4.7 litres
Engine Coolant, Volume
8.5 litres
Engine Configuration
Bore
86 mm (3.4 in)
Stroke
86 mm (3.4 in)
Compression Ratio
9.5 :1
Engine Configuration
Inline
Turbocharger
Single-turbo
Synchronization
Timing Chain
Engine Placement
Front
Engine Mount
Longitudinally
Type of Combustion Engine
Piston
Fuel System
Electronic (Direct) Fuel Injection
Camshaft Type
DOHC
Engine Block
Aluminium
Engine Heads
Aluminium
Engine Cooling
Liquid Cooling
Service Intervals
Air Filter
72,000 km / 4 years
Spark Plug
96,000 km (59,652 mi)
Brake Fluid
240,000 km / 10 years
Oil Change & Engine Filter
1 years
Engine Coolant
240,000 km / 5 years
Transmission, Fluid
156,000 km (96,934 mi)
Transmission, Fluid Filter
156,000 km (96,934 mi)
Interior Filter
36,000 km / 2 years

Transmission & Drivetrain

Transmission
Automatic (Electrohydraulic), 6-speed
Gear Selector
  • Stick
  • Paddles
Gear Selector Location
Mid-Console
Gear Ratio
1st Gear
4.06 :1
2nd Gear
2.37 :1
3rd Gear
1.55 :1
4th Gear
1.16 :1
5th Gear
0.85 :1
6th Gear
0.67 :1
Final Drive
3.45 :1
Reverse
3.2 :1

Brakes

Parking Brake
Electric
Front Brakes
Disc Brakes
Rear Brakes
Disc Brakes
Brakes Material
Cast Iron
Front Brakes
Diameter
321 mm (12.6 in)
Cooling
Ventilated
Rear Brakes
Diameter
315 mm (12.4 in)
Cooling
Ventilated

Suspensions

Spring, Front
Coil
Spring, Rear
Coil
Anti-roll Bar
  • Front
  • Rear
Electronic Damper Control (EDC)
Optional
Suspension, Front
Independent
MacPherson Strut
Suspension, Rear
Independent
Multi-link

Fuel

General
Tank Volume
72 litres
General › Fuel Cap Position
Rear
Right
Emission
Emission Standard
Euro 5
Emission Class
E
Emission Control
  • Catalyst
  • Evaporative Control System
  • Exhaust Gas Recirculation
  • Positive Crankcase Ventilation
Fuel Consumption NEDC
City
12.6 litres / 100 km
Highway
6.1 litres / 100 km
Combined
8.5 litres / 100 km
Emission NEDC
CO₂, City
293 g/km
CO₂, Highway
142 g/km
CO₂, Combined
198 g/km

Dimensions & Weight

Exterior

Track, Front
1,560 mm (61.4 in)
Track, Rear
1,541 mm (60.7 in)
Turning Circle
11.3 - 11.5 m

Interior

Head Room, Front
995 mm (39.2 in)
Head Room, Rear
952 mm (37.5 in)
Leg Room, Front
1,081 mm (42.6 in)
Leg Room, Rear
899 mm (35.4 in)
Hip Room, Front
1,366 mm (53.8 in)
Hip Room, Rear
1,353 mm (53.3 in)
Shoulder Room, Front
1,446 mm (56.9 in)
Shoulder Room, Rear
1,392 mm (54.8 in)

Weight

Gross Weight
2,150 kg (4,740 lb)
Cargo Capacity
392 - 441 kg (864 - 972 lb)
Max Roof Load
75 kg (165 lb)

Exterior

Chassis & Body

Chassis
Chassis
Sedan
Pillars
A-C
Chassis Construction
Unibody
Body Material
Steel
Doors
Front Doors
Conventional
Rear Doors
Conventional
Door Handles
Pull-out
Platform
General Motors Platforms
Alpha Platform

Equipment

Side Mirrors
Mirror Type
Conventional
Adjustments
Electrical
Folding
Electrical
User Memory
Yes
Heated
Yes
Windscreen Wipers
Number of Windscreen Wipers, Front
2
Windows
Window Lifts, Front
Powered
Window Lifts, Rear
Powered
Heated Windows
Rear
Sun Visors
Optional
Tinted Windows
Yes
Windows › Window Lifts, Features
One-touch up/down
  • Driver
  • Passenger
Other Equipment
Sunroof
Optional
Tow Hitch
Tow Hitch Preparation
Normal Roof
Yes

Lights

Main Beam
LED
Rear Lights
LED
Daytime Running Light
LED
Fog Lights
Yes
Special Features
  • Automatic Headlight Activation
  • Main Beam Assist
  • Headlight Washers
Fog Lights
Front
Yes
Rear
Yes
Fog Lights › Front
Cornering Lights
Yes
Special Features
Headlight Range Adjustment
Automatic

Rims & Tires

Tire Pressure Monitoring System (TPMS)
Yes
Anti-Theft Locking Lug Nuts/Bolts
Yes
Rim Material
Aluminium
Rim Type
Disc Wheel

Interior

Equipment

Instrument Cluster
Trip Computer
Yes
Head-up Display (HUD)
Optional
Instrument Cluster › Trip Computer
Display
5.7 - 12.3"
Instrument Cluster › Trip Computer › Display
Type
Colour
Climate Control
Climate Control
Automatic
Air Condition
Yes
Outside Temperature Indicator
Yes
Connectivity
Radio
  • AM
  • FM
  • DAB+
Media Format
  • CD
  • MP3
Bluetooth
  • Phone
  • Audio
Connectivity › Media Format
Memory Card Reader
SD
Connectivity › Media Inputs
USB
Yes
Connectivity › Media Inputs › USB
Number of Ports
3 pcs
Displays
Center Display
8"
Displays › Center Display
Type
Colour
Features
Active Noise Cancellation
Yes
Speakers
Total Number of Speakers
11 - 13 pcs
Speaker Brand
Bose
Rear-view Mirror
Adjustments
Mechanical
Anti-glare
Automatic
Rear-view Mirror: Mirror Type
Standard
Interior Storage › Storage Compartments
Glove Compartment
Light
Armrest Hatch
Front
Interior Storage
Cup Holders
Yes
Interior Storage › Cup Holders
Front
2
Rear
Yes
Lights
Read Light
Front
Guide Light
  • Footwell (Front | Rear)
  • Door Handles
  • Bottom of the Doors
Ambient Light
Yes
Other Equipment
Make-up Mirror
  • Driver Side
  • Passenger Side
Clock
Digital
230V Outlet
Optional
Carpets
  • Front
  • Rear
Ashtray
Yes
Cigarette Lighter
Yes
Other Equipment › Make-up Mirror
Make-up Light
  • Driver
  • Passenger

Steering Wheel

Multifunction Steering Wheel
Yes
Heated
Yes
Power Steering
Electric
Adjustments
User Memory
Material
Leather
Colour
Black
Multifunction Steering Wheel
Cruise Control
Yes
Media
Yes
Multifunction Steering Wheel › Media
Answer Phone
Yes
Volume
Yes
Adjustments
Tilt
Powered
Telescope
Powered

Trunk

Rear Trunk
Yes
Automatic Open
Yes
Automatic Close
Yes
Barrier Net/Grid
Yes
Hatch Opening Type
Under Rear Window
Rear Trunk
Volume
447 litres

Seats

Colour & Material
Upholstery
Leather
Seat Colour
Black
Front Seats › Adjustments, Driver
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Lumbar Support
Powered
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats
Number of Driver Seat Adjustments, Manual
4
Number of Driver Seat Adjustments, Powered
8
Number of Passenger Seat Adjustments, Manual
4
Number of Passenger Seat Adjustments, Powered
8
Power Seat, Driver
Yes
Heated Seats
  • Driver
  • Passenger
Ventilated Seats
  • Driver
  • Passenger
Front Seats › Adjustments, Passenger
Seat Depth
Powered
Seat Height
Powered
Backrest Angle
Powered
Lumbar Support
Powered
Headrest, Height
Manual
Headrest, Tilt
Manual
Front Seats › Power Seat, Driver
User Memory
2 slots
Front Seats › Heated Seats
Areas
  • Cushion
  • Backrest
Second Seat Row
Collapsible
Manual
Number of Seats
3
Type of Seat
Adult
Second Seat Row › Collapsible
Backrest Release
On Top of Backrest
Split Fold Ratio
60/40
Heated Seats
Optional
Second Seat Row › Headrests
Outer Seats
Height Adjustment
Centre Seat
Yes
Second Seat Row › Headrests › Centre Seat
Height Adjustment
Yes

Features

Comfort Features

Keyless Entry
Yes
Keyless Start
Yes
Cruise Control
Yes
Cameras
Rear

Other Features

GPS
Optional
Driving Mode Selection
  • Snow
  • Sport

Accessories

Tire Repair Kit
Yes
Coat Hanger
Yes

Safety & Security

Seat Belt

Type of Belt
Three-Point-Belt
  • Front Seats
  • Outer Rear Seats
  • Centre Rear Seat

Assist Systems

Electronic Stability Control (ESC)
Yes
Forward Collision Warning (FCW)
Yes
Rear Cross-Traffic Alert (RCTA)
Yes
Lane Assist System
Yes
Sign Assist
Yes
Lane Assist System
Lane Departure Warning (LDW)
Yes

Brake Systems

Anti-lock Braking System (ABS)
Yes
Traction Control System (TCS)
Yes

Sensors

Parking Sensors
Rear
Blind Spot Detection (BLIS)
Yes
Light Sensor
Yes
Rain Sensors
Yes
Parking Sensors
Front
Optional
Side
Optional

Other Features

Immobiliser
Yes
Anti-theft Alarm
Yes
Child Safety Locks
Yes
Active Bonnet
Yes
Anti-theft Alarm
Interior Monitoring
Yes

Airbags

Feature
Frontal Airbag
Side Chest Airbag
Knee Airbag
Curtain Airbag

Child Protection

Isofix
  • Passenger: -
  • Rear: Yes

Other

Warranty

Manufacturer
100,000 km / 3 years

Car Classification

American Classification
Mid-Size Luxury Car
British Classification
Executive Car
Australian Classification
Large Car
European Segment
E-Segment
Car.info Classification
Executive Car
